Summary of Contents for Mintech MC-1250

Page 1 Mintech MC-1250 Operating manual 1 / 36...
Page 2 Notice  Please read Chapter Three carefully and all requirements should be strictly observed.  It is strongly recommended that the users read this manual and in particular Chapter One, safety instructions and precautions, before operating the machine.  Do not use the machine in condition of opening the door of the control cabinet.
Page 3 Chapter One: Safety Instructions and Precautions Chapter Two: general description Chapter Three: Installation and Utility Requirements Chapter Four: Operation Chapter Five: Maintenance and Troubleshooting 3 / 36...
Page 4 Chapter One 1.1 General Information 1.2 Laser Safety 1.3 Safety Instructions in Operation 1.4 Safety Instructions in Maintenance 4 / 36...
Page 5: Safety Instructions And Precautions
1 Safety Instructions and Precautions t is strongly recommended that any personnel who are involved with the operation or maintenance of this equipment should first read the contents of this manual. Only authorized personnel who have been instructed in and fully understand the necessary safety procedures must use this equipment.
Page 6 1.1.2 Some important instructions:  1325/1530 is using laser to cut. Laser light, because of its special properties, poses safety hazards not associated with light from other sources. The safe use of lasers requires that all laser users and everyone near a laser be aware of the dangers involved in laser operation.
Page 7 associated with light from other sources. The safe use of lasers requires that all laser users and everyone near a laser be aware of the dangers involved in laser operation. Only authorized personnel who have been instructed in and fully understand the necessary safety procedures must use this laser equipment.
Page 8 Safety precautions Exercise caution to protect against specular reflections since reflections at the laser wavelength are invisible. Eye safety is great concern when using a high-power laser. There are often many secondary beams present at various angles near the laser. These beams are specular reflections of the main beam from polished surfaces.
Page 9  Avoid operating the laser in a darkened environment. Do not use the laser in the presence of flammables, explosives, or  volatile solvents such as alcohol, gasoline, or ether. For additional information on laser safety, refer to the following publications: ...
Page 10  The cable that connected with power supply should be long enough and have damage-protecting external cover. The numerical control system of this machine has strict requirements for the input voltage. Manostat is strongly recommended, to ensure the voltage conform to the requirements for the voltage.
Page 11  The water cooler system should have been running for ten minutes before operating the cutting machine. And check the whole water cooler system, to ensure there are no air bubble in the pipe. Before operating the cutting machine, check each parameter setting, to ensure there are no air bubble in the pipe.
Page 12 Chapter Two 2.1 Introduction 2.2 Technical specification 2.3 Machine structure 12 / 36...
Page 13: General Description
2.General description 2.1 Introduction MINTECH MC-1250/MC-2500 is a brand-new mixing cutting machine which can cut thin metal, acrylic, wood and other nonmetals. The machine can come to Chinese tube 100W/130W/ 220W/260W. MC-1250/MC-2500 with high quality configuration: Here are industrial standard configuration including fixed beam optical laser system, cutting...
Page 14: Technical Specification
2.2 Technical specification Model MC-1250 Laser power 150W CO² Sealed Glass Transverse mode quality ≤1.1 49" x 36" Worktable dimension (1250mm x 900mm) 330 lbs Workbtable load (150 kg) 1-3/16 inch Cutting ability (Acrylic) (30mm) 65.6 ft/min Speed of positioning(X,Y) (20 m/min) ±0.002"/39.4"...
Page 15: Machine Structure
2.3 Machine structure Laser Cutting Machine (figure 2-1) contains of laser unit, the cutting machine, control system, water chiller. Figure 2-1 Laser cutting machine 2.3.1 The cutting machine The cutting machine consists of the base, worktable, gantry frame, cutting head and operating panel. The worktable fixed on the base, and the gantry frame 15 / 36...
Page 16 moves on the rails fixing on the base. The laser unit and the cutting head move on the rails fixing on the gantry frame. There are four casters under the base. The left is the cabinet containing all electric components. The right near the back is the vent, connecting it to exhaust by pipe, thus can vent exhaust gas that cutting made.
Page 17 beam delivery system includes reflecting mirror and lens. (figure 2-3) A,B,C ,D,E are reflecting mirrors and F is lens. Figure 2-3 The Laser Unit Laser head was fixed in the shield. When cutting workpiece, should prevent optics lens from being damaged by high reflectivity material.
Page 18 must filtrate by the clean air system, to ensure the accessorial cutting gas conform to the purity requirements. Refer to figure 2-4. When use the compressed air, you should provide oil mist seperator, filter and dryer, to ensure the particles is smaller than 5μm, the content of condensate is lower than 5mg/m , the content of oil is lower than 0.1 mg/m .
Page 19 Chapter Three 3.1 Hoist and transpotation 3.2 The preparing requirements of the machine installation and adjustment 3.3 The work shop and environment requirements 3.4 Utility requirements 19 / 36...
Page 20 3. Installation and Utility Requirements 3.1 Hoist and transportation It is necessary to fix the moving parts and the whole machine when packing. Pay attention to machine net weight and the position of center of gravity while the machine is being hoisted. The jacks should have enough carrying capacity. It is strongly recommend that moving the machine must be lightly, slowly and smoothly, and collision and leaning should be avoid.
Page 21: Utility Requirements
The groundwork should be tamped. the cement is No. 400, its thickness is more than 50mm. It is recommended that the ground should be covered with water millstone or lacquer. Brush the wall surface with the white lacquer. The door and windows should have well hermetic characteristic. Plastic steel is recommended.
Page 22 3.4.1 Power supply requirement: The main power supply is single-phase 220V 60Hz, full current is 13A the voltage range is 220V±10%. And the area of lead cross section is more than 2.5mm The numerical control system of this machine has strict requirements for the input voltage.
Page 23  Any time, you can start chiller again more than three minutes later after the chiller’s power off, otherwise the chiller can be easily damaged.  Prevent wiring from being sprinkled, otherwise conducing creepage and damaging the chiller.  Do not touch inside, prevent high speed fan and high temperature from hurting body.
Page 24: Operation
Chapter Four Operation 4.1 Notices 4.2 Introduction 4.3 Operating Interface 4.4 Operating Steps 24 / 36...
Page 25 4. The air pressure of the accessorial air source is not less than 0.6MPa and the working air pressure range is from 0.02 to 0.4MPa. 4.2 Introduction MINTECH 1325 / 1530 adopts PC-Based motion controller, it can operate on Windows. The characteristic of the program 1.
Page 26: Operating Interface
Operating Interface 26 / 36...
Page 27 X/Y movement and reset Z movement and reset Program name Cutting start Time of program processing Repeat time setting Cutting stop Cutting speed adjustment Power Program frame Corner power Fire power setting Fire time setting Laser beam output Jog setting 27 / 36...
Page 28: Operating Steps
Turn the key of the start button on the operating panel and the whole system has been enabled. Loosen the emergency button on the operating panel. g. Enter the software of DONGGUAN MINTECH Technology Co., Ltd. 4.4.4 Perform the program a. Click the Import button in the toolbar and select the object to cut.
Page 29 c. Click the Start button in the screen d. Finished the cutting. 4.4.5 Power off a. Push the Emergency button down. b. Switch off the cutting machine. c. Shut off the air pump. d. Shut off centrifugal exhaust fan. e. Shut off the computer. Shut off the water chiller after 5~10 minutes.
Page 30: Maintenance And Troubleshooting
Chapter Five Maintenance and Troubleshooting 5.1 Lubrication Requirements 5.2 Daily inspection 5.3 Optics inspection and cleaning 5.4 Adjustment of the Beam Delivery Optics 5.5 Troubleshooting...
Page 31: Lubrication Requirements
5 Maintenance and Troubleshooting 5.1 Lubrication Requirements Lubrication is absolutely necessary to the linear guide and ball nut. The normal used lubrication oil is No.3 lithium base grease. Lubricate the ball nut and rolling linear guides every two weeks and ensure the grease is enough.
Page 32 The cooling water in the chiller of laser must be instead of new water  periodically (not more than one week). Clean the water tank. If the color of the core in filter changed, you should exchange it. Step: shut off the chiller, take down the export cover, take out the old core, put in the new one, then screw down the cup.
Page 33 Figure 5-1 the Cleaning Picture of Optics Lens Adjustment of the beam delivery For the sake of the normal usage, the operators should be familiar with the operation of adjustment, maintenance of the beam delivery optics. laser is a Class 4 laser product (there are warning This labels on the laser unit and the beam path).
Page 34 reflection and goes forward along Z axis. Then the beam enter the cutting head and focalize by the lens D. Finally, the laser beam vertically incident to the worktable out of the nozzle. Ensure the laser output beam can’t be blocked during the whole travel.
Page 35 5.5 Troubleshooting 5.5.1 Limit warning If it exceeds the stroke limit, the machine will stop. Including: “X+" means the X forward side exceeded the stroke limit. “Y+" means the Y forward side exceeded the stroke limit. “X－" means the X reverse side exceeded the stroke limit. “Y－"...
Page 36 ● The surface of material for machining has rusted. ● The material is moist. Solution: ● Adjust the focus; ● Adjust the beam or the nozzle, ensure both of them are concentric. ● Accessorial gas: metal- oxygen, nonmetal- the air; And adjust the air pressure.
