Eco PS-673W Instruction Manual

WORKS WITH
amazon alexa
Indoor
Wi-Fi Surge Protector
INSTRUCTION GUIDE
Rating: 120 Vac, 60 Hz, 15A
SETUP INSTRUCTION
CAUTION! INDOOR USE ONLY! Do not use Wi-Fi Surge Protector
! !
in outdoors, damp, or wet locations.
READ ALL INSTRUCTIONS before using the Wi-Fi Surge Protector.
RECOMMENDATION: The closer the Wi-Fi Surge Protector is
located to a WiFi router during set-up, the better the signal strength
will be for initial configuration and subsequent programming.
Mac address: If your router identifies by Mac address, please
key in the code number shown in the code label of the unit.
i.e., 3x:2x:7x:0x:Cx:Cx
Grounded/Protected
Indicators
PROTECTED
GROUNDED
Wi-Fi ™ Status Indicator
BLINKING LIGHT
LIGHT
Wi-Fi Surge Protector
is ready for programming
FAST BLINKING LIGHT
Wi-Fi Surge Protector
cannot find a WiFi router.
Please reset.
SOLID LIGHT:
Programming is finished and
the Wi-Fi Surge Protector is
now ready to be used via ECO
Plugs APP
NO LIGHT:
Wi-Fi Surge Protector is
rebooting to default settings
RESET THE Wi-Fi SURGE PROTECTOR
This is how you perform a factory reset of the Wi-Fi Surge Protector
1
STEP
Turn on the power Switch at side.
blinking
OFF
3
STEP
While holding the power button,
plug the Wi-Fi Plug into a 120Vac
wall outlet, THEN release the power
button when the light turns off.
DOWNLOAD THE ECO PLUGS APP:
You can download the ECO Plugs App from either the Apple
APP Store (iPhone) or the Google Play Store (Android)
Scan the QR Codes below or search for 'ECO Plugs'
CIRCUIT BREAKER SWITCH
Manually turns ALL
receptacles ON/OFF
POWER BUTTON
Press this button to turn the
controlled outlets on and off
(iOS 7 or higher)
RESET:
*If you purchase more than
Also used to reset the Wi-Fi
Surge Protector device (see .
by one
instructions below)
STEP 1
Receptacles For controlled
devices(4) (Will only be
controlled via ECO Plugs app
as a group. CANNOT be
controlled individually)
Constantly ON Powered
Receptacles–Not WiFi
Controlled (2)
Plug with wall outlet
then turn on the
power Switch at side.
2
STEP
Press and hold the power button
blinking
4
STEP
Finished! You can now start
setting up the ECO Plugs APP with
the Wi-Fi Plug
SMARTPHONE SETUP
ECO Plugs
(Version 4 or higher)
, setup each device
one ECO Surge Protector
STEP 2
Your phone Your phone
Tap the
Wi-Fi/WLAN icon
Wi-Fi/WLAN on
Setting
! Go into your phone's setting
(Normally is as gear icon symbol first.)
STEP 3
Your phone Your phone
Select the
ECO-XXXXXXXX
Wi-Fi
ECO-XXXXXXXX
abcde
Xyz95
ECO-XXXXXXXX
Xyz95
xrgtg4
xrgtg4
Home
Home
Select the ECO Plugs # (ECO-XXXXXXXX)
!
which labelled on the product.
STEP 5
Select Wi-Fi Network
Device [ECO-XXXXXXXX]
Home Router
Other Router A
Other Router B
Select the Wi-Fi home router that
you want to connect to the ECO
Wi-Fi Plug or tap ( )
(EX: Home Router)
*If this ECO-XXX network does not show in your list, perform a factory
RESET of the
Wi-Fi Plug
*If your router does not show up in the list, press the
manually enter your router's information
STEP 7
EX: USA
USA Canada Other
Enter Zip Code: 2142 (Cambridge)
Name Device: (Named This Device)
Wi-Fi Router(WLAN):
Home Router
Enter Wi-Fi Router Password:
(Wi-Fi's password, if needed)
/
Join Save Setting
Zip Code (USA Only)
Fill in Country,
Phone Area Code (CANADA Only)
one
Name Device (Lamp, TV, small appliances) and Router Password, click the
SAVE SETTING or JOIN button.
* iOS: If you can't find the Join button, please click in the password section.
*For Canada: Please select the Canada, entering the phone area code
instead of zip code.
*Your smartphone should reconnect to your home router. If it does
not, go back into your phone WiFi settings to connect back to it.
STEP 4
Your phone
ECO Plugs
Tap the
ECO Plugs APP
STEP 6
USA Canada Other
Enter Zip Code:
Name Device:
(Named This Device)
Wi-Fi Router(WLAN):
Home Router
Enter Wi-Fi Router Password:
(Wi-Fi's password, if needed)
Fill in all your information.
icon to
EX: CANADA
USA Canada Other
Phone Area Code:
416 (Toronto)
Name Device:
(Named This Device)
Wi-Fi Router(WLAN):
Home Router
Enter Wi-Fi Router Password:
(Wi-Fi's password, if needed)
