Page 1 YL-200PB Automatic Time Printing Bill Binder User Manual...
Page 2: Table Of Contents
Contents 1. For your safety 2. Product Introduction and package details 3. Part name and function 4. Installing and removing of Tape. 5. How to control the temperature 6. How to control the length 7. How to bind and print 8.
Page 3: For Your Safety
For your safety For your safety Please carefully read this user manual before operating the machine. Maintenance requirements 1. Make sure AC 220V power is supplied. The voltage fluctuation must be kept at a minimum. 2. High temperature, high humidity or any other environmental conditions may render the unit not operational due to the tape being jammed around the roller or otherwise.
Page 4: Product Introduction And Package Details
Product Introduction and package details Automatic Time Printing Bill Binder (YL-200PB) *Multi Systems -It is able to bind cash at the same time print the time of when it was bound. *Multi Tasking Function -It is not always clarified that the user would want to print the date, therefore this model is given two modes where: 1.
Page 5: Part Name And Function
Part name and function [ Print part ] 1. Name of button power select down save 2. Display Mode a, Time Display Mode b, Distance Setting up Mode c, Time Setting up Mode d, Serial number setting up Mode a. Time Display Mode *Turn the power on at first the mode is Time Display Mode.
Page 6 c. Time Setting up Mode *Press Select button to set up Min-Time-Sec-Month-Year in regular sequence with Up or Down button at Time Display Mode. *Press Save button to save the Min-Time-Sec-Month-Year d. Serial number Change Mode *Turn Off and then turn On the power pressing Select button at the same time.
Page 7: Installing And Removing Of Tape
Installing and removing of Tape a. Open the front plate. The toggle switch can change the mode between "inserting tape mode" and "strapping mode". If the switch is in the upper position, it is "inserting tape mode" and the lamp of the power switch will start blinking. Put tape in the tape holder. Make sure paper tape will unroll in the right direction.
Page 8: How To Control The Length
How to control the length Use the length control volume to adjust the length of tape Short Long How to bind and print [Preparations] 1. Connect the power cable to the power inlet. (the fuse hold and power switch are integrated). 2.
Page 9: How To Change Ink Cartridge
How to change ink cartridge *Open the up case. *Up the A and B like a picture then ink cartridge will come out. *Insert the ribbon of new ink cartridge between C and D and then press ink cartridge to A and B. Checking before troubleshooting Follow as below if there is operation trouble or machine cannot operate 1) Turn on the power switch and then check if the power/re-set button(red) and start/backward...
Page 10: Product Specifications
Power consumption Plate Heater type paper 30,40mm Tape width 324 (W) × 210 (D) × 500 (H) mm Products size 24kg Weight Use of the tape supplied by BINDTEC CO., LTD is recommended to maintain optimal performance of the binder.
Page 11: Product Warranty
Product warranty BINDTEC CO., LTD warrants that we will repair and replace parts in accordance with the following terms if any “defects in the material or workmanship of the machine occurs within 12 months from the day on which the user purchases it”.
