Installation, Testing,
Maintenance Manual
Unless otherwise noted, SP40S refers to the SP40S family, consisting of
the SP40S, SP40SE, SP40S-D and SP40SE-D.
Part Number P84714
Assembly Number A84715-001
Copyright 2014 Cooper Wheelock, dba Cooper Notification. All Rights Reserved.
Multi-Function Facility
Communication System
Operation and
Revision M
Revision C
SP40S
Advertisement
Table of Contents
Summary of Contents for Cooper Notification SP40S Series
- Page 1 Operation and Maintenance Manual Unless otherwise noted, SP40S refers to the SP40S family, consisting of the SP40S, SP40SE, SP40S-D and SP40SE-D. Part Number P84714 Revision M Assembly Number A84715-001 Revision C Copyright 2014 Cooper Wheelock, dba Cooper Notification. All Rights Reserved.
- Page 2 SP40S Multi-Function Facility Communications System, Revision M...
- Page 3 About Cooper Notification: Cooper Notification fulfills its mission of Helping People Take Action by providing high quality and advanced products and services for the life safety, communications, and security markets. Cooper Notification has served the needs of commercial, educational, industrial, health care, and government users for more than eighty-five years.
- Page 4 SP40S Multi-Function Communication System, Revision M...
-
Page 5: Table Of Contents
Table of Contents 1. Forward 1.1 Intended use ....................13 1.2 Design Change Disclaimer ................13 1.3 User Operation Assistance................13 1.4 Product Model Descriptions ................13 1.5 Typographical Notation Conventions ............. 13 2. Safety Precautions 2.1 Read This Manual ................... 15 2.2 Operational Safety .................. - Page 6 4.4.7 Installing Audio Input Connections ............. 43 4.4.8 Installing Digital Voice Initiating Connections ........43 4.4.9 Installing Ancillary Audio Input Connections ........43 4.4.10 Setting Adjustable Audio BGM Sources .......... 45 4.4.11 Installing Alarm, System Trouble, and AC Trouble Output Connections ..................
- Page 7 7.4 Qualified Personnel ..................63 8. Troubleshooting 8.1 Introduction ....................64 8.2 General ......................64 8.2.1 Procedure A ..................68 8.2.2 Procedure B ..................68 8.2.3 Procedure C ..................68 8.2.4 Procedure D ..................69 8.2.5 Procedure E ..................69 8.2.6 Procedure F ..................
- Page 8 SP40S Multi-Function Communication System, Revision M...
- Page 9 List of Figures Figure 1 Basic Capabilities of the SP40S Panel Figure 2 Layout of SP40S Panel Figure 3 SP40S User Interface Figure 4 SP40 Terminal Blocks Figure 5 SP40S Jumpers Figure 6 SP40S Switches Figure 7 Diagnostic LEDs/Fuses Figure 8 SP40S Potentiometers Figure 9 Grounding Screws and Grounding Standoff Locations Figure 10 Location of Field Wiring Connections Figure 11 SP40S Panel Mounting and Grounding/Conduit Location...
- Page 10 SP40S Multi-Function Communication System, Revision M...
- Page 11 List of Tables Table 1 SP40S Standard Features Table 2 SP40S User Interface Pushbuttons/Indicators SP40S(E)-D User interface Pushbuttons/Indicators Table 4 Terminal Block Connection Definitions Table 5 Digital Voice Message Tests Table 6 Audio Alarm Conditions and Results Table 7 Trouble Procedure Cross Reference SP40S Multi-Function Communication System, Revision M...
- Page 12 SP40S Multi-Function Communication System, Revision M...
-
Page 13: Forward
Cooper Notification assumes no responsibility for any errors that may appear in this manual. Cooper Notification will make every reasonable effort to ensure that this manual is up to date and corresponds with the shipped Cooper Notification SP40S Multi- Function Facility Communication System. - Page 14 Forward application, operation, installation, and testing is used at the sole risk of the user and Cooper Notification will not have any liability for such use. Certain information contained in this manual has been extracted from the NFPA 72 Manual and the Life Safety Code 101™ Manual.
-
Page 15: Safety Precautions
Safety Precautions Safety Precautions 2.1 Read This Manual 1. Cooper Notification recommends that, before performing any actions to specify, apply, install, maintain, and operationally test the SP40S Multi-Function Facility Communication System, personnel properly qualified in the application and use of life safety equipment read this manual carefully. -
Page 16: Expected Equipment Lifecycle
2.2.2 Periodic Testing 1. Cooper Notification recommends testing of the entire protective signaling system, including the SP40S Multi-Function Facility Communication System, all notification equipment, as well as all messages and their output channel, and priority assignment, at least twice each year, or more often as required by local, state and federal codes, regulations and laws, by qualified personnel. -
Page 17: Compliance With Applicable Codes, Regulations, Laws, Standards, And Guidelines
Safety Precautions Compliance with Applicable Codes, Regulations, Laws, Standards, and Guidelines Comply with all of the latest applicable codes, regulations, laws, standards, and guidelines. WARNING: ENSURE THAT FOR EMERGENCY, LIFE SAFETY APPLICATIONS USING THE SP40S MULTI-FUNCTION FACILITY COMMUNICATION SYSTEM, INSTALLATION, TESTING AND MAINTENANCE ALWAYS BE PERFORMED BY QUALIFIED PERSONNEL IN ACCORDANCE WITH ALL THE LATEST NATIONAL FIRE PROTECTION ASSOCIATION (NFPA), UNDERWRITER’S LABORATORY (UL), NATIONAL ELECTRIC CODE (NEC), OCCUPATIONAL... -
Page 18: Rf Interference
Before specifying, installing, operating, testing, maintaining, or servicing a system, carefully read the installation, operation, and testing manual for each piece of equipment and applicable codes. Additional copies of this manual may be obtained from: Cooper Notification 273 Branchport Ave. Long Branch, N.J. 07740 Tel: (800) 631-2148... -
Page 19: Overview
Auxiliary (AUX) input is active and/or Digital Voice message are played. (Each message can be programmed individually to activate the strobe circuitry.) Return allows pass-through for Cooper Notification synchronized One strobe NAC output section strobes, remote SP40S panels, additional strobe appliances, or EOLR. - Page 20 Overview Capable of playback and record (via 1/8” audio jack). Digital Voice Message Chip contains the recording program and memory for eight message sections. Memory in eight sections with corresponding inputs. A total of four minutes of messages. Each message is 30 seconds in duration.
-
Page 21: Enclosure And Configuration
Overview Audio NAC circuit wiring -- open and short conditions during standby AND active (Alarm and BGM) Ground Fault detection Strobe NAC circuit wiring -- open and short conditions PTT Microphone -- not installed or damaged Full supervision with on-board Amplifier -- operation diagnostics and trouble reporting Digital Voice Section... -
Page 22: User Interface
Overview MOTHERBOARD GROUNDING TERMINAL BLOCK AC W iring Wiring to Battery (NON-POWER (NON-POWER LIMITED) LIMITED) MUST BE ROUTED OUT BOTTOM LEFT OF ENCLOSURE USER INTERFACE Figure 2 Layout of SP40S Panel User Interface The User Interface of the SP40S Multi-Function Facility Communication System displays Table the basic status of the unit as well as allowing for a limited amount of user controls. -
Page 23: Basic Operation Of User Interface
Overview Table 2 SP40S User Interface Pushbuttons/Indicators Pushbutton or Indicator Description/Function Message 1 - 8 (there are 8 messages, 1 through 8) Button manually actives Messages 1- 8. Illuminated steady means contact closure is on a DV input. Illuminated blinking means DV is activated via button push. - Page 24 Overview located on each DV message PB. For the SP40S firmware, a flashing LED indicates that the PB activated a message, and a solid LED indicates that a CC activated a message. 3.5.2.2 Operation of the Digital Voice Messages with the SP40S-D firmware Each PB and CC for DV messages 1 through 6 are individual inputs each having their own 10-minute timer.
-
Page 25: Additional Drawings
Overview 3.5.2.3 Timeout State Other outputs may be affected when the system is in the timeout state. In the timeout state, the alarm active relay and LED will deactivate. If strobes are tied to a message, then the strobe output and LED will also deactivate. Additional Drawings Figure 4 SP40 Terminal Blocks SP40S Multi-Function Communications System... -
Page 26: Figure 5 Sp40S Jumpers
Overview J1 Audio JP4 Contact Output Select Closure Supervision 2 Wire/4 Wire Mode (For connection to Audio Boosters) J4 AUX IN JP5 DV Select Record J6 User J5 FACP Interface Display (for future use) Interface Connection Figure 5 SP40S Jumpers SP40S Multi-Function Communications System... -
Page 27: Figure 6 Sp40S Switches
Overview SW2 AC Trouble Settings Booster Connection Settings SW3 Strobe Activation Tone Types NAC/Contact Closure Select SW7 DV IN Supervision and Auxiliary SW5 Pretone/ Timeout Postone Enable SW9 Sync/ Nonsync Strobe Settings Figure 6 SP40S Switches SP40S Multi-Function Communications System... -
Page 28: Figure 7 Diagnostic Leds/Fuses
Overview D4 MIC PTT MIC Missing D1 Audio Circuit or Inoperable Open D3 DV D5 AMP Digital D6 SPB Amplifier Section Voice Section D2 Audio Circuit Supervision Open Trouble Short D8 Batteries Missing or Low (Red) Audio Peak/Overload D44 AUX IN, CC Open, RMX or Remote MIC... -
Page 29: Figure 8 Sp40S Potentiometers
Overview R40 Telephone Page Volume Control R92 Background Music Volume Control R93 Tone Control Treble R73 Digital Voice Volume R94 Tone Control Control Bass R81 Digital R100 AUX IN Voice Tone Volume Volume Control Control Figure 8 SP40S Potentiometers SP40S Multi-Function Communications System... -
Page 30: User Settings
Overview Figure 9 Grounding Screws and Grounding Standoff Locations These 8 parts must be installed and securely fastened. User Settings 3.7.1 Switch Descriptions SW2 (AC Trouble Settings, Booster Connection Settings) FUNCTION 10k EOLR supervision On For SPB Ext. AC Loss Sup. SUP Contacts 170 minute AC Loss Delay AC Loss Delay... - Page 31 Overview SW3 (Strobe Activation) FUNCTION DV1 Strobe STB on when DV1 active DV2 Strobe STB on when DV2 active DV3 Strobe STB on when DV3 active DV4 Strobe STB on when DV4 active DV5 Strobe STB on when DV5 active DV6 Strobe STB on when DV6 active DV7 Strobe...
-
Page 32: Jumper Descriptions
Overview SW6 (Initiation mode select for Aux IN) SETTING DESCRIPTION Contact Closure Mode for use with RMX or SPRM 8 to 33VDC NAC Input SW7 (DV IN Supervision and Auxiliary Timeout) FUNCTION DV MES 1 CC Supervision 10k EOLR supervision ON for IN1 DV MES 2 CC Supervision 10k EOLR supervision ON for IN2 DV MES 3 CC Supervision... -
Page 33: Led Descriptions
LED Descriptions Head Description Additional Audio Output Open ON = Audio Output is open or missing EOLR Audio Output Short ON = Audio Output is shorted DV, Digital Voice Section ON = DV Audio is low or DV is damaged ON = MIC missing or inoperable;... -
Page 34: Installation
Installation Installation Introduction Remember, the lives of people depend upon the safe and proper installation of the voice evacuation system and the SP40S Multi-Function Facility Communication System. Please read, understand, and follow the specific installation instructions set forth in this chapter carefully to avoid damage to the panel and equipment connected to it. -
Page 35: General Installation Instructions
Installation General Installation Instructions For a view of the location of wiring connections used in the installation of the SP40S Multi- Function Facility Communication System, refer to Figure 10. Table 4 explains the functions of the different wiring connections. Section 2 System Trouble Connections Section 1 Alarm Connections... -
Page 36: Table 4 Terminal Block Connection Definitions
Installation Table 4 Terminal Block Connection Definitions Terminal Definitions Symbol Alarm Connections Block Alarm Connections Alarm Form C relay changes state in Audio Alarm Conditions. These conditions are: Push-to-talk Button on MIC depressed. AUX initiated via Alarm connections CC or NAC, and IN1- IN8 inputs present. Contacts are rated at 24VDC, 2A. - Page 37 Installation Auxiliary Input and 24VDC Output Connections (For Connection To SPRM or SP4-RMX) Auxiliary Input Audio Line Level Audio Input, Remote MIC, or SP4-RMX Priority 2. Contact closure or NAC will initiate AUX IN Audio. CC is supervised. Terminal CC/NAC Contact Closure/NAC Connects to RMX or Remote MIC (CC Mode).
-
Page 38: Preparing The System Wiring Diagram
1. Check the exterior of the shipping container(s) for any exterior damage, then the interior of the container(s). 2. Notify both the carrier and Cooper Notification immediately on the straight bill of lading (supplied by the carrier) if any damage is found both verbally and in writing;... -
Page 39: Figure 11 Sp40S Panel Mounting And Grounding/Conduit Location
Installation 2" - 2 1/2" - 3" Conduit Knockouts (2 Places) 3/4" - 1" Conduit Knockouts (18 Places) 14.00" 17.00" Grounding Terminal Block Figure 11 SP40S Panel Mounting and Grounding/Conduit Location CAUTION: Use care when punching out knock-outs to avoid damage to internal components. -
Page 40: Installing Field Wiring Connections
Installation Wire Distance Chart For 25V Speaker Line in feet Watts 12 AWG 14 AWG 16 AWG 18 AWG 2179 1374 1090 Wire Distance Chart For 70V Speaker Line in feet 12 AWG 14 AWG 16 AWG 18 AWG Watts 17087 10775 6780... -
Page 41: Installing Strobe Connections
The Strobe Appliance Circuit consists of a NAC (8 to 33VDC) input and supervised NAC (regulated 27VDC) output. The strobe output provides a synchronized output for compatible Cooper Notification, synchronized strobes. When a synchronized signal from a previous module is used, turn OFF SW9-position 1. This action also allows for pass-through of the synchronized NAC Circuit on the RET connections. -
Page 42: Installing Audio Output Connections
Position 10 of SW3 in the ON position initiates the strobe circuit during an AUX activation. Position 2 (ON) of SW9 selects the Cooper Notification Sync Mode during an alarm strobe activation. 4.4.5 Installing Audio Output Connections 1. -
Page 43: Installing Auxiliary Circuit Connections
Installation 4.4.6 Installing Auxiliary Circuit Connections Refer to the Remote MIC or RMX Installation Manual for proper connections from 24V OUT, AUX IN, and CC/NAC to these products. All connections to these products are made from TB6. 4.4.7 Installing Audio Input Connections The SP40S panel has thirteen inputs. -
Page 44: Figure 16 Ancillary Audio Input Connections
Installation The Telephone Page input requires input from a Telephone Page Port. The Night Ring input requires a dry contact closure. The Background Music input requires a line level, 600 Ohm, 1Vrms signal. for TB5’s location. Figure 10 1. Connect Telephone Page Input (TEL) to TB5. See Figure 16 is an enlarged picture of the referred area. -
Page 45: Setting Adjustable Audio Bgm Sources
Installation 4.4.10 Setting Adjustable Audio BGM Sources NOTE: Use a good multi-meter that provides true RMS readings in the AC voltage scale and calculates the results through average sampling. Some multi-meters can select instant or average sampling readings. Always do this adjustment in the “averaging” mode. Most digital multi-meters use the average sampling method in the “AC Volts RMS”... -
Page 46: Wiring The System
Installation 4. Check the integrity of all field wiring. Confirm that the specified cable is installed, and that there is continuity between required points (no open circuits), with no unwanted shorts to other conductors, chassis, or earth ground. a) Verify that the field wiring complies with the instructions of this manual and the detailed wiring diagram prepared for this installation. -
Page 47: Field Wiring Connections
Installation WARNING: ROUTE ALL SP40S MULTI-FUNCTION FACILITY COMMUNICATION SYSTEM AUDIO WIRING AWAY FROM ANY HIGH VOLTAGE OR HIGH CURRENT WIRING (SUCH AS AC OR DC POWER WIRING, AUDIO POWER WIRING, AND MOTOR OR RELAY ACTUATION WIRING). FAILURE TO DO SO MAY CAUSE ELECTRICAL SHOCK, RESULTING IN SERIOUS INJURY OR DEATH TO YOU AND/OR OTHERS. -
Page 48: Speaker Notification Appliance Output Wiring
The output meets Class B supervision requirements for notification appliance circuits. To meet Class A requirements, a Cooper Notification splitter (SP4-A/B or SP4-APS) is required. For the audio output circuit, install a UL Listed 10K Ohm, ½ W EOLR installed across the last notification appliance. -
Page 49: Wiring The Alarm Output Contact
Installation UL LISTED 10K OHM, 1/2 W AUDIO END OF LINE RESISTOR Figure 19 Wiring Diagram for Audio Only Notification Appliance Output CAUTION: Do not loop wire under terminals. Break wire run to provide supervision of the connection. 4.5.7 Wiring the Alarm Output Contact The location of the Alarm Output Connections (TB1) is shown in Figure 10. -
Page 50: Wiring The System Trouble Connections
Installation 4.5.8 Wiring the System Trouble Connections The locations of the System Trouble (Trouble Status Output) Connections (TB2) are shown in Figure 10. A magnified view of this area on the motherboard is shown in Figure 21. Wire gauge selection of the system Trouble Status output contact wiring involves consideration of all factors including, wire length, maximum current capacity, and maximum voltage drop allowable. -
Page 51: Checkout Procedure
Installation 5. If applicable, connect the strobe circuit to TB12 STB OUT. Verify that the strobe circuit has a UL Listed 10K Ohm, ½ W EOLR. 6. If Strobe synchronization is to be defeated, turn OFF positions 1 and 2 of SW9 Strobe Synchronization Defeat. -
Page 52: Table 5 Digital Voice Message Tests
Installation 2. Test the strobe circuit associated with the first message by switching DIP switch SW3 (DV/Strobe Select), position 1 “ON.” The STB LED on the interface (Red) turns “ON.” If the strobe circuit is attached to TB11, strobes flash. 3. -
Page 53: Ground Fault Detection
Installation 4.6.2.5 E Night Ring Test Test Night Ring by shorting NR connection TB5 (Figure 16). The chime sound should be heard from the output speaker circuit. 4.6.2.6 F Telephone Page Test If the Telephone Page circuit is used, make a telephone page from the phone system. The page should be heard from the AUDIO OUT speaker circuit. -
Page 54: Storing Batteries
Installation The case and cover of the batteries are ABS plastic resin, which may suffer damage from these chemicals. DO NOT install batteries in a heavy vibration or shock location. ALWAYS wear insulated gloves when handling batteries. DO NOT use together batteries of different capacities, age, or manufacture. WARNING: DO NOT CRUSH, INCINERATE, OR DISMANTLE BATTERIES. -
Page 55: Installing Ac Power And Batteries
Installation 2. Calculate speaker output current by totaling all the speaker wattage settings. Multiply the sum by 0.040. The result is the current draw in Amps. 3. Add the strobe current, the speaker current, and auxiliary current together. The result is the total Alarm Current in Amps. -
Page 56: Installing Batteries
Installation AC Field Wiring (non-power limited) LINE, GROUND Grounding and NEUTRAL Terminal Block Thread wire out knockout on the left side of the enclosure. Figure 22 VAC Input Connection 4.9.2 Installing Batteries NOTE: Batteries are not supplied with the SP40S Multi-Function Facility Communication System and must be purchased separately. -
Page 57: Figure 24 Battery Alignment And Jumper Connection
Installation Figure 24 3. Refer to and place one 12 Volt battery with the battery terminals on top and to the right. Place the second battery to the right of the first battery with the battery terminals on top and to the left. CAUTION: Always install the two batteries with the battery terminals pointing to the center and in the upright position as shown in Figure 24. -
Page 58: Operation
Operation Operation Introduction This chapter describes the operating characteristics of the SP40S Multi-Function Facility Communication System. Included is information about the following panel features: Supervision Audio Notification Appliance Output Circuit Supervision Amplifier Supervision Actions that Initiate Alarms User Interface The User Interface on the SP40S displays the basic status of the unit as well as providing a limited number of user controls. -
Page 59: Visual Notification Appliance Output Circuit Supervision
Operation WARNING: MESSAGES REQUESTED BEFORE AND DURING A TROUBLE CONDITION MAY NOT BE HEARD, WHICH COULD RESULT IN SERIOUS INJURY OR DEATH TO YOU AND/OR OTHERS. IF MESSAGES REQUESTED BEFORE AND DURING A TROUBLE CONDITION ARE STILL NECESSARY, REPEAT THEM WHEN THE SP40S PANEL IS RETURNED TO NORMAL. 5.3.1 Visual Notification Appliance Output Circuit Supervision The Visual Notification Appliance Output Circuit uses Class B, Style Y wiring, and is supervised for open and short circuits when the output is de-energized. -
Page 60: Operating Procedures
Operating Procedures Operating Procedures Making Live Announcements 1. Hold the on board or remote microphone within 2 inches from your mouth, press the Push-To-Talk (PTT) switch and begin speaking. (For best results, hold the microphone within a half inch from your mouth.) 2. -
Page 61: Recording Messages On The Digital Voice Section
Recording Messages on the Digital Voice Section CAUTION: Recording of any new message permanently erases the previous message. If a Cooper Notification factory prerecorded fire or emergency message or a tailored message is accidentally or intentionally erased, a new factory recorded message kit must be purchased to restore the message. -
Page 62: Verifying Messages
Operating Procedures Verifying Messages NOTE: Verify that DIP switch JP5 is in place. See Figure 5 for location. Message 1 Message 2 Message 3 Message 4 Message 5 Message 6 Message 7 Message 8 Figure 25 SP40S User Interface 1. Press the button of the desired DV message. The message will begin playback and the corresponding DV message LED will blink (LED will be steady with model SP40S(E)-D). -
Page 63: Periodic Testing And Maintenance
Periodic Testing and Maintenance Periodic Testing and Maintenance Introduction Conduct periodic testing and maintenance of the panel and all notification equipment frequently as required. Check local, state and federal codes, regulations and laws, for required tests. Make sure that only qualified personnel perform all tests and maintenance. Periodic Testing 7.2.1 Test Frequency Perform mandatory testing of equipment at least twice each year, or more often as... -
Page 64: Troubleshooting
Troubleshooting Troubleshooting Introduction WARNING: SOME ELECTRONIC COMPONENTS STORE A HIGH VOLTAGE CHARGE, EVEN THOUGH POWER IS NOT CONNECTED, AND CAN CAUSE A DANGEROUS SHOCK IF TOUCHED. DO NOT TOUCH EXPOSED CIRCUITRY ON THE SP40S MULTI-FUNCTION FACILITY COMMUNICATION SYSTEM UNLESS THE CIRCUITRY HAS DISCHARGED FOR ONE HOUR AND A SAFE DISCHARGE PROCEDURE IS USED. - Page 65 Troubleshooting System status is indicated to the visual indicators on the user interface, the internal Trouble Sounder, and the Trouble and AC Trouble Form "C" relay contacts. If the AC (primary power) is removed or low, the trouble the panel responds as follows: ...
-
Page 66: Table 7 Trouble Procedure Cross Reference
Troubleshooting Table 7 Trouble Procedure Cross Reference Troubleshooting Condition Trouble Description Procedure D109 (POWER ON LED) AC and Battery power are missing or Low Section 8.2.1 (A) is OFF D96 AND D97 are ON Strobe Over current Protection is active Section 8.2.2 (B) D8 (BAT) is ON Battery voltage is below 20.4 VDC or battery is missing... -
Page 67: Figure 26 Trouble Led And Fuse Locations
Troubleshooting D4 MIC PTT MIC Missing D1 Audio Circuit or Inoperable Open D3 DV D5 AMP Digital D6 SPB Amplifier Section Voice Section D2 Audio Circuit Supervision Open Trouble Short D8 Batteries Missing or Low (Red) Audio Peak/Overload D44 AUX IN, CC Open, RMX or Remote MIC... -
Page 68: Procedure A
Troubleshooting 8.2.1 Procedure A If the green PWR LED is “OFF” and all other LEDs are “OFF,” a power loss condition has occurred. A power loss condition may be caused by: Loss of AC input voltage and battery back-up voltage. ... -
Page 69: Procedure D
Troubleshooting 3. With the batteries NOT connected to the SP40S measure the series voltage of the batteries. If the battery voltage is below 18.5VDC allow the SP40S more time to charge the batteries. 4. With the batteries NOT connected, check for 24VDC at (+, -) BAT connection at TB10 on the motherboard. -
Page 70: Procedure F
Troubleshooting 8.2.6 Procedure F If the green PWR LED is “ON,” the yellow SYSTEM TROUBLE LED is “ON,”D4 MIC LED is “ON” steadily, the push-to-talk microphone is missing, improperly plugged in, or defective. Perform the following: 1. Install the microphone. 2. -
Page 71: Procedure I
Troubleshooting 8.2.9 Procedure I If the green PWR LED is “ON,” the yellow SYSTEM TROUBLE LED is “ON,” and D97 STB OPEN LED is “ON,” an open condition exists on the STB OUT NAC output circuit. A STB OPEN trouble condition might be caused by: ... -
Page 72: Procedure L
Troubleshooting 8.2.12 Procedure L If the green PWR LED is “ON,” the yellow SYSTEM TROUBLE LED is “ON,” and D1 AUDIO OPEN LED is “ON,” an open condition exists on the STB OUT NAC output circuit. A STB OPEN trouble condition might be caused by: ... -
Page 73: Procedure O
Troubleshooting 8.2.15 Procedure O If the green PWR LED is "ON," the yellow SYSTEM TROUBLE LED is "ON," and D6 EXT AC WIR is "ON," an open condition exists on the SPB SUP terminals (TB4). This trouble can be caused by: ... -
Page 74: Procedure R
Troubleshooting 8.2.18 Procedure R If the green PWR LED is "ON," the yellow SYSTEM TROUBLE LED is "ON," and D93 BATT CHG TRB LED is "ON," a battery charger trouble has occurred. NOTE: The CHG TRB LED turns ON during an AC TROUBLE. Restoring the AC Voltage turns OFF the CHG TRB LED. -
Page 75: Technical Data
Mounting Indoor surface mount Top, left, right, and bottom knockouts (3/4”-1”) (18 total) Wiring Top (2” - 2 ½” - 3”) (2 total) Entry Door Lock Standard Cooper Notification key-lock 1 Motherboard PC Boards 1Keypad board Environmental Parameter Description Operating Temperature 0 to 49 °C (32 to 120 °F) -
Page 76: Outputs
Technical Data Method of Activation Description Strobe NAC 8-33VDC Push-to-Talk Microphone Connected to Mother Board Auxiliary Input Remote Microphone or RMX Initiation Contact Closure. Activates Message 1 on Digital Voice Section. Contact Closure. Activates Message 2 on Digital Voice Section. Contact Closure. -
Page 77: Wiring Connections
Technical Data Wiring Connections Parameter Description Accepts #12 to #18 AWG for single wire Screw terminals connection, or #16 to #18 AWG for double wire connection. 9.4.1 End of Line Resistor (EOLR) Parameter Description Accepts #12 to #18 AWG for single wire Screw terminals connection, or #16 to #18 AWG for double wire connection. -
Page 78: Warranty
Warranty LIMITED WARRANTY Cooper Wheelock, Inc. dba Cooper Notification and Cooper Notification, Inc. (each, a “Seller”) products must be used within their published specifications and must be PROPERLY specified, applied, installed, operated, maintained and operationally tested in accordance with these instructions at the time of installation and at least twice a year or more often and in accordance with local, state and federal codes, regulations and laws. -
Page 79: Battery Backup Calculation Worksheet
Battery Backup Calculation Worksheet Battery Backup Calculation Worksheet SP40S BATTERY CALCULATION SHEET STANDBY CURRENT CALCULATIONS 1. The Standby Current for the SP40S is 0.130 Amps. ______________Amps 2. Enter Auxiliary Current (If Applicable) ______________Amps 3. Add Steps 1 and 2. Multiply by the number of hours required. 24 Hours –... -
Page 80: Compatible Signaling Appliances
Compatible Signaling Appliances Compatible Signaling Appliances The following Cooper Notification products are LISTED compatible with the audio notification appliance output and the visual notification output circuits for the SP40S Panel. When connected to the SPB-80/4, strobe synchronization is system-wide. All strobe products can be fully synchronized. - Page 81 Compatible Signaling Appliances SP40S Multi-Function Communications System...
