Page 3 SAT>IP CI+ Receiver User’s Manual ZIP - 5107...
Page 4 SAFETY INSTRUCTION Please review the following safety precautions. If this is your first time to use a SAT>IP Receiver, then read this manual before installing or using this receiver. If the receiver is not functioning properly, please contact your local distributor or system installer. n Please read the safety instructions carefully.
Page 5 Be careful with electricity: Power outlet : To prevent electric shock, make sure the electrical plug used on the receiver’s power cord matches the electrical outlet used to supply power to the receiver. Connect the power cord only to a power source that operates at 90~250 Volts AC, 50/60 Hz. Power plug : If a three-prong power plug is provided with the receiver, make sure it is used with a properly grounded three-wire power socket.
Page 6: Table Of Contents
TABLE OF CONTENT SET UP RECEPTION SYSTEM ..............................5 PRODUCT OVERVIEW ................................6 FEATURE ....................................7 REMOTE CONTROL ................................. 8 INITIAL SETUP ..................................9 CI+ SMART CARD SLOT ............................... 10 MAIN MENU ..................................... 11 CHANNELS ....................................11 EPG ......................................13 SETTINGS ....................................
Page 7: Set Up Reception System
Set Up Reception System If your service provider or system installer has already set up the SAT>IP Server Set-Top-Box and connected it to this receiver, then you may want to skip this section. However, if you are setting up the system by yourself, please read below "Connecting to Audio &...
Page 8: Product Overview
Product Overview n Front Panel GREEN LED It lights on when the power is on. BLUE LED It lights on when receiving signal from server. Press to switch between Operation and POWER STANDBY Standby modes. RESET BUTTON Press to reset the receiver. n Rear Panel Connect to DC input of the Power Adapter.
Page 9: Feature
Therefore, the client can enhance your experience and allow you to watch not only Free-To-Air programs but also Pay-Tv channels. Package Contents Please check the parts in the package. Contact the distributor if something is missing. ZIP-5107 SAT>IP CI+ Receiver A/C Power Cord Remote Control Unit Users’ Manual Description of Equipment ZINWELL High Definition SAT>IP Receiver are designed to receive free-to-air and encrypted...
Page 10: Remote Control
Remote Control The remote control provides easy access to all of the receiver’s functions, including selecting channels and using the menus. It uses infrared signals, and must be operated within seven meters from the receiver. When using the remote control, make sure there is a direct line of sight to the receiver. Please install the batteries in the remote control before using the receiver.
Page 11: Initial Setup
Initial Setup When plug in the power in the first time, the SAT>IP Receiver will enter below initial setup screen. • Menu Language : Select the language for the menu and OSD (On Screen Display). • Time Zone : Set up the time for the receiver. •...
Page 12: Ci+ Smart Card Slot
CI+ Smart Card Slot How To Watch Scrambled Channel Using The SAT>IP Receiver? What is scrambled channel? l When message “Program scrambled” with black screen. It means this program has been encrypted and you need to purchase an authorized smart card to decrypt it. Use smart card to watch scrambled channel l After inserting a smart card, the receiver will start the authorization procedure automatically, and you...
Page 13: Main Menu
Main Menu Press “MENU” key to display the Main Menu screen. Use the cursor keys to move through the menu, the “OK/LIST” button to choose your option. Note: Entering some menus requires a password. The default password is “0000”. CHANNELS In the Channels menu, you can conduct the following functions: Channel List Manage l Displays the channel list.
Page 14 Operator Profile l Operators can show their profile in this menu.
Page 15: Epg
The EPG (Electronic Program Guide) is a table which displays current and upcoming TV program’s detail information up to 7 days. The EPG shows the program schedule for all services broadcasting EPG information. Note: not all broadcasters provide program information. You can use cursor keys to select channel and use “RED KEY”...
Page 16: Settings
SETTINGS Audio Setup l You can select available audio language(s). Video Setting Menu l You can set the video output and screen ratio in this menu: HD Video Format: You can switch the output resolution between (480i), (576p), (720p), (1080i), and (1080p). Aspect Ratio: You can choose between (4:3 Pan Scan), (4:3 Letterbox), (16:9 Wide Screen), and (Full Screen) for video output.
Page 17 OSD Setting Menu l I-Plate Timeout: To adjust the display time of the information box, set the Info Box Display Time option as you desire. Its available range is 5 to 20 seconds. l Menu Language: The Sat>IP SAT>IP Receiver provides menus in different languages.
Page 18: Installation
INSTALLATION Manual Scan l You can implement the channel scan manually by entering specific information, such as Channel Number, Frequency, Symbol Rate, System Type, Polarization, Modulation, FEC, DiSEqC parameter. l *Note: The default password is “0000”. Auto Scan l By choosing the auto scan, current channel list will be erased, and all available channels will be added automatically.
Page 19: System
SYSTEM Password l You can change the default password “0000” to your desired password. Information l You can see all the system information in this menu, such as Hardware version, Software version, IP Address, MAC Address, Release Time, and System Date.
Page 20 USB Upgrade l You can upgrade the SAT>IP Receiver with the latest firmware. The upgrade process can be complete by doing three steps; First, Store the latest firmware to a root folder of a USB drive. Second, plug the USB drive in the SAT>IP Receiver. Third, conduct the USB upgrade menu.
Page 21 l In this menu, you can see information about your Smart Card if it’s properly inserted. Depending from module you can read module information, smart card information, and download new software for module and set up module language. l Select the ‘CA’ and press “OK”. PIN-Code modification l You can change the PIN-Code of the Smart card.
Page 22 Select Smart Card’s language l You can choose the language of the smart card. Module Information l You can show information of the CAM(Conditional Access Module), such as Model Name, Brand Name, Part Number, Serial Number, Software Version, Hardware Version, Hardware Version, and Last Software Update.
