Summary of Contents for FriCARE STP01001
- Page 1 FriCARE Dual Head Stethoscope Instructions & Lifetime Warranty...
- Page 2 Did you locate the correct heart’ s position? Check the Dual Head Chestpiece FriCARE dual head chestpiece enables you to switch the active sound chan- nel from the diaphragm side to the bell side or vice versa, which is flexible to listen to high and low frequency sound for auscultating adult patients.
- Page 3 The stem can be rotated in either clockwise or counterclockwise directions. Rotate the stem can achieve the change of diaphragm and bell easily. If the Indicator dot is oriented on the same side as the diaphragm, the dia- phragm is active for auscultation. To switch to the bell side of the chestpiece, Index (rotate) the chestpiece 180º...
- Page 4 Put your two ear pieces, and it should point out like your nose. If it’ s pointed toward you, that means it is the wrong direction. (Fig.4) If this is reversed, it will affect the sound quality of the patient. And this ensures that the eartubes will align with your ear canals for comfort and maximum sound transmission.
- Page 5 Where to place the stethoscope Aortic area: Pulmonic area: Systolic murmur Systolic ejection murmur Tricuspid area: Holosystolic murmur Diastolic murmur Mitral area(apex): Holosystolic murmur Systolic murmur Diastolic murmur Sometimes a patient's heart is under a lot of fat or tissue or is surrounded by fluid.
- Page 6 Adjusting the Binaural Tension To adjust the spring tension of the binaural headset for a more comfortable fit, securely grasp both of the metal binaural tubes and either extend the tubes fully apart to reduce the tension or squeeze them together until they fully overlap to increase the tension.
-
Page 7: Care And Maintenance
Wipe with 60% - 70% isopropyl alcohol solution. Check the video if you are not sure about the instructions mention above: https://www.fricare.com/pages/stethoscope-instruction-video Get Your lifetime Warranty We stand by the quality of our product by offering a basic 5 year warranty. - Page 8 Contact us at support@fricare.com to get the support your need and win the chance for new product test and giveaways.
