Thank you for purchasing our Copy Adapter CPAD-C1A.
• This product is designed to copy function codes and their data, which are stored in
the FRENIC-Mini series of inverters and to write them into other inverters. Read
through this instruction manual and be familiar with the handling procedure for
correct use.
• Improper handling might result in incorrect operation, a short life, or even a failure
of this product as well as the motor.
• Deliver this manual to the end user of the product. Keep this manual in a safe
place until the Copy Adapter is discarded.
• For the usage of inverters and optional equipment, refer to the instruction manuals
prepared for the FRENIC-Mini series of inverters and its optional equipment.
Fuji Electric Systems Co., Ltd.
Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com
Copy Adapter "CPAD-C1A"
Copy Adapter "CPAD-C1A"
Instruction Manual
n Manual
INR-SI47-0886a-EU Rev 052010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRENIC Mini CPAD-C1A and is the answer not in the manual?

Questions and answers

Related Manuals for Fuji Electric FRENIC Mini CPAD-C1A

Summary of Contents for Fuji Electric FRENIC Mini CPAD-C1A

  • Page 1 • For the usage of inverters and optional equipment, refer to the instruction manuals prepared for the FRENIC-Mini series of inverters and its optional equipment. Fuji Electric Systems Co., Ltd. INR-SI47-0886a-EU Rev 052010 Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
  • Page 2 All rights reserved. No part of this publication may be reproduced or copied without prior written permission from Fuji Electric Systems Co., Ltd. All products and company names mentioned in this manual are trademarks or registered trademarks of their respective holders.

  • Page 3: Preface

    Preface Thank you for purchasing our Copy Adapter "CPAD-C1A." The Copy Adapter can copy and set function codes and their data stored in FRENIC-Mini series of inverters into other ones while the inverters are in a stop state. Connecting the Copy Adapter to the connector provided for an RS485 communications card (option) on the inverter allows you to copy (by reading data in the inverters and writing them into other ones), set, and monitor function codes and their data.
  • Page 4 Connection and cabling/wiring of the copy adapter • Do not handle the inverter and/or the cable connector with wet hands. Doing so could cause electric shock. • Before connecting the copy adapter’s cable connector, first turn off the inverter, wait more than 5 minutes, and make sure that the DC link bus voltage between the terminals P (+) and N (-) has dropped below the safe voltage level (+25 VDC), using a multimeter.

  • Page 5: Table Of Contents

    How this manual is organized This manual is made up of chapters 1 through 5. Chapter 1. BEFORE USING THE COPY ADAPTER This chapter describes the points to check upon delivery and lists the inverter models, which the copy adapter is designed to interface with. Chapter 2.

  • Page 6: Copy Adapter

    Figure 1.1. If you suspect the product is not working properly or if you have any questions about your product, contact your Fuji Electric representative. Figure 1.1 Back of Copy Adapter CPAD-C1A * Type of inverter ...

  • Page 7: Chapter 2 Connection And Removal

    Chapter 2 CONNECTION AND REMOVAL This chapter guide you how to connect and remove the copy adapter to/from the inverter. Connection • Before connecting the Copy Adapter’s cable connector, first turn off the inverter, wait more than 5 minutes, and make sure that the DC link bus voltage between the terminals P (+) and N (-) has dropped below the safe voltage level (+25 VDC), using a multimeter.

  • Page 8: Removal

    (2) Connect the cable connector of the copy adapter to connector CN3 on the inverter, with the arrow mark facing up as shown below. Figure 2.2 Connecting the Cable Connector Turn on the inverter power. 2.2 Removal • Before removing the Copy Adapter’s cable connector, first turn off the power of inverter, wait more than 5 minutes, and make sure, using a circuit tester or a similar instrument, that the DC link bus voltage between the terminals P (+) and N (-) has dropped below a safe voltage (+25 VDC).
  • Page 9 (1) Power off the inverter. (2) Check that the DC link bus voltage between the terminals P(+) and N(-) lowers below the safe level (+25 VDC). (3) Remove the cable connector from CN3. To remove the cable connector, pinch its outside between your fingers and pull it towards you.

  • Page 10: Chapter 3 Operation Using The Copy Adapter

    Chapter 3 OPERATION USING THE COPY ADAPTER 3.1 Familiarizing Yourself with the Copy Adapter The copy adapter is composed of a 4-digit, 7-segment LED monitor, an LED block consisting of 5 LEDs, and 7-segment LED monitor 6 keys as shown in Figure 3.1. indicators PROGRAM STOP key...

  • Page 11: Functions Of The Copy Adapter

    3.2 Functions of the Copy Adapter The copy adapter has the following functions. Table 3.3 Functions and Operations of Copy Adapter Function Description Remarks Run/Stop These functions are disabled in the copy adapter. Pressing the key or key sets the set frequency and PID process command, and also sets the Set up timer.
  • Page 12 Display on LED Function Description Monitor Verify Verifies (collates) the data stored in the memory of the copy adapter with the function code data held in the inverter. ueri data When a discrepancy is detected, the verify operation will be aborted, with the function code in disagreement Function code displayed blinking.
  • Page 13 *Also during the copy and ueri operations, the function name and the function code data block number appear alternately. Figure 3.3 Status Transition during Selecting of Function Code Data Block Number asic key operation If the ROM version of your inverter is “CIS10900” or earlier, set function code E52 to "2: Full menu mode" before using the copy adapter. Turn the inverter on.
  • Page 14 • The function codes stored in the copy adapter are not compatible with those stored in the inverter. Non-standard function code data may have been stored, or the inverter may have been upgraded in an incompatible manner. Consult your Fuji Electric representative.

  • Page 15: Periodical Replacement Parts4-1

    Table 4.1 below lists its recommended service life for your reference. Ten pieces of the connector adapters (CPAD-C1-CN) come with the product for periodical replacement. When you become to need more connector adapters (CPAD-C1-CN), consult your Fuji Electric representative.

  • Page 16: Reassembling

    (2) Remove the connector adapter along the arrow shown in Figure 4.3. Pinch the connector between your fingers to remove the connector adapter. Do not so with gripping the cable sheath. Doing so may damage the cable. Figure 4.3 Removing the Connector Adapter 4.2.2 Reassembling (1) Place the attached connector adapter with the connector end.

  • Page 17: Inquiries About Product And Guarantee

    4.3 Inquiries about Product and Guarantee (1) When making an inquiry Upon breakage of the product, uncertainties, failure or inquiries, report the following information to your Fuji Electric representative. 1) Copy adapter type 2) SER No. (serial number of equipment) (Refer to Section 1.1 in this manual.)

  • Page 18: Chapter 5

    Chapter 5 SPECIFICATIONS 5.1 General Specifications Table 5.1 summarizes the general specifications of the Copy Adapter "CPAD-C1A." Table 5.1 General Specifications Item Specifications Remarks Environment Inverter is idle. No. of connectable unit One per inverter Max. cable length Connection to an inverter Cable connector For 10 function code data blocks Data storage space...
  • Page 19 Please feel free to send your comments regarding any errors or omissions you may have found, or any suggestions you may have for generally improving the manual. In no event will Fuji Electric FA Components & Systems Co., Ltd. be liable for any direct or indirect damages resulting from the application of the information in this manual.
  • Page 20 MEMO Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
  • Page 21 Fuji Electric Systems Co., Ltd. Fuji Electric Corp. of America Information subject to change without notice. Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
