Summary of Contents for Xtrails ADPRO 49841000
- Page 1 ADPRO Network I/O Units For ADPRO NVR+ Technical Manual March 2018 Doc. 33355_00...
- Page 3 ADPRO Network I/O Units – Technical Manual Disclaimer The contents of this document are provided on an "as is" basis. No representation or warranty (either express or implied) is made as to the completeness, accuracy or reliability of the contents of this document. The manufacturer reserves the right to change designs or specifications without obligation and without further notice. Except as otherwise provided, all warranties, express or implied, including without limitation any implied warranties of merchantability and fitness for a particular purpose are expressly excluded. Intellectual Property and Copyright This document includes registered and unregistered trademarks. All trademarks displayed are the trademarks of their respective owners. Your use of this document does not constitute or create a license or any other right to use the name and/or trademark and/or label. This document is subject to copyright owned by Xtralis. You agree not to copy, communicate to the public, adapt, distribute, transfer, sell, modify, or publish any contents of this document without the express prior written consent of Xtralis. Trade Name Statement Xtralis, the Xtralis logo, The Sooner You Know, VESDA-E, VESDA, ICAM, ECO, OSID, HeiTel, ADPRO, IntrusionTrace, LoiterTrace, ClientTrace, SmokeTrace, XOa, XOh, iTrace, iCommand, iRespond, iCommission, iPIR, and FMST are trademarks and/or registered trademarks of Xtralis and/or its subsidiaries in the United States and/or other countries. Other brand names mentioned herein are for identification purposes only and may be trademarks of their respective holder(s). General Warning This product must only be installed, configured and used strictly in accordance with the General Terms and Conditions, User Manual and product documents available from Xtralis. All proper health and safety precautions must be taken during the installation, commissioning, and maintenance of the product. The system should not be connected to a power source until all the components have been installed. Proper safety precautions must be taken during tests and maintenance of the products when these are still connected to the power source. Failure to do so or tampering with the electronics inside the products can result in an electric shock causing injury or death and may cause equipment damage. Xtralis is not responsible and cannot be held accountable for any liability that may arise due to improper use of the equipment and/or failure to take proper precautions. Only persons trained through an Xtralis accredited training course can install, test and maintain the system. Liability You agree to install, configure, and use the products strictly in accordance with the User Manual and product documents available from Xtralis. Xtralis is not liable to you or any other person for incidental, indirect, or consequential loss, expense or damages of any kind including without limitation, loss of business, loss of profits, or loss of data arising out of your use of the products. Without limiting this general disclaimer the following specific warnings and disclaimers also apply: Fitness for Purpose You agree that you have been provided with a reasonable opportunity to appraise the products and have made your own independent assessment of the fitness ...
- Page 4 Network I/O Units – Technical Manual ADPRO Contact Us UK and Europe +44 1442 242 330 D-A-CH +49 431 23284 1 The Americas +1 781 740 2223 Middle East +962 6 588 5622 Asia +86 21 5240 0077 Australia and New Zealand +61 3 9936 7000 www.xtralis.com Environmental Information The crossed-out wheeled bin means that within the European Union the product must be taken to separate collection at the product end of life. This applies to the device but also to any accessories marked with this symbol. Do not dispose of these products as unsorted municipal waste. If you need more information on the collection, reuse, and recycling systems please contact your local waste administration. You can also contact us for more information on the environmental specifications of our products. 33355_00...
-
Page 5: Table Of Contents
ADPRO Network I/O Units – Technical Manual Contents About the Network I/O Units Features Requirements for Monitored Inputs Ordering Information Possible Configurations Identifying New Units Specifications – Base Unit Specifications – Extension Unit LED Indicators Installation Connections and Adjustments Replacing or Removing a Unit Setting the Base Unit IP Address Updating the Firmware Troubleshooting Firmware Updates Input Circuits Frequently Asked Questions 33355_00... - Page 6 Network I/O Units – Technical Manual ADPRO 33355_00...
-
Page 7: About The Network I/O Units
ADPRO Network I/O Units – Technical Manual About the Network I/O Units Note You can find the latest versions of this document and any referenced document on the Xtralis Security Solutions Support site www.xtralissecurity.com (logon may be required). If a document number is indicated (between parentheses), you can enter it in the Keywords box on the site, and search for the document. Features The Network (Net) I/O units are modules with LED indicators, contact inputs and relay outputs, controlled by an ADPRO NVR+ device. The Net I/O units are compatible with the following device types: ADPRO FastTrace 2 Series: FastTrace 2, FastTrace 2X, and FastTrace 2E ADPRO iFT Series: iFT and iFT-E ADPRO iFT Gateway ADPRO V3100 The host system controls the Net I/O units through the Ethernet network (10 Mbps network only). The base unit offers: 4 monitored or unmonitored inputs for voltage-free contacts. The possible states are: idle alarm tamper short circuit (monitored inputs only) tamper open circuit (monitored inputs only). ... -
Page 8: Requirements For Monitored Inputs
Network I/O Units – Technical Manual ADPRO As you can link your ADPRO NVR+ device to up to 8 units (8 base units, each with up to 3 extension units), you can obtain a total of 128 extra inputs and 128 extra outputs. Requirements for Monitored Inputs Monitored inputs are only available on the new Net I/O units. To use a Net I/O unit with monitored inputs, all the requirements listed below must be fulfilled: For a base unit: The base unit hardware must be version 2 (V2). The base unit firmware must be version 2 (V2). The ADPRO NVR+ device controlling the unit must be running firmware version XO 4.02 or above. For an extension unit: the extension unit hardware must be version 2 (V2). its base unit must fulfil the requirements as listed above. If any of the above requirements is not fulfilled, the units will function as the legacy units, with unmonitored inputs (only 2 states: idle/alarm). The new units are backwards compatible with the legacy units. For details on identifying new or legacy units, see Identifying New Units on page 9. For an overview of all possible combinations of new and legacy units, see Possible Configurations on page 9. Ordering Information Use these reference numbers to place your order with Xtralis: Item Reference number... -
Page 9: Possible Configurations
ADPRO Network I/O Units – Technical Manual Possible Configurations The table below provides an overview of all possible combinations of new and legacy units (base and extension), and the resulting possibilities for the inputs (monitored or unmonitored): Behaviour inputs on base Behaviour inputs on Base unit Extension unit unit extension unit Hardware V1 Unmonitored (2 states) Hardware V1 or V2 Unmonitored (2 states) Firmware V1 or V2 Hardware V2 Unmonitored (2 states) Hardware V1 or V2 Unmonitored (2 states) Firmware V1 Hardware V2 Firmware V2 Unmonitored (2 states) Hardware V1 or V2 Unmonitored (2 states) XO version < 4.02 Hardware V2 Monitored (4 states) -
Page 10: Specifications - Extension Unit
Network I/O Units – Technical Manual ADPRO Jumpers SW1: shorted temporarily to reset (internal use, default = open) SW2/SW4: default = open. LEDs D9: on = video system is powered D11: on = video system in error state D10: on = video system is currently recording D18: on = relay K1 activated D19: on = relay K2 activated D20: on = relay K3 activated D21: on = relay K4 activated Specifications – Extension Unit Power supply Powered by base unit Voltage 12 VDC ± 10 % Current 50 mA max. (all LEDs and relays activated) 10 mA (all relays off) Inputs 4 monitored or unmonitored inputs for voltage-free contacts: idle, alarm, tamper short circuit, tamper open circuit (tamper states only on monitored inputs) Outputs 4 switchover relay contacts: NC/C/NO, rated 30 VDC @ 1 A Dimensions... - Page 11 ADPRO Network I/O Units – Technical Manual Note The three system LEDs (power, fault, and recording) are on simultaneously when the unit's IP address is still at the default setting. 33355_00...
-
Page 12: Installation
Network I/O Units – Technical Manual ADPRO Installation Connections and Adjustments Caution! Before plugging or unplugging any extension units, switch off the power to the base unit. Plugging or unplugging extension units with power on may result in permanent and irreparable damage to the base and/or extension units. The table below provides an overview of the connectors. 33355_00... -
Page 13: Replacing Or Removing A Unit
ADPRO Network I/O Units – Technical Manual Connector Description IP (base unit only) Use an Ethernet cable to connect the base unit to the IP network, and (optionally) to power the unit over Ethernet (PoE). If using PoE, fix the included clamp on the Ethernet cable inside the mounting box. Place the clamp as close as possible to the Net I/O unit. 12V (base unit only) Optional: if you are using a local power adapter instead of PoE, connect the DC power wires to the 0V and + terminals. Respect the polarity! If using a local power adapter, fix the included clamp on the power supply input. Make one loop inside the clamp. IN 1–4 Inputs. Each input has its own GND (0V). The inputs function as monitored inputs (4 states), depending on hardware, firmware, and ADPRO NVR+ firmware version. For details, see Requirements for Monitored Inputs on page 8. OUT 1–4 Voltage-free switchover relay contact outputs. Each output has a common terminal (C) and a normal open (NO) and normal closed (NC) terminal. DIP1 (extension DIP switch to set the extension unit address from 0 to 2 (address 3 is not supported in units only) the ADPRO NVR+ software) as indicated in the table below. The switch for the most significant bit (MSB) is located away from the edge of the unit. Set switch To set address Other... -
Page 14: Setting The Base Unit Ip Address
Network I/O Units – Technical Manual ADPRO It may, for example, damage input/output 1 (relay permanently active) and send incorrect signals to the ADPRO NVR+ device. Proceed as follows before plugging or unplugging extension units: If the base unit is powered via a local power adapter: unplug the power adapter from the base unit. If the base unit is powered via PoE: unplug the network (Ethernet) cable from the base unit. After plugging or unplugging the extension units, plug the power adapter or network cable back in. Setting the Base Unit IP Address The default IP address of the base unit is 192.168.1.100 with subnet mask 255.255.255.0. The three system LEDs on the base unit will light up simultaneously if the unit is still set at the default address. The extension units do not have an IP address. You assign them an address (or sequence number) using the DIP switch on the unit. For details, see Connections and Adjustments on page 12. Use the NetFinder tool to locate all base units on your network and set their IP addresses. You can find the NetFinder tool on the DVD that comes with your ADPRO NVR+ device, or on the Xtralis Security site www.xtralissecurity.com. Caution! NetFinder will not detect units behind a router. Make sure that your PC and the units are in the same ... -
Page 15: Updating The Firmware
ADPRO Network I/O Units – Technical Manual 3. Click the desired unit, and then click Assign. 4. Type the IP address, the subnet mask and the gateway, and then click OK. The unit stores the settings in its flash memory. Updating the Firmware Use the NetFinder tool to update the firmware on a base unit. The unit will preserve its IP address, subnet mask, and gateway settings during an update. There is no firmware on the extension units. Caution! NetFinder will not detect units behind a router. Make sure that your PC and the units are in the same IP network segment. The firmware update uses the Trivial File Transfer Protocol (TFTP). Make sure it is enabled on your PC. For instructions, see Troubleshooting Firmware Updates on page 16. To update the base unit firmware, proceed as follows: 1. Start NetFinder on your PC. 2. Click Search. NetFinder will indicate the Net I/O units in green. 3. Click the desired unit, and then click Reboot. 4. Select the Force bootload mode option, and then click OK. If successful, the message Success – Device rebooted will appear. The unit is now disabled and goes in reboot mode. -
Page 16: Troubleshooting Firmware Updates
Network I/O Units – Technical Manual ADPRO 7. Select the firmware file (.img), and then click Open. The system will now upgrade the unit's firmware. When successful, the message Transfer successful will appear in the Windows Command screen. Troubleshooting Firmware Updates If updating the firmware fails, then check if TFTP is active in your operating system, and check the network settings. TFTP not active or blocked by firewall NetFinder uses TFTP (Trivial File Transfer Protocol) to update the base unit's firmware. You may need to enable TFTP in your Windows operating system. Also, check if your firewall is not blocking the TFTP application. To enable TFTP in Windows, proceed as follows: 1. Choose Start > Control Panel > Programs and Features. 2. Click Turn Windows features on or off. 3. ... - Page 17 ADPRO Network I/O Units – Technical Manual Normally open – NEOL Normally open – SEOL Short circuit = alarm Short circuit = alarm Open circuit = idle 1K1 = idle (Default setting) Open circuit = tamper Normally closed – NEOL Normally closed – SEOL Short circuit = idle Short circuit = tamper Open circuit = alarm 1K1 = idle Open circuit = alarm Normally open – DEOL Short circuit = tamper 1K1 = alarm 3K3 = idle Open circuit = tamper Normally closed – DEOL Short circuit = tamper 1K1 = idle 3K3 = alarm Open circuit = tamper 33355_00...
-
Page 18: Frequently Asked Questions
Network I/O Units – Technical Manual ADPRO Frequently Asked Questions Can I upgrade legacy Net I/O units so they provide monitored inputs? No. The only units that can provide monitored inputs are the new units with the new hardware. Can I replace a legacy Net I/O unit by a new one? Yes. You can just swap the units. Make sure to switch off power before swapping. After swapping, check the unit's configuration in the XO client: make sure the inputs/outputs are configured as before. If using XO version 4.02 or above, check that all inputs are set to NEOL. Test if the new unit functions exactly like the old one. Can I install the new firmware V2 on a legacy base unit? Yes, but it is not recommended. Although the new firmware is compatible with the legacy units, it does not ... - Page 20 www.xtralis.com UK and Europe +44 1442 242 330 D-A-CH +49 431 23284 1 The Americas +1 781 740 2223 Middle East +962 6 588 5622 Asia +86 21 5240 0077 Australia and New Zealand +61 3 9936 7000 A Disclaimer about this document, statements about Intellectual Property, Copyrights, and Liability, as well as a General Warning are available in an earlier section of this document. Document No: 33355_00 ...
