Summary of Contents for HESHBON HO-250A
- Page 1 Fully Automatic A.T.F Changer Installation/Operation & Maintenance Manual Installation/Operation & Maintenance Manual HO-250A Please read this manual carefully before operation. You must read and understand the precautions for safety and avoid any damages and injury.
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Introduction 1-1. Features and characteristics 1-2. Names of each part 1-3. Description 1-4. Specification 2. Safety 2-1. Danger/Warning/Caution 3. Operation 3-1. Check points before operation 3-2. Calibration 3-3. Operation 4. Maintenance 4-1. Trouble-Shooting 5. Sparepart List ▶This manual was prepared in January 2017 the product specifications contained in this manual are subject to change without notice. -
Page 3: Features And Characteristics
1-1.Features and characteristics Possible to work for 4-10 shift transmission Exchanging level gauge Mode Possible to work for car type without level gauge DIGITAL Voice guidance Mode DIGITAL One-touch oil line change Mode DIGITAL Input car data Etc. •Equiped electronic digital scale •Oil saving Mode (Some of car type are excluded) •Installed oil exchange program on cooler line... -
Page 4: Description
1-2. Description ① Exchanging level gauge Mode ⑩ Up button ② Exchanging IN/OUT Cooler line ⑪ Down button ③ Oil saving Mode : 0.1 liters of used oil ⑫ Start button recovery and inject new oil, so you let healing the least. (Except for some models) ④... -
Page 5: Specification
1-3. Specification Model No. HO-250A Control type Computer control Measurement Digital scale control Motor 0.2kw 1PH 220V Pump Type TRO CHOID Relief Auto New oil tank 20ℓ Used oil tank 40ℓ Net weight Approx. 50kg Dimension 530(W) x 595(L) x 900(H)mm 2-1. -
Page 6: Operation
Do not apply excessive Make sure to install force to unplug power it indoors only and protect it cord. from rain or snow. ▶ It may cause an electric shock or a fire. Do not expose this product Do not work with this product directly to rain and moisture. -
Page 7: Calibration
3-1. Preparing to work (1) Fill up new oil in the new oil tank. (2) Connect power supply and turn on the power switch. (3) FWD vehicle shift the gear into N and RWD vehicle shift the gear into P. (4) Connect coupler to recovery hose and injection hose. - Page 8 3-3. How to Use (1) Exchanging level gauge mode AUTO_1 volume: 8.0 1) Insert the hose to the oil check gauge of the vehicle. 2) Connect the appropriate accessories in the vehicle. (Accessories for level gauge) 3) Connect a hose on any device orientation. 4) Select the level gauge mode(AUTO1).
- Page 9 (3) Oil saving Mode AUTO_3 volume: 8.0 1) Remove the cooling line of the vehicle. 2) Connect the appropriate accessories in the vehicle. 3) Connect a hose on any device orientation. 4) Check the oil flow direction. (The normal flow is flowing over, under it.) ⇡ 5) Switch the direction lever to replace the line if the oil flow direction does not match.
- Page 10 (5) Discharge used oil DISCHARGE volume: 5.4 1) Pull the exchange lever forward. 2) Connect the hose accessories at the end of Injection hose (red). 3) Press the discharge used oil button. 4) Press the Start button. 5) Check that the discharge through an Injection hose. (6) Other information Description NEW : 0.0 L 1) Standby : Display oil temperature, new oil and...
- Page 11 (7) CVT exchange the Mission oil Volume : 0.0 1) Park the vehicle in a flat position or lift. 2) Set the selection lever to the “P” position and fill the parking brake. 3) Start the engine of the vehicle and check the amount of oil in the oil level gauge check range.
- Page 12 (8) AUTO 3_Exchange : Flushing exchange 3stages Step 3 : Change the Flushing: Press the AUTO3 button to enter this function. Move the arrow with the ENTER button, and change the data with the UP / DOWN buttons 3 STAGE MODE 1sta >...
-
Page 13: Troubleshooting
4-1. Troubleshooting Symptom Solution 1. Check the amount of oil of vehicle 0.1 liter for 20 seconds 2. The vehicle shift lever P-> as N, N-> P When used oil is not recovered After the conversion starts 1. Ensure that the new oil tank is in- stalled correctly 2. - Page 16 Part list Feature Description Code Feature Description Code Electric Hose 880101 880110 valve (1) holder Electric Hose 880102 880111 valve (2) (2.5M) Pressure 880103 Speaker 880112 switch Trans- 880113 Motor 880104 former Key pad 880114 Oil pump 880105 Rear Display 880106 880115 wheel...
- Page 17 Part list Feature Description Code Oil tank 880119 Power 880120 Power ca- 880121 ble socket Pressure 880122 gauge Sight glass 880123...
- Page 18 HESHBON CO.,LTD. 673-52, GYEONGSEO-DONG, SEO-GU, INCHEON, 404-170 KOREA TEL:+82-32-585-3570(Int’l trading) / FAX: +82-32-585-3535 http://www.heshbon.com / e-mail:export@heshbon.com...
