- Page 1 DIESELFIxx / DIESELMAxx with NUMERIxx3 oval gear meter, mechanical 60 l/min · 100 l/min 230 V-1~AC...
-
Page 2: Table Of Contents
Construction and Functional Description The diesel pump can be fitted with a variety of FMT accessories. To prevent environmental damage the diesel pump is fitted with a siphon protection system. This means that if the discharge hose is damaged while the pump is stopped, siphon action will not empty the tank. -
Page 3: Application Range
Operating instructions for DIESELFIxx / DIESELMAxx G Application Range The diesel pump is suitable for the delivery of diesel and heating oil only when they are not heated above their flash points. The temperature of the delivery fluids must be between –10 °C and +40 °C. The temperature limits must not be exceeded. -
Page 4: Risks When Working With The Diesel Pump
G Operating instructions for DIESELFIxx / DIESELMAxx Risks when Working with the Diesel Pump Danger! Never work on a pump that is running! Mount or remove attachments and accessories only when the pump is switched off. ■ ■ For your own safety, disconnect the pump from the power supply. ■... - Page 5 Operating instructions for DIESELFIxx / DIESELMAxx G Figure 3-1: Removal of cover 4 screws (not supplied) with diameter less than 9 mm are required to attach the fuelling station unit. Select suitable screws according to the surface on which the unit is to be mounted.. Screw in the screws so far, that between screw head and wall approx.
-
Page 6: Mounting The Hose Support
G Operating instructions for DIESELFIxx / DIESELMAxx Mounting the hose support The hose support is pre-assembled. Loosen the two screws and pull out the hose support, appr. 100 mm. Tighten the screws. 100 mm Figure 3-2: Mounting the hose support Installing the Siphon Protection Remove cover as in chapter 3.1. -
Page 7: Safety
Operating instructions for DIESELFIxx / DIESELMAxx G Caution! Never operate the pump without delivery fluid. There is a danger of your diesel pump being damaged if operated dry. Squeeze the nozzle valve control lever according to the delivery flow required, or lock it in „automatic“ for maximum delivery rate. -
Page 8: Servicing
G Operating instructions for DIESELFIxx / DIESELMAxx Servicing Replacing worn blades Danger! Never work on a pump that is running! Assemble or disassemble accessories only with switched off pump. ■ ■ For your own safety additionally isolate the pump unit from the power supply. ■... -
Page 9: Repairs/Service
Operating instructions for DIESELFIxx / DIESELMAxx G Repairs/Service The diesel pump was developed and produced according to the highest quality standards. Should a problem develop, despite all quality controls, please contact our customer service: FMT Swiss AG Tel +49 9462 17-216 Fax +49 9462 1063 service@fmtag.ch Spare parts and accessories Diesel pump 60 l/min, No. -
Page 10: Exploded View
G Operating instructions for DIESELFIxx / DIESELMAxx Exploded view Quantity Description DIESELFIxx DIESELMAxx Sheet metal assembly for DIESELFIxx NUM 83 791 Sheet metal assembly for DIESELMAxx NUM 83 792 Washer DIN1256,4x12x1,6 - Steel zn 04 516 04 516 Screw DIN 933 M6x20 - 8.8 zn 02 886 02 886 Countersunk screw DIN 7991 M3x22... - Page 11 Cheese head screw M3x25 DIN 912 A2K 8.8 83 401 83 401 Nozzle support for Dieselfixx 85 036 85 036 FMT display foil for DIESELFIxx-DIESELMAxx 84 285 84 285 Diesel-exchange filter 30 µm - 100 l/min - G 1½“ i 23 209 23 209 Elbow 90°-Al-DN 19 G 1“...
- Page 12 G Operating instructions for DIESELFIxx / DIESELMAxx...
- Page 13 Operating instructions for DIESELFIxx / DIESELMAxx G...
- Page 14 FMT Swiss AG Fluid Management Technologies Swiss AG Gewerbestraße 6 6330 Cham / Schweiz Tel. +41 41 712 05 37 Fax +41 41 720 26 21 info@fmtag.com www.fmtag.com...
