PET LOADER H20 Assembly Instructions

The Pet Loader comes to you partially assembled and with all the hardware to complete the assembly
and installation on the boat. These assembly instructions will guide you through the assembly of the
steps. Tools you will need are;
¼ Allen wrench – supplied
•
9/16 open end wrench or pliers
•
1) First open the box and lay out all contents on a flat surface. Be sure to check that you have all the
items noted on the parts list. Please note that since the Pet Loader is partially assembled so some of
these components will not be packaged separately in the box.
ITEM NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17-20
21
22
PET LOADER H20 ASSEMBLY INSTRUCTIONS – 3 STEP
PART DESCRIPTION
Boat Deck H2O Petloader as
shipped
7.5625x19.75 Step
Boat Mount Left Bracket
Boat Mount Right Bracket
Rubber Mount Gasket
Mount Plate
Short Brace
9x18 Step
18x24 Platform
Brace Bar
Spacer Washer – 3/8
3/8 SHCS x 1.250
3/8 Washer
3/8 SHCS x 1.000
3/8 Locking Hexnut
3/8 Hex Bolt x 2.50
Position Pins, Pin Mounting Brackets
and Cable Assy.
10-24 PH-CR x .750
10-24 Locking Hexnut
Allen wrench
3/8 SHCS x .75
3/8 Locking Acorn Nut
Default/QTY.
1
1
1
1
4
2
2
1
1
2
4
6
26
2
10
4
4
2
4
1
4
2
