- Page 1 Terminus T3 Products User Manual Bulletin JA19-UM Revision Date 25 May 2017...
-
Page 2: Table Of Contents
Winfield reserves the right to make modifications, additions and deletions to this document due to typographical errors, inaccurate information, or improvements to programs and/or equipment at any time and without notice. Such changes will, nevertheless be incorporated into new editions of this application note. All rights reserved 2011 Connor-Winfield Corporation Terminus T3 User Guide JA19-UM Page 2 Rev: 00 Date: 05/25/17 ©... -
Page 3: T3 Connections
T3 Terminus Description The Terminus T3 is a communication control terminal with a compact, rugged enclosure that encapsulates everything needed for easy M2M integration. The multiple orderable versions allow for system deployment in different networks with little to no change in the design investment. -
Page 4: Rs232
On/Searching Slow Blinking (0.3 sec on / 2.7 sec off) Registered Fast Blinking (0.5 sec on / 0.5 sec off) Shutting down Terminus T3 User Guide JA19-UM Page 4 Rev: 00 Date: 05/25/17 © Copyright 2017 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. -
Page 5: Antenna Connections
Slide the top of the SIM card holder back to unlock, insert the SIM card and close. Slide back to the original position to lock back in place. Step 5. Slide the panel back into the enclosure, replace, and tighten the four TX-10 screws. Terminus T3 User Guide JA19-UM Page 5 Rev: 00 Date: 05/25/17 ©... -
Page 6: Absolute Maximum Ratings
SMS or Socket attempt. Note: 1) Average Supply Current specification is stated as the maximum average current the Terminus T3 terminal can draw while maintaining junction temperatures within the internal power supply IC’s specifications. It is the applications responsibility to maintain operation within this limit to maintain reliable operation over the life of this terminal product. 2) Values taken with GPS turned OFF. When GPS is used, expect a 20mA increase during operating states. Terminus T3 User Guide JA19-UM Page 6 Rev: 00 Date: 05/25/17 © Copyright 2017 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. -
Page 7: Cellular Antenna Specifications
Input Power > 24.4 dBm in CDMA ≤ 5:1 VSWR Absolute Max ≤ 2:1 VSWR Recommended Terminus T3 User Guide JA19-UM Page 7 Rev: 00 Date: 05/25/17 © Copyright 2017 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. -
Page 8: Gps Antenna Specifications
=< 15dB overall at the connector (Antenna and LNA included) Impedance VSWR Current Consumption 30mA Max, 20mA Typ Terminus T3 User Guide JA19-UM Page 8 Rev: 00 Date: 05/25/17 © Copyright 2017 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. -
Page 9: Mechanical Specifications
.3250 5.2142 4.1142 1.811 0.790 All measurements in inches unless otherwise noted. Terminus T3 User Guide JA19-UM Page 9 Rev: 00 Date: 05/25/17 © Copyright 2017 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. -
Page 10: Starting A Terminal Session
Getting started with the T3 This will take you through the basic steps required to power the Terminus T3 and communicate with the modem. Please confirm that you have these items before continuing. If you are evaluating the GSM or HSPA based T3 ensure that you have an active SIM card. -
Page 11: Sending An Sms
To enter the receiving subscriber unit phone number and message enter: AT+CMGS=”8885551234” Wait for response”>” then enter message text Enter “ctrl z” <cr> to end the message Terminus T3 User Guide JA19-UM Page 11 Rev: 00 Date: 05/25/17 © Copyright 2017 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. -
Page 12: Making A Gprs Data Call
• Start NMEA Stream: Send command AT$GPSP=1<cr> • End NMEA Stream: Send command AT$GPSP=0<cr> Terminus T3 User Guide JA19-UM Page 12 Rev: 00 Date: 05/25/17 © Copyright 2017 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision. - Page 13 • Start NMEA Stream: Send command AT$GPSP=1<cr> • End NMEA Stream: Send command AT$GPSP=0<cr> Terminus T3 User Guide JA19-UM Page 13 Rev: 00 Date: 05/25/17 © Copyright 2017 Janus Remote Communications Specifications subject to change without notice All Rights Reserved See website for latest revision.
-
Page 14: Revision History
Terminus T3 Products User Manual Terminus Models & Ordering Ordering Description HSPA910T3 v1.00 HSPA+/UMTS/EDGE/GPRS/GSM (AT&T Certified) EVDO910T3 v3.00 EV-DO (Verizon) CDMA910T3 v2.00 CDMA-1xRTT (Sprint) CDMA910T3 v3.00 CDMA-1xRTT (Verizon) CDMA910T3 v4.00 CDMA-1xRTT (Aeris) LTE910T3 v1.00 LTE (AT&T) LTE910T3 v2.00 LTE (Sprint) LTE910T3 v3.00...
