Display Mount Pro DRS601 Assembly Instructions

Assembly Instructions for DVD/BLUE-RAY/Receiver Shelf

Thanks for choosing our DVD/Blue-Ray/Receiver shelf, this shelf was designed to be mounted on the wall.
Safety Warning: If you do not understand these directions, or have any doubts about the safety of the installation, please call a
qualified contractor. Check carefully to make sure there are no missing or defective parts. Never use defective parts. Improper
installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this
manual. We can not be liable for damage or injury caused by incorrect mounting, incorrect assembly, or incorrect use.
Note: We makes every effort to assure all necessary television mounting hardware is included. If the hardware you need is not
included please consult your local hardware store.
Required Tools: Phillips screw driver.

Supplied Parts

No.
1
2
3
4
5
6
7
8
9
10
Description
Glass Shelf
Right Shelf Support
Left Shelf Support
Wall Plate
M5 Screw
Glass Shelf Aluminum Head
M6 Screw
M6 Washer
Lag Bolt
Concrete Anchor
1
English
Quantity
1
1
1
1
4
2
2
5
3
3
