TYPHOON BlackPhysics Quick Start Manual

Features:
»
Standard 81 keys and 13 multimedia keys
» Bluetooth 3.0 by BROADCOM chipset
®
» Scissors keycap structure for keyboard, sensational touch perception
»
The key coding follow Bluetooth
»
When the keyboard is not connected to any device,
press "ESC + K" for ID connection.
»
Press FN + F1 to enter iOS system, FN + F2 to enter Android system,
and FN + F3 to enter Windows system.
»
3 red LED light indicator on the keyboard.
»
Battery uses red light for indication.
»
Supports standard PC, Mac OS, iOS system,
Samsung Galaxy Pad and other Android devices.
Specifications:
Interface
Control Angle
Control Distance
RF Frequency
Date Rate
RF Modulation
Hopping Type
RF Channel
RF Bandwidth
RF Output Power
Sensitivity
Power In
Dimension
BlackPhysics
Wireless Bluetooth 3.0 Keyboard
Part No.: TI013
3.0 HID.
®
USB 2.0
360°
Up to 10 m
2.400 – 2.480 GHz
Bluetooth 3.0 (3 Mbps)
®
Generic AMP
FHSS (Frequency Hopping Spread Spectrum)
79 channels
1 MHz
Bluetooth class 2 (up to +4 dBm)
®
Bluetooth class 2 (down to -86 dBm)
®
Enhanced power control
342.5 x 112.5 x 7 mm
