Wheatstone TALENT STATION TS-4 Technical Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TS-4
T
S
alenT
TaTion
T
M
echnical
anual
600 Industrial Drive, New Bern, N.C. 28562 (tel 252-638-7000 / fax 252-637-1285

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TALENT STATION TS-4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Wheatstone TALENT STATION TS-4

  • Page 1 TS-4 alenT TaTion echnical anual 600 Industrial Drive, New Bern, N.C. 28562 (tel 252-638-7000 / fax 252-637-1285...

  • Page 2: Technical Manual

    TS-4 alenT TaTion echnical anual Wheatstone Corporation September 2013...
  • Page 3 TS-4 Talent Station Technical Manual ©2013 Wheatstone Corporation 600 Industrial Drive New Bern, North Carolina 28562 tel 252-638-7000 / fax 252-637-1285...
  • Page 4 This equipment must be installed and wired properly in order to assure compliance with FCC regulations. Caution! Any modifications not expressly approved in writing by Wheatstone could void the user's authority to operate this equipment. TS-4 / Oct 2013...
  • Page 5 In order to utilize all the features of the TS-4 Talent Station the device must be added to the System Peripheral Devices tab in the Wheatstone WheatNet-IP Navigator program (aka the Navigator GUI). This sheet shows you the basics of that procedure. Refer to the WheatNet‑IP BLADE 3 Audio Over IP Network Technical...

  • Page 6: Table Of Contents

    C O N T E N T S TS-4 Technical Manual Table of Contents Chapter 1 - General Information Introduction ..................1-2 TS-4 Placement ................1-2 TS-4 Desk Panel Full Size Template ................1-4 TS-4V Talent Station Countertop Full Size Template ..........1-4a TS-4H Talent Station Countertop Full Size Template ..........1-4b TS-4V Talent Station Turret Full Size Template............1-4c TS-4V Talent Station Turret Full Size Template............1-4d...
  • Page 7 C O N T E N T S Chapter 4 - Device Setup Device Definition ................4-2 Device List Window ....................4-2 Add, Edit, or Remove Devices in List .................4-2 Add New Device ......................4-2 Edit “Selected Device” ....................4-2 Remove “Selected Device” ..................4-2 Online Check Box ....................4-3 Add / Edit Device Dialog ....................4-3 Mapped BLADE Configuration .............
  • Page 8 GENERAL INFORMATION General Information Contents Introduction ..................1-2 TS-4 Placement ................1-2 TS-4 Desk Panel Full Size Template ................1-4 TS-4V Talent Station Countertop Full Size Template ..........1-4a TS-4H Talent Station Countertop Full Size Template ..........1-4b TS-4V Talent Station Turret Full Size Template............1-4c TS-4V Talent Station Turret Full Size Template............1-4d Power Supply and Ethernet Connection ........

  • Page 9: Introduction

    GENERAL INFORMATION General Information Introduction TS-4 Talent Station provides lighted on/off/mute and talkback switches for a single talent microphone. A rotary headphone source selector is provided along with an OLED display for identifying the selected source. The source selector doubles as a volume control.
  • Page 10 GENERAL INFORMATION The TS‑4 ships with attached under counter mounting bracket and four screws for securing the unit to the countertop. page 1 - 3 TS-4 / Sep 2013 TS-4 / Oct 2013...

  • Page 11: Ts-4 Desk Panel Full Size Template

    1- 3/ 4" 6" 5- 1/2" COUNTER CUTOUT DIMENSIONS 5-1/2" x 1-3/ 4" FRONT PANEL FACE RECESS DIMENSIONS 6" x 1- 3/4" x 3/32" TS-4 Desk Panel Full Size Template page 1 - 4 TS-4 / Apr 2014...

  • Page 12: Ts-4V Talent Station Countertop Full Size Template

    2-7/16" R - 1/8" TYP. 2-3/16" 7-3/8" 8" 7-5/8" 3/16" D =1/16" COUNTER CUTOUT DIMENSIONS 7-3/8" x 2-3/16" FRONT PANEL FACE RECESS DIMENSIONS 8" x 2-7/16" x 3/32" TS-4V Talent Station Countertop Full Size Template page 1 - 4a TS-4 / Sep 2016...

  • Page 13: Ts-4H Talent Station Countertop Full Size Template

    8" 7-3/8" R - 1/8" TYP. D =1/16" 2-7/16" 2-3/16" FRONT PANEL FACE RECESS DIMENSIONS 8" x 2-7/16" x 3/32" COUNTER CUTOUT DIMENSIONS 7-3/8" x 2-3/16" 3/16" 7-5/8" TS-4H Talent Station Countertop Full Size Template page 1 - 4b TS-4 / Sep 2016...
  • Page 14 4-1/8" 2 Drill Center Marks for #8 Screws 3/16" bit 8-15/16" 5-3/16" 4-3/4" 3/8" 3-3/8" TS-4V Talent Station Turret Chassis Full Size Template page 1 - 4c TS-4 / Sep 2016...
  • Page 15 2 Drill Center Marks for #8 Screws 3/16" bit 3-3/16" 6-3/4" 10" TS-4H Talent Station Turret Chassis Full Size Template page 1 - 4d TS-4 / Sep 2016...

  • Page 16: Power Supply And Ethernet Connection

    Station and power supply adapter together. Connect To Network The Talent Station must be connected on a network with at least one Wheatstone BLADE in order to function. The unit has been programmed at the factory with a device Name and an IP Address. This information is displayed on a label on the device. Please make sure you know what name and IP address are programmed for the device as you follow these steps.
  • Page 17 T S - 4 O P E R A T I O N TS-4 Operation Contents Volume Knob and INPUT Button ..........2-2 Display .................... 2-2 Signal Name .......................2-2 Signal Location ......................2-2 Microphone Icon ......................2-2 Microphone Buttons ..............2-3 Microphone LIOs ......................2-3 Studio Tally LIOs ......................2-4 Front Panel Menus ................

  • Page 18: Volume Knob And Input Button

    T S - 4 O P E R A T I O N TS-4 Operation VOLUME Knob and INPUT Button The TS-4 has a VOLUME knob that is used to control the volume of the headphone plugged into the Talent Station. The current volume level is shown in the blue line at the bottom of the display.

  • Page 19: Microphone Buttons

    T S - 4 O P E R A T I O N Microphone Buttons The Talent Station TS-4 has four Microphone buttons – ON, OFF, TB, and MUTE. These buttons are designed to be used to support the usual micro- phone functions.

  • Page 20: Studio Tally Lios

    T S - 4 O P E R A T I O N The LIOs are defined so they can be included in a Source signal, which could be connected to a Destination signal on a surface, which in turn supports the microphone LIOs.

  • Page 21: Front Panel Menus

    T S - 4 O P E R A T I O N Front Panel Menus There are several operations that can be performed from the TS-4 front panel. To perform these operations you first must enter the front panel menu system. To do this, press and hold the INPUT button for about five seconds until the display shows the menu.

  • Page 22: Versions

    T S - 4 O P E R A T I O N • Dim Level – this item allows you to view the brightness setting of the TS‑4 dis‑ play when it is in dim mode – dobby the VOLUME knob and you can edit this setting • Dim Timeout –...
  • Page 23 S E T U P G U I O P E R A T I O N Setup GUI Operation Contents Installing The Talent Station Setup Tool ........3-2 File Menu ..................3-2 View Menu ..................3-2 WheatNet-IP System Menu ............3-2 Hardware Menu ................

  • Page 24: Installing The Talent Station Setup Tool

    S E T U P G U I O P E R A T I O N Setup GUI Operation Installing The Talent Station Setup Tool You begin Talent Station setup by running the WheatNet‑IP Talent Station‑4 Setup Tool program that shipped either with the system or with the TS‑4. If you haven’t already done so, install the program by running the provided Talent Station GUI installer file –...
  • Page 25 S E T U P G U I O P E R A T I O N scan the system database is stored in a file on your PC so that you have the information whether you are attached to your WheatNet‑IP system network or not. • File Open...
  • Page 26 S E T U P G U I O P E R A T I O N then be prompted to select an RBN file from your PC hard drive. Some de‑ tails of the selected file will be shown before you begin the download of the new software.
  • Page 27 D E V I C E S E T U P Device Setup Contents Device Definition ................4-2 Device List Window ....................4-2 Add, Edit, or Remove Devices in List .................4-2 Add New Device ......................4-2 Edit “Selected Device” ....................4-2 Remove “Selected Device” ..................4-2 Online Check Box ....................4-3 Add / Edit Device Dialog ....................4-3 Mapped BLADE Configuration .............

  • Page 28: Device Definition

    D E V I C E S E T U P Device Setup Device Definition You will need to setup your GUI with a list of each TS‑4 panel in your system. The setup steps only need to be performed once since the setup information will be stored on your PC.

  • Page 29: Online Check Box

    D E V I C E S E T U P Online Check Box The online check box allows you to set your GUI offline when you are not con‑ nected to a device. If the online check box is checked, the GUI will be trying to estab‑ lish a TCP connection to the device which is selected in the device list.
  • Page 30 D E V I C E S E T U P The button labeled “...” to the right of the IP address edit boxes will open a BLADE picker dialog box when pressed. The Blade Picker (shown below) will display all of the BLADEs that are known to your system info database.

  • Page 31: Miscellaneous Setup

    D E V I C E S E T U P Miscellaneous Setup The Miscellaneous Tab is used to specify a number of parameters for the TS‑4 Talent Station. The setup steps only need to be performed once since the setup information will be stored in the TS‑4 Flash memory and on your PC.

  • Page 32: Display Brightness

    D E V I C E S E T U P Display Brightness The brightness of the display can be controlled by the settings in this region. The display brightness varies from a set‑ ting of 1 (which is off) to a maximum of 16.

  • Page 33: Visibilities

    D E V I C E S E T U P Visibilities The Visibilities tab is used to configure the set of Source signals that is shown when doing a Source selection for the Talent Station headphone. Channel This area is used to select which destination the visibilities is being configured for.
