Tripp Lite DMWC3770M Owner's Manual

Corner wall mount for flat or curved screens
Hide thumbs Also See for DMWC3770M:

Advertisement

Quick Links

Download this manual
Owner's Manual
Corner Wall Mount
Curved Screens
Este manual esta disponible en español en la página de Tripp Lite:
Ce manuel est disponible en français sur le site Web de Tripp Lite :
Русскоязычная версия настоящего руководства представлена на
веб-сайте компании Tripp Lite по адресу: www.tripplite.com
Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website
Register your product for quicker service and ultimate peace of mind.
You could also win an ISOBAR6ULTRA surge protector—a $100 value!
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
19-02-089-93391F-EN.indd 1
for Flat or
Model: DMWC3770M
200x200 / 300x200
300x300 / 400x200
400x300 / 400x400
600x400
www.tripplite.com
www.tripplite.com
verfügbar: www.tripplite.com
PROTECT YOUR INVESTMENT!
www.tripplite.com/warranty
Copyright © 2019 Tripp Lite. All rights reserved.
1
70"
99 lb.
MAX
(45 kg)
2/27/2019 2:41:51 PM

Advertisement

loading
Need help?

Need help?

Do you have a question about the DMWC3770M and is the answer not in the manual?

Questions and answers

Related Manuals for Tripp Lite DMWC3770M

Summary of Contents for Tripp Lite DMWC3770M

  • Page 1 600x400 Este manual esta disponible en español en la página de Tripp Lite: www.tripplite.com Ce manuel est disponible en français sur le site Web de Tripp Lite : www.tripplite.com Русскоязычная версия настоящего руководства представлена на веб-сайте компании Tripp Lite по адресу: www.tripplite.com Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar: www.tripplite.com...

  • Page 2: Warranty And Product Registration

    FREE Tripp Lite product!* * No purchase necessary. Void where prohibited. Some restrictions apply. See website for details. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Photos and illustrations may differ slightly from actual products.

  • Page 3: Component Checklist

    Component Checklist IMPORTANT: Ensure you have received all parts according to the component checklist prior to installing. If any parts are missing or faulty, visit www.tripplite.com/support for service. (x2) (x2) (x2) (x4) (x4) (x1) (x1) Package M M5x14 (x4) M6x14 (x4) M6x30 (x4) M8x30 (x4) M8x50 (x4)
  • Page 4 Assembly Mount on Wood Stud Wall 55 mm (2.2") O / 4.5 mm (O / 3/16") Find and mark the exact location of mounting holes W-A W-C Drill pilot holes Screw the assembled wall plate to the wall WARNING • Make sure the mounting screws are anchored into the center of the studs. Use of a stud finder is highly recommended.
  • Page 5 Assembly Mount on Solid Brick and Concrete Block 60 mm (2.4") O / 10 mm (O / 3/8") Find and mark the exact location of mounting holes W-A W-C Drill pilot holes Screw the assembled wall plate to the wall WARNING •...
  • Page 6 Assembly 23.6 in. (600 mm) 15.75 in. (400 mm) 11.8 in. (300 mm) 7.9 in. (200 mm) 19-02-089-93391F-EN.indd 6 2/27/2019 2:41:55 PM...
  • Page 7 Assembly For Flat Back Screens Note: Choose appropriate screws and washers according to the type of screen. • Position the adapter brackets as close as possible to the center of the display. • Firmly secure the adapter brackets onto the display using the screws and any other necessary hardware components included with the unit.
  • Page 8 Assembly For Recessed Back Screen or to Access A/V Inputs Note: Choose appropriate screws, washers and spacers (if necessary) according to the type of screen. • Position the adapter brackets as close as possible to the center of the display. •...
  • Page 9 Assembly Using an assistant or mechanical lifting equipment, hook the display with attached adapter brackets over the top of the wall-mount bracket. Tighten the bolt on the bottom of the wall- mount bracket to secure the unit. 19-02-089-93391F-EN.indd 9 2/27/2019 2:41:57 PM...
  • Page 10 Assembly 180° +5° –5° +5° –5° 19-02-089-93391F-EN.indd 10 2/27/2019 2:41:59 PM...

  • Page 11: Maintenance

    Maintenance • Check that the bracket is secure and safe to use at regular intervals (at least every three months). • Please visit www.tripplite.com/support if you have any questions. 19-02-089-93391F-EN.indd 11 2/27/2019 2:41:59 PM...
  • Page 12 1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support 19-02-089 93-391F_RevA 19-02-089-93391F-EN.indd 12 2/27/2019 2:41:59 PM...
