TCP 570 GU Series Installation Instructions

57000WPCGU
Outdoor Wall Fixture with
White Finish and Prismatic Diffuser
7.4"
10"
WARNINGS AND CAUTIONS
WARNING
• Shut off power at
the circuit breaker
or fuse panel
before removing
the old fixture.
This TCP product is warranted for a period of two years from date of original purchase against defects in
materials and workmanship. If this product should fail to operate due to defects in materials or workmanship,
simply return this product to the place of purchase or call TCP service center at 1-800-324-1496, along with
the original sales receipt within two years of purchase. This product will be repaired or replaced, at TCP's
option. This warranty is expressly limited to repair or replacement of the product. This warranty gives the
consumer specific legal rights, which vary from state to state. Light bulbs are not covered under this warranty.
WARRANTY IS VOID IF PRODUCT IS NOT USED FOR THE PURPOSE FOR WHICH THIS PRODUCT IS
MANUFACTURED.
TCP, Inc.
325 Campus Dr. | Aurora, Ohio 44202 | www.tcpi.com | Customer Service: 800.771.9335
©TCP, Inc. 2008/02630a
570 S eri es G U W al l Pac k F ixture s
Hardware Kit
Height-10.0"
Width-7.4"
Depth-4.4"
CAUTION
• DO NOT USE THIS FIXTURE WITH A DIMMING CIRCUIT.
If you presently have dimmer controls, you will need to
remove them, and replace them with regular electrical
swithces. If you have a three way dimmer, you will have
to replace it with a regular three way switch. If you are
unfamiliar with electrical installations, we recommend
you have a qualified electrician do your installation.
LIMITED WARRANTY
57000BPCGU
Outdoor Wall Fixture with
Black Finish and Prismatic Diffuser
10"
GU24 Lamp
Installation Instructions
7.4"
Hardware Kit
Height-10.0"
Width-7.4"
Depth-4.4"
CARE AND MAINTENANCE
Your fixture is made from quality
materials that will last for many, many
years with minimum care. You may want
to periodically clean the fixture using a
mild, non-abrasive glass cleaner and
soft cloth. Do NOT use solvents or
cleaners containing abrasive agents.
When cleaning the fixture, make sure
you have the power turned off and do
not spray liquid cleaner directly onto the
bulb, socket, ballast, or wiring.
