DoubleSight DS-27PS Quick Installation Manual

Full motion single monitor arm, pole mount
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model: DS-27PS
Full Motion Single Monitor Arm, Pole Mount
Quick Installation Guide
Please Review the entire Quick Installation Guide prior to installation.
If you have any questions regarding the compatibility of this Mount with your
Monitor please contact DoubleSight Customer Service prior to beginning the
installation. It may also be helpful to check your Monitor's Manual for any
special mounting requirements outlined by the Monitor manufacturer.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-27PS and is the answer not in the manual?

Questions and answers

Related Manuals for DoubleSight DS-27PS

Summary of Contents for DoubleSight DS-27PS

  • Page 1 Please Review the entire Quick Installation Guide prior to installation. If you have any questions regarding the compatibility of this Mount with your Monitor please contact DoubleSight Customer Service prior to beginning the installation. It may also be helpful to check your Monitor’s Manual for any...

  • Page 2: Getting Started

    Images may differ from actual product. Disclaimer DoubleSight intended to make this manual completely all right. However, DoubleSight makes no claim that the information comprised herein covers all conditions or details in connection with installation or use of this product.

  • Page 3: Specifications

    360 / 180 /360 degree Maximum Mounting Surface Thickness 2.95” (75mm) VESA Compatibility 75x75mm and 100x100mm Please contact DoubleSight Displays Service and Support if you are missing any of the package contents or need assistance. DoubleSight Customer Support: 888.897.8869 or Support@DoubleSight.com...

  • Page 4: Parts List

    Carefully inspect the mount components to ensure all components are present. Note: Read all assembly instructions before staring the installation process. Please contact DoubleSight Displays Service and Support if you are missing any of the package contents or need assistance.
  • Page 5 INSTALLATION Model: DS-27PS Base Installation - Desk Clamp Note: Do not over tighten the Handle. Stop immediately if you encounter any resistance. Note: Other tools may be required depending on your method of installation. Note: It is installer’s responsibility to make sure the desktop structure to which this product is attached can support the combined weight of all compnents.
  • Page 6 INSTALLATION Model: DS-27PS Install the Pole Assembly to Desk Edge 1. Place the Pole Assembly (3) over the open edge of the desk in the desired location. (See Figure 3). Tighten the Clamp (4) by turning the handle until the Pole Assembly is securely in place. (See Figure 4)
  • Page 7 INSTALLATION Model: DS-27PS Alternate Installation - Install the Pole Assembly through Desk’s Cable Guide 1. Insert Left Cover and L Plate within the base of the Pole (3). Fix the pin of L Plate Connection into the hole of L Plate. Insert Left cover and L plate within the base of the pole.

  • Page 8: Installing Your Monitor

    INSTALLATION Model: DS-27PS Installing your Monitor Note: Using of improper screws size may damage your display. If spacers are required, be sure to use correct size of screws. Proper screws used will easily and completely thread into the display mounting holes. Inadequate thread engagement in the display may cause display falling.
  • Page 9 INSTALLATION Model: DS-27PS Attaching the Monitor and Arm to the Pole Assembly 1. Install the Extension Arm (2) over the Pole. (See Figure 10) 2. Being careful to balance the weight of the Monitor and LCD Arm, attach the LCD Arm to the Extension Arm.
  • Page 10 INSTALLATION Model: DS-27PS Using Cable Management Feature 1. Once you have connected your Monitor’s Cabling you can use the built in cable management to organize your cabling. Locate the Cable Channels on the underside of the LCD Arm. Simply push cables into the channel, leaving sufficient slack so as not to pull out cables when LCD Arm is moved.

  • Page 11: Adjusting The Monitor Height

    INSTALLATION Model: DS-27PS Adjusting your New LCD Arm to your preferences Once your Monitor and LCD Arm are completely installed you may find it necessary to make adjustments to best suit your needs. Adjusting the Position on your Desk 1. Remove the Monitor and Arm from the Pole prior to relocating the Pole. Simply lift off the Monitor and Arm and set aside on a level flat surface.
  • Page 12 CONTACT Model: DS-27PS DoubleSight Displays Sales Tel : 877.896.5237 Email : sales@doublesight.com Support Tel : 888.897.8869 Email : support@doublesight.com Website www.doublesight.com...
