Summary of Contents for Amazing Roller Shutters SE14.21 CP 970
- Page 1 Wolf n en Installation Instructions SE 14.21-25,40 ER CP970 115VAC 1PH Date: 21.10.2013 Version: 1.1 SE115V 1PH...
- Page 2 SAFETY DIRECTIONS Basic Directions This control has been built in accordance with EN 12453 Industrial, commercial and garage doors and gates - Safety in use of power operated doors - Requirements and EN 12978 Industrial, commercial and garage doors and gates - Safety devices for power operated doors - Requirements and Test methods;...
-
Page 3: Table Of Contents
TABLE OF CONTENTS PAGE TECHNICAL SPECIFICATIONS …………………………………………………………. 4 MECHANICAL INSTALLATION .................. 5 LIMIT AND MOTOR CONNECTION................6 ELECTRICAL CONNECTIONS ……………………………………......7 SETTING THE LIMITS....................8 ..................9 WIRING THE ACCESSORIES PROGRAMMING THE UNIT .……………..............10 OPERATING STATUS DISPLAY .……............... 13 MANUAL OPERATION . -
Page 4: Technical Specifications
TECHNICAL DATA SE14.21 CP 970 Output torque Output speed Output shaft / hollow shaft 25,40 / 1 mm/inch Maximum holding torque Maximum door weight 6000 Supply voltage 115V 1PH Secondary Supply 24VDC, max load 150mA Operating current AMPS Operating frequency... -
Page 5: Mechanical Installation
1. MECHANICAL INSTALLATION OF SE14.21 OPERATOR & PANEL A. Prerequisites The permissible loads on walls, fastenings, mountings and transmission elements must not be exceeded. For maximum holding torques or locking torques refer to technical data. Fasteners: Self-locking fasteners with a Utilize the hole diameter to the Use adequately dimensioned minimum strength of 800 N/mm... -
Page 6: Limit And Motor Connection
2. VERIFY ELECTRICAL CONNECTION OF LIMIT SWITCH AND MOTOR 1. Remove limit cover 2. Verify limit switch plug is in 3. Verify limit jumpers are in place. BAHAC07_Z001 4. Remove motor cover 5. Verify wiring of motor cables. Note After verifying proper connections re-instal limit and motor cover. Elec trical i nstallati on Danger ... -
Page 7: Electrical Connections
3. ELECTRICAL CONNECTIONS Confirm Primary Voltage Confirm power cord is wired Plug into dedicated 15AMP outlet within 3’ of control panel properly Motor cable connection to Fit cable through the provided Wire motor cables into CP 970 operator & control panel overview strain relief panel Limit cable connection to... -
Page 8: Setting The Limits
4. SETTING THE LIMITS Warning First check motor rotation Turn power ON. The door must open when the OPEN push button is operated. If the door closes, 3 and 1 of control panel must be exchanged with the power off. See hardware overview on page 15. -
Page 9: Wiring The Accessories
5. WIRING THE ACCESSORIES The following wiring diagrams are for recommended and optional accessories. A. Safety Photocell B. Safety Edge It is recommended to install a normally closed contact It is recommended to install a normally closed photocell to the CP 970. If not used Jumper 6.1 & 6.2. contact Safety Edge to the CP 970. -
Page 10: Programming The Unit
6. PROGRAMMING THE UNIT 1. Entering programming mode 2. Choose program and Open enclosure lid confirm Press & Hold selector switch for 3 Turn selector AND Press & seconds until display = Hold selector switch for 3 seconds 3. Adjustment 4. - Page 11 2. Choose program and 3. Adjustment 4. Set confirm Control Functions Do not use Do not adjust Do not use Do not adjust Automatic closing Time can be set between 1-240 sec. feature Press Ex. 1-6.2 = 162 sec. stop button Do not use Do not adjust...
- Page 12 Display appears “CS“ and adjusted Reaction when reaching 0 number of cycles Changing to DEADMAN display appears “CS“ and adjusted number of cycles Changing to DEADMAN same as 0.2 reset to about 500 cycles possible,press stop button for 3 seconds 2.
-
Page 13: Operating Status Display
8. OPERATING STATUS DISPLAY Report Description Measure to solve the problem Missing jumper Insure jumper is in 2.1 & 2.2 on CP970 Missing jumper Insure jumper is in 21 through 26 on DES Limit Emergency stop activated Check the emergency stop is activated, or whether the supply cable is broken Missing jumper Insure jumper is in 2.1 &... -
Page 14: Manual Operation
OPERATING STATUS DISPLAY Report Command Acknowledgements Open command being given Stop command being given Close command being given Cycles for maintenance reached Report Status Flashing Opening Flashing Closing Door stopped between set limits Door stopped at upper limit Door stopped at lower limit Note ... - Page 15 Supply 24VDC Max 500mA Resistor – Do not remove 2.1 & 2.2 Push button - If not used Jumper 5.1 & 5.2 Photocell or Safety edge N.C. – If not used Jumper 6.1 & 6.2 Radio control N.O. 7.1 & 7.2 Jumper –...
-
Page 16: Wiring Diagram Overview
12. ACCESSORIES WIRING DIAGRAM... -
Page 17: Operator And Panel Parts Breakdown
D eclar ati on of inc or por ation / c onfor mance 13. OPERATOR AND PANEL PARTS BREAKDOWN CONTROL PANEL PART DESCRIPTION 1. ENCLOSURE 2. CP970 CONTROLLER 3. CONTACTOR 24VAC 4. FUSE HOLDER 5. FUSE – 2 AMP 6. TRANSFORMER 115V-24VAC 7.
