SC50LPGW
EN
OPERATING AND INSTALLATION
INSTRUCTIONS OF
FREESTANDING
GAS COOKER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC50LPGW and is the answer not in the manual?

Questions and answers

Summary of Contents for CALOR SC50LPGW

  • Page 1 SC50LPGW OPERATING AND INSTALLATION INSTRUCTIONS OF FREESTANDING GAS COOKER...
  • Page 2 Dear Customer, Our goal is to offer you products with high quality that exceed your expectations. Your appliance is produced in modern facilities carefully and particularly tested for quality. This manual is prepared in order to help you use your appliance that is manufactured by the most recent technology, with confidence and maximum effciency.

  • Page 3: Table Of Contents

    CONTENTS: 1. Part : PRESENTATION AND SIZE OF PRODUCT 2. Part : WARNINGS 3. Part : INSTALLATION AND PREPARATION FOR USE 3.1 Environment where the appliance will be installed 3.2 Installation of oven 3.3 Adjustment of feet 3.4 Gas connection 3.5 Electric connection and security 3.6 General warnings and measures 4.

  • Page 4: Part : Presentation And Size Of Product

    4- Supply Leg MODEL DEPTH WIDTH HEIGHT 5- Oven Door (cm) (cm) (cm) 6- Oven Tray SC50LPGW 7- Wire Grid 8- Oven Lamp 9- Semi-Rapid Burner 10- Rapid Burner 11- Auxillary Burner 12- Hob Grids 13- Semi-Rapid Burner 14- Battery box...

  • Page 5: Part : Warnings

    2. Part : WARNINGS READ THESE INSTRUCTIONS CAREFULLY AND COMPLETELY BEFORE USING YOUR APPLIANCE, AND KEEP IT IN A CONVENIENT PLACE FOR REFERENCE WHEN NECESSARY. THIS MANUAL IS PREPARED FOR MORE THAN ONE MODEL IN COMMON. YOUR APPLIANCE MAY NOT HAVE SOME OF THE FEATURES THAT ARE EXPLAINED IN THIS MANUAL.
  • Page 6 2. Part : WARNINGS - WARNING: Danger of fire: do not store items on the cooking surfaces. - WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of electric shock. - For hobs incorporating a lid, any spillage should be removed from the lid before opening.
  • Page 7 2. Part : WARNINGS - Do not use steam cleaners for cleaning the appliance. - WARNING: Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of electric shock. - CAUTION: Accessible parts may be hot when the cooking or grilling is in use.
  • Page 8 2. Part : WARNINGS transportation. In case of any defect; do not use the appliance and contact a qualified service agent immediately. As the materials used for packaging (nylon, staplers, styrofoam...etc) may cause harmful effects to children, they should be collected and removed immediately.
  • Page 9 2. Part : WARNINGS FOLD DOWN LID The lid provided for this cooker is for cosmetic purposes only. It is safe to use the cooker with the lid in the raised position but the lid may become discoloured or scratched if cleaned while hot, used as a work surface or left in position while using the oven.
  • Page 10 2. Part : WARNINGS POSITIONING The temperature at the centre of the oven corresponds with the selected temperature and will vary according to the shelf position being used. The base of the oven will become very hot during operation and should not be used as a shelf position. CONDENSATION AND STEAM When moist food is heated it produces steam in the same way as boiling a kettle.

  • Page 11: Part : Installation And Preparation For Use

    3. Part : INSTALLATION AND PREPARATION FOR USE This modern, functional and practical oven, that was manufactured with parts and materials of the highest quality, will meet your cooking needs in every aspect. You must read this manual so that you don't have any problems in the future and to achieve satisfactory results.

  • Page 14: Installation Of Oven

    3. Part : INSTALLATION AND PREPARATION FOR USE access to fresh air. This electric fan must have the capacity to change the air of the kitchen environment 4-5 times of its own volume of air per hour. Cooker hood flue Electrical ventilator Air inlet section Air inlet section...

  • Page 15: Adjustment Of Feet

    3. Part : INSTALLATION AND PREPARATION FOR USE • Pay attention not to place it near the refrigerator, there must be no flammable or inflammable materials such as curtains, cloth, etc. that will begin to burn quickly It is required that there must be least a 2cm blank space around the oven for •...
  • Page 16 3. Part : INSTALLATION AND PREPARATION FOR USE As gas is turned on, all connection parts and hose must be checked with soapy water or leakage fluids. Do not use naked flame to check gas leakage. All metal components used during gas connection must be clear of rust. Also check the expiry dates of components used.

  • Page 17: Part : Use Of Your Oven

    4. Part : USE OF YOUR OVEN 4.1 Use of gas burners Ignition of the burners To determine which knob controls which burner, check the position symbol above the knob. Manual Ignition of the Gas Burners If your appliance is not equipped with any ignition aid or in case there is a failure in the electricity network, follow the procedures listed below For Hob Burners: To ignite one of the burners, press and turn its knob counter-clockwise so that the knob is in max.

  • Page 18: Control Of Hob Burners

    4. Part : USE OF YOUR OVEN Oven / Grill Burners Regardless of the model of your appliance, all oven burners are equipped with a gas safety device. For this reason, during ignition, keep the oven knob pressed until you see stable flames. If the flames cut out after you release the knob, repeat the procedure again.

  • Page 19: Control Of Oven Burner

    4. Part : USE OF YOUR OVEN Make sure that the tips of the flames do not spread out of the outer circumference of the pan, as this may also harm the plastic accessories around the pan (handles etc.) Figure 14 When the burners are not in use for prolonged periods, always turn the main gas control valve off..
  • Page 20 4. Part : USE OF YOUR OVEN Preheating When you need to preheat the oven, we recommend you do so for 10 minutes. For recipes needing high temperatures, e.g. bread, pastries, scones, soufflés etc., best results are achieved if the oven is preheated first. For best results when cooking frozen or cooked chilled ready meals always preheat the oven first.

  • Page 21: Control Of Grill Burner

    4. Part : USE OF YOUR OVEN WRONG WRONG WRONG CORRECT pot bottom is round pot buttom does not sit well pot buttom is small Do not use cooking containers that protrude from the cookers' table. These temperature settings may change slightly when both top and main ovens are operated together.

  • Page 22: Accessories Used In Oven

    4. Part : USE OF YOUR OVEN Cooking • The grill burner cannot be modulated between maximum and minimum positions and creates a source of heat at a constant rating. When turning the grill burner off, turn the knob in the clockwise direction so that the knob shows "0"...
  • Page 23 4. Part : USE OF YOUR OVEN As explained in the corresponding clauses, never attempt to use the gas • operated grill grill burner without the grill protection lid. If your oven has a gas operated grill burner, but the grill protection lid is missing, or if the lid is damaged and cannot be used, request a spare lid from the nearest service.

  • Page 24: Part : Cleaning And Maintenance

    5. Part : CLEANING AND MAINTENANCE 5.1 Cleaning Be sure that all control switches are off and your appliance has cooled before cleaning your oven. Turn off the appliance. Check whether they are appropriate and recommended by the manufacturer before using the cleaning materials on your oven.

  • Page 25: Maintenance

    5. Part : CLEANING AND MAINTENANCE Burner Caps: Periodically, the enameled pan supports, enameled covers and burner heads must be washed with soapy warm water rinsed and dried. After drying them thoroughly, replace them correctly. Enamelled Parts: In order to maintain these parts, it is necessary to clean them frequently with mild warm soapy water and then dry with a cloth.

  • Page 26: Part : Service And Transport

    6. Part : SERVICE AND TRANSPORT 6.1 Basic troubleshooting before contacting service If the oven does not operate : The oven may be switched off. • • There may have been a black out. If the oven does not heat : The heat may not be adjusted with the oven's heater control switch.
  • Page 27 INJECTOR TABLE G30 28-30mbar 9.4 kW 683 g/h G30/G31 II2H3+ GB Clase: 1 G20 20 mbar 28-30/37 mbar LARGE BURNER DIA. of INJECTOR (1/100mm) NOMINAL RATING (KW) CONSUMPTION 285,7 l/h 218,1 g/h MEDIUM BURNER DIA. of INJECTOR (1/100mm) NOMINAL RATING (KW) 1,65 1,65 CONSUMPTION...
  • Page 28 The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
