Summary of Contents for Triax UFO 100
- Page 1 UFO 100, 120, 140 digital antenna 891020C Mounting instructions TRIAX - your ultimate connection...
- Page 2 UFO 100, 120, 140 digital antenna Connection cable and assembly Use Class A or A+ high shielded coaxial cable only. Mount UFO on base Ensure that the UFO shells are A: Push forward fully mated with B: Push down the bracket...
- Page 3 Mounting options on vertical or horizontal surface Positioning the antenna: Assemble brackets and desk mount. Positioning the antenna and mark off holes for fixing. Mounting on mast.
- Page 4 UFO 100, 120, 140 digital antenna Mounting with universal mount (UFO 120 and UFO 140) Mounting with centre mount (UFO 120, optional accessory for UFO 100 and UFO 140) Positioning the antenna: Positioned antenna Centre mounting bracket and and counter nut fixed.
-
Page 5: Troubleshooting Guide
Troubleshooting guide Problem Possible root cause Solution Weak or missing signal Check LED on PSU/power inserter Remove the cable from the PSU/ (optional accessory IFP 529) power inserter. If the LED lights up, there is a short in the cable. Repair Often this is caused by a short or or replace the cable. - Page 6 UFO 100, 120, 140 digital antenna Application examples Fuse...
-
Page 7: Technical Data
Technical data Type UFO 100 UFO 120 UFO 140 Digital Digital Digital Art. No. 109100 109120 109140 LTE is a trademark of ETSI Frequency range FM 87.5-108 87.5-108 87.5-108 174-230 174-230 174-230 470-862 470-862 470-790 Channels FM/5-12/21-69 FM/5-12/21-69 FM/5-12/21-60 Elements pcs. - Page 8 02-2012 891020C DECLARATION OF CONFORMITY TRIAX confirms that the product conforms to relevant EEC harmonized standards and consequently can carry CE-mark. Relevant harmonized standards: EN 50083 and EN 60065 A product of the TRIAX group Dealer TRIAX - your ultimate connection...
