PALLET FORK
CLASS II & CLASS III
(LAF1137 Shown)
SERIAL NUMBER: ___________________
Manual Number: MR45503
Models: LAF1108, LAF1135,
MODEL NUMBER: ___________________
LAF 1136, LAF1137, LAF1138,
LAF1163, LAF1172, LAF1173,
LAF1175 and LAF1197;
10021, 10022 and 10047.
Date: April 10, 2006
800-747-2132 I www.paladinbrands.com
100 East Lee Road, Lee, IL 60530, United States of America
Advertisement
Table of Contents
Summary of Contents for FFC LAF1108
- Page 1 PALLET FORK CLASS II & CLASS III (LAF1137 Shown) SERIAL NUMBER: ___________________ Manual Number: MR45503 Models: LAF1108, LAF1135, MODEL NUMBER: ___________________ LAF 1136, LAF1137, LAF1138, LAF1163, LAF1172, LAF1173, LAF1175 and LAF1197; 10021, 10022 and 10047. Date: April 10, 2006 800-747-2132 I www.paladinbrands.com...
-
Page 3: Table Of Contents
FFC at the telephone number or address listed on the cover of this manual. -
Page 4: Owner And Operator Safety Information
Translations of this manual into other languages are available by submitting an order to FFC. The best safety device is a careful operator. FFC and your dealer ask that YOU be that careful, responsible equipment operator. -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS WORK SAFELY - A CAREFUL OPERATOR IS THE BEST INSURANCE AGAINST ACCIDENTS !! SECTION 1 WARNING Use the right tool for the job at hand. Obey all the safety instructions listed in Make sure that your tools are in good condition this section and throughout this manual. - Page 6 Do not roll back this product so far that the load falls original products that were designed by your loader / off toward or on the operator. quick-attach manufacturer. If this product does not fit properly, contact FFC WHEN ADJUSTING, SERVICING OR REPAIRING before operating. THIS PRODUCT: Never place your finger into the mounting plate or Make no modifications to your Pallet Fork.
-
Page 7: Safety Signs
Replacement parts for parts with safety signs attached must also have safety signs attached. Safety signs are available, free of charge, from your dealer or from FFC. (LAF1137 Shown) PLACEMENT OR REPLACEMENT OF SAFETY SIGNS 1. Clean the area of application with non-flammable solvent, and then wash the same area with soap and water. -
Page 8: Power Unit Specifications, Mounting
POWER UNIT SPECIFICATIONS IMPORTANT Exceeding any of the maximum recommended power unit specifications CAN result in damage to this product and WILL void all FFC warranties. DESCRIPTION SPECIFICATIONS Lift Capacity of Power Unit’s loader 3,000 3,750 5,500 10,000 lbs. maximum... -
Page 9: Operation
IMPORTANT Lifting a load heavier than the ALLOWABLE LOAD or centered farther than 24” out on the fork teeth CAN result in damage to this product and WILL void all FFC warranties. -
Page 10: Maintenance
Using a fork tooth or teeth to pry on any object CAN result in damage to this product and WILL void all FFC warranties. POSITIONING THE LOAD 1. Approach the load so that the weight will be centered between the fork teeth. If the load has a heavy side, then that side should be closest to the main back plate rather than near the tips of the fork teeth. -
Page 11: Parts Illustration
PARTS ILLUSTRATION LAF1163 (or similar) ONLY (LAF1137 Shown) -
Page 12: Parts List, Specifications
LAF1173 LAF1175 LAF9464 LAF1113 LAF1153 LAF1164 Main Backplate See List Below for Fork part numbers. Fork Tooth Weldment: Includes Contact FFC to obtain the correct item. Latch Assembly Not Used Not Used Not Used LAF9949 Step Not Used Not Used... -
Page 13: Warranty
NOTE! Make one copy each for the dealer’s and owner’s records. Mail original to FFC Attachments. Form MR00000-000 Rev. 09/04 FFC Attachments • 100 E. Lee Road • PO Box 122 • Lee, IL 60530 • 800-747-2132 • Fax 815-824-2071 www.ffcattachments.com... - Page 14 Our obligation under the warranty is expressly limited, at our option, to the replacement or repair at FFC, of Lee, Illinois, or at a service facility designated by us, or such part or parts as inspection shall disclosed to have been defective. We are not responsible for unauthorized repairs or replacements.
