Assembly & OperAting instructiOns
mOdel: 900034495 (4 Burner Flat Top BBQ) Vpn: MG104FT
AGA
approval
No: 7771
Australian Gas Association
impOrtAnt! reAd these instructiOns cArefully befOre use
FOR YOUR SAFETY
1. Do not store or use any flammable vapours or liquids in the vicinity of this or any other appliance.
2. A disconnected LPG cylinder shall not be stored in the vicinity of this or any other appliance.
IF YOU SmEll GAS:
1. Turn off all gas valves.
2. Extinguish any remaining open flames.
3. If the odour of gas remains, immediately contact your gas supplier for further advice.
WARNING
• For outdoor use only.
• Improper installation, adjustment, alteration, service or maintenance can cause property
damage, injury or death. Read the installation, operating and maintenance instructions
thoroughly before installing or servicing this appliance.
• Warning: Accessible parts may be very hot. Keep young children away at all times.
• Do not move the appliance during use.
• Turn off the gas supply at the gas cylinder after use.
• DO NOT modify this appliance.
• Installer to leave instructions with the consumer and consumer to retain them for future reference.
FOR OUTDOOR USE ONLY
This Appliance is designed for use with UNIVERSAL LPG
Certification No: AGA 7771
MFG Model ID: MG104FT
MG104FT-2014-06-18-V3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 900034495 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mitre10 900034495

  • Page 1 Assembly & OperAting instructiOns mOdel: 900034495 (4 Burner Flat Top BBQ) Vpn: MG104FT FOR OUTDOOR USE ONLY approval No: 7771 Australian Gas Association impOrtAnt! reAd these instructiOns cArefully befOre use This Appliance is designed for use with UNIVERSAL LPG Certification No: AGA 7771...

  • Page 2: Important Safety Instructions

    impOrtAnt sAfety instructiOns 1. This appliance is for OUTDOOR USE ONlY. Under no circumstances is it to be used indoors. 2. Read all operating instructions and familiarise yourself with the appliance before operating. 3. Do not perform any servicing on this appliance yourself. Servicing must only be conducted by a suitably qualified and authorised technician.

  • Page 3: Outdoor Areas

    OutdOOr AreAs Figure F1 - Outdoor Area - Example 1 30 percent or more in total Open side at least of the remaining wall area 25% of total wall area is open and unrestricted Figure F4 - Outdoor Area - Example 4 Figure F2 - Outdoor Area - Example 2 Both ends open Open side at least...

  • Page 4: General Information

    generAl infOrmAtiOn • Minimum size LPG cylinder size - 4kg (POL Valve). • Strong winds and low ambient temperatures will affect the heating performance of the appliance. You should consider these factors during use, it is part of cooking outdoors. • Never use your appliance in a garage, porch, breezeway or any other similar enclosed area.

  • Page 5: Parts List

    PARTS lIST NOTE: To assemble this appliance you will require a minimum of a medium size Phillips head screw driver and a 200mm adjustable wrench. pArt # descriptiOn pArt # descriptiOn Lid Handle Cast Iron Grate Hose and Regulator Assy Lid Bracket Bolt Pack Cast Iron Plate...
  • Page 6 cOnstructiOn Step 1: Assemble leg, lower shelf and wheels M6x4PCS M8x2PCS M10x6PCS M8x2PCS Step 2: Fasten serving shelves, cylinder hook & appliance chassis M6x10x2PCS M6x85x9PCS M6x60x4PCS M6x4PCS Spacersx8PCS Step 3: Lid Assembly M6x12x2PCS M6x10x2PCS M6x2PCS...
  • Page 7 Step 4: Final Assembly Step 5: Completed.

  • Page 8: Usage Instructions

    usAge instructiOns Gas Connections All gas connections must be tested before each use for leaks using a soapy water solution. With the gas cylinder turned on and the appliance controls off, sponge soapy water onto the gas connection and look for a stream of bubbles.

  • Page 9: After Cooking

    The temperature of the appliance is set by adjusting the controls. Each control adjusts the burner immediately behind it. There are safety detents at the ‘OFF’ and ‘HIGH’ positions to stop accidentally rotating a control and placing the appliance in a condition that maybe hazardous. To rotate the control from OFF to ‘HIGH’ you must depress the knob and hold it depressed while you move the control from the ‘OFF’...
  • Page 10 stOrAge Do not store the appliance until it has completely cooled. • Storage of the appliance in doors is permissible only if the gas cylinder has been disconnected, removed from the appliance and remains outdoors. • Store the appliance in a cool dry location. • Always disconnect the gas cylinder and store it in a safe suitable location away from naked flames and sources of ignition.
  • Page 11 12 months from the date of purchase. 3. In order to claim under this warranty you will need to bring the product to any MITRE10 (New Zealand) store, along with proof of purchase (typically this will be a receipt). Any cost incurred by you in bringing the product to the service desk will be borne by you.
