Summary of Contents for S-RFID HW-5056
- Page 1 HW-5056 &HW-5088 Proximity Reader User’ s Manual LCD SCREEN...
- Page 2 ★ Open door from the Keypad： The Screen Shows: HW-5056 I-OPEN When the user press *, the reader open the door and the screen 9/01/12 00:03:23 will show I-OPEN ★ To change the PIN code： After the user presents the card and enters the PIN code, he/she has to press OFF, and enter a new 4 digits PIN code.
- Page 3 1 to 4 seconds, depends on the memory capacity of the reader. ♦ After senor, the LCD will show: HW-5056 OPEN I : ******** ♦ Ender the password , the LCD will show:...
- Page 4 II. Set up the Functions： ♦ Use the Master Card to senor the reader and press OFF will get to Function set up screen LCD display of Function Set Up Menu HW-5056 FUN:** A. Set up the Electronic Lock Timing HW-5056 FUN:01 DROTM:01.0 SEC...
- Page 5 ♦ Press CLS to exit. ※ The above four functions will not be in active if enter 0. E. Set Up the Date HW-5056 FUN:10 DATE:02/00/01 ♦ This is to set up the date in the reader ♦ Input 10 and press ENT ♦...
- Page 6 G. Set Up Reader Number Linked Through RS-485 HW-5056 FUN:14 LN485:****** ♦ Set up the reader number ♦ Input 14 and press ENT ♦ Input the model number from 000000-999999, then press ENT ♦ Press CLS to exit. H. Delete All Learned Cards...
- Page 7 III. Wire Layout + Reader Power -- DC 12V 600mA Black Blue Green +Lock Power – Lock (NO) DC12V 1A CON8 Alarm (12V) Orange Black Weigand DATA 0 White Weigand DATA1 Yellow Magnetic Switch (NC) Open Door With SW Blue (NO) Green Link to Computer DATA --...
- Page 8 PIN4 PIN6 PIN5 PIN4 6P BOX PIN3 150O (PHONE) PIN2 Forward Resistance PIN1 PIN1 PIN2 PIN3 PIN5 : DATA + Connect to HW-5056 Brown Line : DATA + PIN4 : DATA－ Connect to HW-5056 Green Line: DATA－ PS..In the middle...
- Page 9 HW-5056 Number 1 HW-5056 Number 2 PC Output Port Brown Green Brown Green COM1 or COM2 ＋ － － 150O RS232ßà RS485 Terminal Converter Resistance (PHONE) Signal Line PIN5 150Ω PIN4 ★ PS. Warning : 1. Installation : A.. Signal line must connect to Number 1 from box(Phone), and from Number1 to Number 2 and to Number 3…...
- Page 10 2. Box(Phone) have to install a forward resistance (150 Ohm). The terminal resistance has to install in the line of latest HW-5056. èYou have to install two resistance ( 150 Ohm) in the whole line. 3. 4P or 6P is available only ( Line).
