Shearwell SDL 400S Operating Manual

Stick reader

Table of Contents

Download this manual

Light ring

The s ck reader comes with four AA rechargeable ba eries. Standard AA ba eries can also be used.

Inser ng ba eries

Note: You will not lose your data when you remove the ba ery pack.

1. Open the s ck reader by unscrewing the end of the red or blue handle. Use the white loop to pull out

the ba ery pack.

2. Insert the ba eries into the holder ensuring the posi ve and nega ve markings (+ / -) on the ba er-

ies match up with the (+ / -) on the holder.

3. Insert the ba ery pack with the green arrow and green circle facing the same direc on as the green

bu on on the reader. Ensure that the ba ery pack is aligned with the grooves inside the s ck

reader.

4. Replace the end of the reader by screwing the cap on. Warning: Do not over- ghten the ba ery cap

as this could damage the thread.

Stick Reader

SDL 400S & 440S

OPERATING GUIDE

LCD screen

Ba ery pack

Shearwell label

Blue light

Green bu on

Handle

End cap for

ba ery access

Version 19.03.2019

Table of Contents

Need help?

Do you have a question about the SDL 400S and is the answer not in the manual?

Page 1 Stick Reader Stick Reader SDL 400S & 440S SDL 400S & 440S OPERATING GUIDE Light ring Light ring Shearwell label LCD screen Blue light Blue light Ba ery pack Green bu on End cap for Handle ba ery access The s ck reader comes with four AA rechargeable ba eries. Standard AA ba eries can also be used.
Page 2 Battery information Check the ba ery level The ba ery level indicator shows very brieﬂ y on the start-up screen when the s ck reader is turned on. To check the level of the ba eries when the s ck reader is turned on, ﬁ rst turn it oﬀ , then turn it back on to see the start-up screen.
Page 3 Menu options The menu is a list of op ons for changing the way the s ck reader func ons. 1. Turn oﬀ the s ck reader by holding down the green bu on. 2. With the s ck reader oﬀ , press and hold down the green bu on. Con nue holding down the green bu on to view all the menu op ons.
Page 4 SDL440 (blue handled s ck) links to iPhone or Android devices. » Mobile apps are free to download from the Shearwell website www.shearwell.co.nz Look for a label on the back of your s ck reader that shows its Bluetooth name, Bluetooth number and the serial number.

Sdl 440s
