- Page 1 SubDrive NEMA4 Heatsink Cover Kit 225805901 Install Guide 400 E. Spring Street Bluffton, IN 46714 Tel: 260-824-2900 • Fax: 260-824-2909 www.franklin-electric.com 225804101 Rev. 0 M1614 01-10...
- Page 3 SubDrive NEMA4 Heatsink Cover Kit SubDrive NEMA4 Heatsink Cover Kit INSTALLATION GUIDE INSTALLATION GUIDE Notes: Tools and Hardware Required Installation of the heatsink cover requires only a Philips screwdriver. Installation Procedure 1. Locate the three (3) Philips-head screws located on the topside of the SubDrive NEMA 4 unit.
- Page 4 SubDrive NEMA4 Heatsink Cover Kit SubDrive NEMA4 Heatsink Cover Kit INSTALLATION GUIDE INSTALLATION GUIDE 3. Position the heatsink cover with the retention hooks pointing into the four 5. Be sure that the eyelets of the cover align with the screw holes on the topside (4) square opening in the mounting bracket of the drive.
