GENERAL NOTES 1.1 PERMITTED USE The touch screen remote control panel allows the centralized management of a network of chiller/heat pump. It can also be used for partial functions (i.e. as a remote control panel of a single chiller/heat pump or ambient temperature thermostat). It includes humidity and temperature sensors for the thermo hygrometric analysis of the environment and for the management of the double set point for radiant floor heating systems that use a dehumidification system. -
Page 5: Input/Output Resources (I/O)
Touch Screen 2 Input/Output RESOURCES (I/O) 2.1 TOUCH SCREEN PCB 2.1.1 LAYOUT Figure 1. Layout 2.1.2 TOUCH-SCREEN USE The interface has a resistive touch-screen LCD with sensitive areas applied to the contextual content of the active screen. It allows you to select items or perform functions with ease. Do not exert too much pressure on the touch screen with your fingers and do not use a sharp object on the touch screen. -
Page 6: Connections
Touch Screen 2.3 CONNECTIONS Open the control applying a slight pressure in the lower and upper parts of the devise in order to separate the rear cover from the front one. Pass the cables through the hole in the rear over and make connections according to the following guidelines. Terminals 1 and 2: 12 V AC power connect supply (terminal on chiller 12V- e 12V+). -
Page 7: User Interface
Touch Screen 3 USER INTERFACE The touch-screen can be used in the following ways: • Interface panel (unit interface) for a single heat pump • Chillers/heat pumps network network manager Manager of Chiller/heat pump and fan coil units network • •... -
Page 8: Home Page
Touch Screen 3.4 HOME PAGE The home page has the following appearance: Figure 5. Home page – indication meanings From the home page it is possible to access to the different device’s screens, simply touching the displayed resource. The sensible areas (indicated in the image by red boxes) inside this page are: 1. -
Page 9: Chiller Screen/Heat Pump
Touch Screen Figure 6. Home screen – only chiller is networked Figure 7. Chiller/Heat Pump Referring to the above figure, it is possible to obtain the following information: • presence of chillers that are connected in the network (the chiller is correctly accepted when touching its figure you can access to the pages dedicated to itself);... - Page 10 Touch Screen Figure 10. Chiller page – information and sensitive areas The information in the chiller’s page are: 1. Temperature detected by chillers (for a specific chiller): a. Air temperature (°C) b. Inlet water temperature (°C) c. Outlet water temperature (°C) 2.
- Page 11 Touch Screen Figure 11. Insert chiller name The name of the chiller can have a maximum of 13 characters. 3.4.1.2 CHILLER AREA The area 5 shown in Figure 10 gives indications about the operation (compressor running) of the chiller, graphically displaying the fan rotation Press on the area 5 to get access to a further screen from which you can read the list of the real time data corresponding to the interested chiller such as:...
- Page 12 Touch Screen 3.4.1.3 TOOLBAR CHILLER AREA On the left scroll sidebar there are icons that symbolize the active/activable functions in the chiller taken into account. In particular: Colourful icon = function enabled, Lock icon = function configured on the machine but not currently active. Below there is a table with icons that may appear in the scroll side bar.
-
Page 13: Fancoil Page
Touch Screen 3.4.2 FANCOIL PAGE From the main page, by touching the fancoil symbol (sensitive area number (3), Figure 5), you can access at the fancoils screen page in the network. From this page of fancoils, you can display all information refeering to the operation of the individual fan coils, identified by the belonging’s area and the identification number of each fancoil. -
Page 14: Touch Screen Area
Touch Screen Figure 13. Fan speed configuration The four slectable levels of speed: • Minimum fan speed • Medium fan speed • Maximum fan speed • Automatic fan speed (auto-mode) To set the speed, use the up and down arrows buttons, and then press the green button to confirm the selected speed. -
Page 15: Second Main Page
Touch Screen Figure 14. Ethernet network configuration page On this page there are the addresses for the configuration of an Ethernet connection. A parameter is present to also assign the connection port (parameter 65, port 80 default). Logging in with maintainer/manufacturer permission, you can change the default addresses. It’s implemented a local web server to access to the Touch Screen from local area network with a HTML 4.01 compatible browser (see Paragraph 5.2). -
Page 16: Home System
Touch Screen 3.6 HOME SYSTEM From the second page, touching the arrow icon to navigate to the next screen, you go to a third screen for general settings, the "system main page", showing the following functional icons: Figure 16. System main page Above, from the left to right: 1) STATUS SETUP;... -
Page 17: Programs Page (Chronothermostat)
Touch Screen From this screen you can set the chiller’s parameters and also configurate the fancoil zones. If enabled, you can also set the sanitary hot water setpoint (see Paragraph 4.7.3) and for rapid DHW preparator, the second set-point (see Paragraph 4.10) and the offset for the climatic compensation (see Paragraph 4.11). - Page 18 Touch Screen 3.6.5.1 USER MENU – KEYBOARD SETUP To access the user menu you have to set the user password (modifiable): 0. From here you can: • Set the date and the hour by pressing on “Clock” key (it appears on the screen shown in Figure 22); •...
-
Page 19: Help Page
Touch Screen To change the value of a parameter: • Enter in Parameter List, use the up and down arrows to scroll through the pages of the parameters, until you find the desired parameter; • press on the currently set value; •... -
Page 20: Machines Status And Functions
Touch Screen MACHINES STATUS AND FUNCTIONS 4.1 NEWTORK MANAGEMENT A network managed by the remote control Touch Screen can be composed of a maximum of 7 chiller/heat pumps and a maximum of 80 fancoil units. For what concerns the configuration of the network, you have the following functions as indicated below: •... -
Page 21: Chiller/Heat Pumps Management
Touch Screen intervention of the chillers change, by rotating the decalibration of the set point of the chillers, in order to balance the load on the various machines. If a chiller is in alarm, it is excluded from the regulation. By default Par 8/65=0. 4.3 CHILLER/HEAT PUMPS MANAGEMENT Up to 7 chiller HP_OWER series can operate by mean of the Touch Screen remote control panel. -
Page 22: Assignment Of The Fancoils To The Zones And Zone Name Customization
Touch Screen In the case of disconnection from the network of one or more fan coils that were correctly addressed and detected (for example in case fancoils’ power supply failure), the centralized remote controller proceeds with updating the number of fancoils actually in operation in the system with a delay of 2 minutes from the occurrence of the failure, after update, an error message will be displayed. -
Page 23: On/Off Sanitary Mode
Touch Screen After getting access to "Status Setting" and pressing on "ZoneN" it is possible to control differently each individual zone (for example, the control of zone 1 is not a sufficient condition for starting up the chiller if it is already in off mode): ZONEn PROGRAMED MANUAL... -
Page 24: Setting Of The Set-Point
Touch Screen 5. If the status of the system is set to "Summer and san" or "Winter and san", the priority is given on the production of domestic hot water; therefore the system goes first in domestic hot water production, when the sanitary is satisfied, the system switches the mode to summer or winter operation. -
Page 25: Programs Setup (Chronothermostat)
Touch Screen DOUBLE SET-POINT CHILLER SANITARY WINTER SUMMER Water set Water set eco Water set 2 Water set eco 2 Water set Water set eco Water set 2 Water set eco 2 Sanitary set Change the value of the set with the up and down arrows within the maximum and minimum limits indicated and confirm 4.7.4 PROGRAMS SETUP (CHRONOTHERMOSTAT) The chronothermostat programming takes place separately from chillers and fancoil terminal units: so it is necessary to program... - Page 26 Touch Screen Figure 24. Chronothermostat, "Summer Chiller" page 1. Scheduling of a day time-line: press on the day currently displayed to move to the next days and select a day; • choose if you want to set the way of operation in normal mode (press "Normal"), or Economy (press "Eco"), or if you want •...
- Page 27 Touch Screen The chronothermostat (configuration page) colourful time-lines shows: the blue time-line indicating normal operation, the green time-line indicating the economical operation, the red time-line indicating the time in which the legionella cycle is programmed (thus the machine in that condition may be active even if the scheduler is set to Off). 4.7.4.2 WEEKLY PROGRAM SANITARY WATER PRODUCTION In a similar way to what is reported for the settings on the chronothermostat of chillers and fan coils, you can define when to enable the production of sanitary hot water (by setting the individual days of the week, with a minimum step of 15 minutes).
-
Page 28: Ambient Thermostat
Touch Screen Figure 27. Chronothermostat, "Legionella disinfection" page The set timeline appears red-colored. The pink line shows the eventual setting of the previous day that overruns in current day because the duration exceeds the midnight. It is necessary to enable the electric heaters in sanitary integration, by setting the parameter R15 = 1. OPERATION: •... -
Page 29: Keyboard Settings Procedure
Touch Screen The call of the ambient thermostat is disabled when the temperature detected by the Touch Screen thermostat is greater than the zone setpoint, and the heat pump is in standby mode. Figure 30. Second main page On the individual fancoil screen, the displayed temperature is the one given by the temperature sensor of the fancoil unit (HNSbox) and not the one used for temperature regulation. -
Page 30: Diagnostic Errors
Touch Screen 4.9 DIAGNOSTIC ERRORS 4.9.1 ACTIVE ALARMS You can display the current alarms of the connected units. To do this, from the home page, press the triangle icon of danger, if present; from here you can access to the list of all active alarms in the system. Also, when you are in an unit page (i.e. -
Page 31: Dew Point Temperature
Touch Screen With double set-point function enabled, if the chiller works on the second set-point (radiant panels side), the double set-point icon appears in the toolbar of the functions in the pages of chillers and fan coils and it remains transparent. If, however, the chiller switch to thermoregulate on the first set-point (fan coil side), the double set-point icon appears colourful. -
Page 32: Climatic Compensation
Touch Screen Given the environmental temperature and the humidity, the Touch Screen remote control calculates the dew point. In operation of the plant in summer mode, with the double set-point function active on chillers and thermoregulation normally made with the radiant panels (second set of work), it activates a control to keep the dew point of at least a quantity defined by the keyboard maintainer parameter Par42/65: "Dew-point temp. -
Page 33: Secondary Circulator
Touch Screen 4.12 SECONDARY CIRCULATOR It allows the management of a secondar or re-launching circulator to serve the plant. The following functions should be active: • Secondary circulator management function, see the related paragraph in the user’s-installer’s manual of the unit; •... -
Page 34: Password And Protections
Touch Screen 4.15 PASSWORD AND PROTECTIONS There are more protection and password levels. An initial distinction includes the following three access levels: User’s level Service level Manufacturer’s level To each of these three different levels you can access from the “Configuration” screen, previously inserting a dedicated password. The user’s password, default set to “0”, can be modified by accessing to user’s parameters (see Paragraph 3.6.5.1). - Page 35 Touch Screen Figure 37. Touch Screen Ethernet main page The indications on Status, Season and Alarms are those of the entire system. The room temperature and the relative humidity are the ones measured from the sensors integrated inside the current Touch Screen.
- Page 36 Touch Screen Figure 39. Command sent confirmation page Figure 40. Touch Screen Ethernet "Set-point” page In the “Set-point” page are available, in read only mode, the set-point set by Touch Screen. The set-points set for the winter season (water set-point, economy water set-point and, if enabled, double set-point, second water set-point and second water economy set-point appear) under "Winter".
-
Page 37: Firmware Update
Touch Screen Figure 41. Touch Screen Ethernet “Alarms” page The “Alarms” page is related to all the active alarms inside the system at the moment when the page is shown. 6 FIRMWARE UPDATE In the home page, by pressing on the symbol in the left-high side, showing Hi-T, it is possible to see the current firmware version installed in the touch-screen. -
Page 38: "Touch Screen" Control Panel Configuration Parameters
Touch Screen “TOUCH SCREEN” CONTROL PANEL CONFIGURATION PARAMETERS The maintainer parameters of the chillers are reported in the control manual of HP_OWER units. The maintainer parameters of the remote control panel are listed below: MINIMUM MAXIMUM DEFAULT MEASUREMENT N° PARAMETER VALUE VALUE VALUE... - Page 39 Touch Screen MEASUREMENT MINIMUM MAXIMUM DEFAULT N° PARAMETER VALUE VALUE VALUE UNIT Regulation temperature in zone 1 “Winter” 0 = Average temp. of the fancoils of the zone 1 = Minimum temp. of the fancoils of the zone 2 = Maximum temp. of the fancoils of the zone 3 = Temperature measured by the “Touch Screen”...
- Page 40 Touch Screen MEASUREMENT MINIMUM MAXIMUM DEFAULT N° PARAMETER VALUE VALUE VALUE UNIT Regulation temperature in zone 9 “Winter” 0 = Average temp. of the fancoils of the zone 1 = Minimum temp. of the fancoils of the zone 2 = Maximum temp. of the fancoils of the zone 3 = Temperature measured by the “Touch Screen”...
- Page 41 Touch Screen MEASUREMENT MINIMUM MAXIMUM DEFAULT N° PARAMETER VALUE VALUE VALUE UNIT Regulation temperature in zone 8 “Summer” 0 = Average temp. of the fancoils of the zone 1 = Minimum temp. of the fancoils of the zone 2 = Maximum temp. of the fancoils of the zone 3 = Temperature measured by the “Touch Screen”...
