SENSTAR LM100 Product Manual

Intelligent perimeter lighting and sensing solution
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Senstar LM100™
Intelligent Perimeter Lighting and Sensing Solution
Product
Guide
E8DA0102-001 Rev D
February 14, 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LM100 and is the answer not in the manual?

Questions and answers

Summary of Contents for SENSTAR LM100

  • Page 1 Senstar LM100™ Intelligent Perimeter Lighting and Sensing Solution Product Guide E8DA0102-001 Rev D February 14, 2020...
  • Page 2 The information provided in this guide has been prepared by Senstar Corporation to the best of its ability. Senstar Corporation is not responsible for any damage or accidents that may occur due to errors or omissions in this guide. Senstar Corporation is not liable for any damages, or incidental consequences, arising from the use of, or the inability to use, the software and equipment described in this guide.

  • Page 3: Table Of Contents

    Installing LM100 luminaires - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
  • Page 4 Installing the LM100 gateway - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -...
  • Page 5 Replacing the gateway assembly - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 73 Updating the Senstar LM100 Firmware - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 73...
  • Page 6 Related publications: The following documents, included on the Senstar LM100 CD, contain information that may be applicable to the Senstar LM100 system E8DA0103-001 Senstar LM100 quickstart instruction • E8DA0303-001 Installing Luminaires • E7DA0103-001 Wireless Gate Sensor • 00DA0109-001 Network Manager Overview •...

  • Page 7: System Planning

    LED lighting with an accelerometer-based vibration detection sensor. The system is comprised of a distributed set of LM100 luminaires, which include the LED lights and the vibration detecting sensor, a gateway device that processes the signals from the luminaires, and a luminaire AP (access point) that provides an RS-485 half-duplex connection between the RF-based luminaires and the gateway.
  • Page 8 The Senstar LM100 can be part of a Silver Network based security system. In this case the gateway requires a network interface card (NIC) that connects to a PC running Senstar’s Network Manager (NM) service.

  • Page 9: Senstar Lm100 Luminaires

    System description Senstar LM100 luminaires The luminaire is both the sensing unit and the lighting unit for the Senstar LM100 system. The luminaires communicate over a wireless mesh network, relaying status information to the gateway via the luminaire AP. Luminaires are usually mounted near the tops of the fence posts, and can also be mounted on walls or other flat surfaces.

  • Page 10: Senstar Lm100 Luminaire Ap

    24 VDC power supply. Senstar LM100 gateway The gateway is the central controller for the Senstar LM100 system. It communicates with the distributed luminaires through a 2-wire RS-485 connection to the luminaire AP. The gateway...

  • Page 11: Operating Frequency Selection

    LM100 can use for mesh network communication. Therefore, if your site uses a Wi-Fi network you should select an LM100 channel that does not overlap a Wi-Fi band in use at your site. In North America, Wi-Fi channels 12 and 13 are not used, so Senstar LM100 channels 15 and 16 can be used without potential Wi-Fi interference.

  • Page 12: The Universal Configuration Module

    The Universal Configuration Module (UCM) is a Windows based software application, which serves as the calibration, setup and maintenance tool for the Senstar LM100 system. The UCM communicates with the gateway locally through a USB connection, or remotely via the Silver Network Manager.

  • Page 13: Fail-Safe Relay Operation

    Power source and wiring The Senstar LM100 system operates on a wide range of input voltages (12 to 48 VDC). A 12 VDC power supply is suitable for powering the gateway and the luminaire AP, or a single luminaire.

  • Page 14: Power Over Ethernet

    Senstar LM100 gateway. Grounding considerations The Senstar LM100 gateway requires a stable low resistance earth ground connection. Use a short straight length of heavy gauge copper wire to connect the ground lug on the bottom of the enclosure to an approved low resistance earth ground.

  • Page 15: Security Factors

    (pointed stakes or pales). Senstar recommends that the minimum fence height for a Senstar LM100 installation on a flexible fence type is 2.5 m (8 ft.). For rigid fence types the minimum recommended fence height is 2 m (6.5 ft.).

  • Page 16: Fence Structures

    It is also possible to install luminaires by marking the fence posts, drilling four holes and using self-tapping screws. Flexible fence types chain-link welded-mesh expanded metal Figure 5: Standard flexible fence types Rigid fence types Figure 6: Rigid fence (palisade) Page 16 Senstar LM100 Product Guide...

  • Page 17: Climb-Over Deterrent Hardware

    Fence structures Climb-over deterrent hardware Note The mounting height of the Senstar LM100 luminaires on the fence posts may require adjustment to avoid contact with the climb-over deterrent hardware. Barbed wire Barbed wire outriggers must be secure to prevent movement due to environmental conditions.

  • Page 18: Gates

    Prevent locking hardware from moving in the wind. • Prevent sliding gate track hardware, supports, guides, etc., from rattling in the wind. There are two ways to protect gates with the Senstar LM100 system: • The wireless gate sensor (WGS), •...

  • Page 19: Equipment Layout

    Use a site plan to mark the locations for the Senstar LM100 components: • LM100 gateway - indicate the location and note the address for network based systems • LM100 luminaire AP - indicate the location for the Access Point •...
  • Page 20 Equipment layout Page 20 Senstar LM100 Product Guide...

  • Page 21: Installation

    (light control) discrete outputs (alarms / control points) network interface to SMS Figure 10: Senstar LM100 concept drawing Note The installation location of the luminaire AP depends on the location of the gateway. Refer to the site plan to identify the location of the gateway and the luminaire AP.
  • Page 22 5. Measure the space between the top of the fence post and the luminaire’s bracket and install the remaining luminaires at the same height. Page 22 Senstar LM100 Product Guide...
  • Page 23 2.5 cm separation lower the mounting height to increase separation 2 stainless steel clamps power cable drip loop Figure 13: Luminaire installation example Figure 14: 2.4 m (8 ft.) chain-link fence with luminaires Senstar LM100 Product Guide Page 23...

  • Page 24: At Corners Or Heavy Gauge Posts

    Figure 16: Luminaire installation on heavy gauge posts Installing luminaires on welded-mesh fence Mount the luminaire as high on the fence post as possible on the side of the fence that is facing the threat. Page 24 Senstar LM100 Product Guide...

  • Page 25: Installing Luminaires On Rigid Fences

    Mount the luminaire as high on the fence post as possible on the side of the fence that is facing the threat. ® Impasse II high-security palisade fence power cable post clamps drip loops Figure 18: Palisade fence with luminaire Senstar LM100 Product Guide Page 25...

  • Page 26: Surface Mounting Luminaires

    Power cables are typically run along the top of the fence and daisy-chained from luminaire to luminaire. The power cables pass through a grommet at the bottom of each luminaire and are connected to the luminaire’s power wires with nylon-insulated, closed-end crimp connectors. Page 26 Senstar LM100 Product Guide...

  • Page 27: Tools And Equipment

    Molex crimps are available in kit E8KT0101 (2 crimps per kit). One kit per luminaire. Note In harsh weather environments which include wind blown salt water spray, Senstar recommends the use of a protective marine type dielectric grease compound to protect the electrical connections to the luminaires. Tools and equipment...
  • Page 28 Figure 26: Preparing the splice 8. Make the crimp. If the crimp tool you are using does not cover the full length of the internal crimp ring make a second crimp. Page 28 Senstar LM100 Product Guide...

  • Page 29: Installing The Luminaire Ap

    AP and the AP connections to the gateway. See Figure 11: Figure 12: Figure 38: additional installation and connection details. DC power luminaire AP RS-485 data cable shield Figure 29: Luminaire AP mounting and connection Senstar LM100 Product Guide Page 29...

  • Page 30: Installing The Lm100 Gateway

    The gateway can be installed up to 100 m (328 ft.) away from the luminaire AP by splicing in a length of power and data cable. Protect the splice inside the AP’s shaft, or in an outdoor-rated junction box. Figure 30: Senstar LM100 gateway features Page 30 Senstar LM100 Product Guide...

  • Page 31: Cable Entry Ports

    Installing the LM100 gateway Item Description Item Description Network interface card mounting hardware (X 2) 7 T8 - I/O ports 6 - 10 Activity LEDs - DOOR OPEN, UCM ACTIVE, T5 - RS-485 connection to luminaire AP: (green A NETWORK POWER FAIL, INTERNAL POWER...
  • Page 32 CAUTION For installations in environments which include hot sunny periods, Senstar recommends that a sun shield be installed to protect the enclosure from direct sunlight, or that the enclosure be installed in a shady area. The maximum operating temperature, as measured inside the enclosure, is 70º...

  • Page 33: Surface Mounting

    Installing the LM100 gateway 1. Hold the enclosure against the fence at the specified installation location. 2. Feed the end of the stainless steel clamp through an upper flange slot, around the fence post, and back through the second slot.

  • Page 34: Grounding

    Consult the local electrical code for grounding information. Input/Output ports The LM100 gateway includes ten I/O ports that can be configured as either dry contact inputs or relay outputs in any combination. The I/O ports are accessed through removable screw terminal blocks.

  • Page 35: Relay Contact Ratings

    Installing the LM100 gateway high side drive I/O port shunt Form B Form A dry contact output (N.O.) power sourcing output dry contact output (N.C.) Figure 36: Gateway output schematics Relay contact ratings The gateway’s relays are latching, and are rated 30 V @ 1 A maximum.

  • Page 36: Gateway Wiring Connections

    Figure 37: Gateway input wiring examples Gateway wiring connections LM100 gateway wiring connections are made on removable terminal blocks. The screw terminals accept wire sizes from 12 to 24 AWG, with a 6 mm (¼ in.) strip length. Remove the terminal blocks to make the wiring connections.
  • Page 37 Installing the LM100 gateway T6 DC power T7 I/O ports 1 - 5 T8 I/O ports 6 - 10 T5 RS-485 INPUT POWER (12 to 48 VDC) RS-485 AP -VDC* AP B-side data* gateway -VDC gateway +VDC AP A-side data*...

  • Page 38: Silver Network Wiring Connections

    Installing the LM100 gateway Silver Network wiring connections Note A network interface card is required on the gateway to enable Silver Network communications. Silver Network specifications • Data rate - fixed 57.6 k bps • Maximum 60 devices spread over up to 4 independent network loops •...
  • Page 39 Installing the LM100 gateway NIC mounting hardware (X 2) expansion header T1 (on solder side) (plugs into T2 on gateway) A-side comms B-side comms use single point grounding (connect the cable shield to ground at one end, trim back the other end and leave it...

  • Page 40: Silver Network Data Path Connections

    Installing the LM100 gateway Silver Network data path connections In the standard Silver Network setup, a point to point loop configuration is used for network communications. Figure 42: shows the network connections for the RS-422 and fiber optic communication options.
  • Page 41 Installing the LM100 gateway maximum 60 devices first device last device second device maximum distance between devices single-mode fiber optic = 10 km (6.2 miles) multi-mode fiber optic = 2.2 km (1.4 miles) Network Interface Unit TXA RXA to Network Manager...

  • Page 42: Power Supply Connections

    Installing the LM100 gateway Power supply connections The LM100 gateway operates on 12 to 48 VDC. The power connection is made on removable terminal block T6. In most cases, the luminaire AP’s power leads are also connected to T6. WARNING! DO NOT bring AC mains power into the gateway enclosure.

  • Page 43: Using The Wireless Gate Sensor

    Using the wireless gate sensor Using the wireless gate sensor The wireless gate sensor (WGS) operates in conjunction with the Senstar LM100 system to provide RF-based wireless security protection for gates. The WGS is comprised of two components. The wireless gate sensor module (GSM) is attached to the gate. The GSM analyzes signals picked up from the fence fabric on the gate and transmits alarm data when it detects vibration, motion, or positional changes.
  • Page 44 Using the wireless gate sensor Page 44 Senstar LM100 Product Guide...

  • Page 45: Calibration & Setup

    The Universal Configuration Module (UCM) is a Windows based software application, which serves as the calibration, setup and maintenance tool for the Senstar LM100 system. The UCM communicates with the gateway locally through a USB connection, or remotely via the Silver Network Manager.
  • Page 46 Figure 49: UCM Status window The following table includes the Senstar LM100 configuration parameters along with a brief description of each parameter. The Sensor Head Configuration settings apply to all of the installed luminaires, unless the parameter is assigned to a specific segment or zone.
  • Page 47 Config tab - sensor head configuration, settings apply to luminaires, see Figure 54: Comm Channel If 2 or more Senstar LM100 systems operate within 400 m (1300 ft.) of each other, they must use different Comm Channels to prevent mutual interference (1 - 16)
  • Page 48 (schedule starts) time OFF (schedule ends) Zone, Level - 3 brightness level selections prioritized from lowest to highest (i.e., Level 1, Level 2, force Off) SD Card tab - select the type of data that will be saved to an SD card on the LM100 gateway, troubleshooting feature...

  • Page 49: Senstar Lm100 Configuration Overview

    Senstar LM100 configuration overview Senstar LM100 configuration overview To setup and calibrate the Senstar LM100: 1. Set the gateway’s Silver Network parameters, if required (see Initial gateway setup on page 52). • Silver Network Address • Silver Network configuration (Loop or Star) •...

  • Page 50: Senstar Lm100 Definitions

    Segments are software-defined during setup, and are assigned to zones for display and control purposes. Each Senstar LM100 system can be comprised of up to 50 segments. A single segment, or multiple segments, can be assigned to one zone. Each luminaire segment has an independent event threshold.

  • Page 51: Intrusion Detection

    If the Alarm Window Time lapses before the Event Count setting is reached, the Event Count and Alarm Window are reset without triggering an alarm. Intrusion detection The Senstar LM100 system guards against three intrusion scenarios: • An intruder attempting to cut through the fence.

  • Page 52: Setting The Supervision Tolerance

    If the supervision alarm rate is unacceptable at the 8x setting, the fence should be repaired or replaced to be protected by the Senstar LM100. Initial gateway setup Senstar recommends that the initial setup be done at the gateway location using a direct USB connection to the UCM. Note An enclosure tamper condition must exist to enable UCM communication via a USB connection.

  • Page 53: Silver Network Configuration

    Sequencing the heads Silver Network configuration For Senstar LM100 gateways that use Silver Network alarm data communications, you must define the network Protocol under the Network Cfig tab. There are two selectable Protocols based on the network configuration: • The Silver Loop Protocol uses a ring topology and sends data in both directions around a perimeter to provide communication redundancy.

  • Page 54: Compiling The Unordered Heads List

    1. Establish a UCM connection to the gateway (USB or NM). 2. On the Config tab, select the Sequence button. 3. Select the Record button below the Unordered Heads field and wait for the LM100 gateway to compile the list of unordered heads (this process can take several minutes).

  • Page 55: Compiling The Ordered Heads List

    Ordered Heads list, hold down the shift key and select the last luminaire in the Ordered Heads list to highlight all of the luminaires. Next, select the double arrow button to move the Ordered Heads list to the Head Sequence list in the same order. Senstar LM100 Product Guide Page 55...

  • Page 56: Senstar Lm100 Calibration

    Head Sequence table will include the segment and zone information with the heads that are assigned to them. Senstar LM100 calibration When calibrating the Senstar LM100 for the first time, begin with the detection parameters in the default settings. The Sensitivity Profile A Sensitivity Profile should be recorded for the full length of the protected fence.

  • Page 57: Recording The Sensitivity Profile

    (e.g., loose, sagging, stretched). Senstar recommends that you save a UCM file that includes the recorded sensitivity profile. This can be useful for future maintenance and troubleshooting activities.

  • Page 58: Detection Parameter Setup

    10. Close the Profile window and download the Sensitivity Profile data to the gateway. Detection parameter setup The Senstar LM100 segments, alarm zones and detection parameters are setup globally through the gateway, and are applied to all of the luminaires. The Config tab includes 2 sub-panels the Lights sub-panel and the Zones sub-panel.

  • Page 59: Light Control

    Defining the luminaire segments and alarm zones Each Senstar LM100 system can be organized into up to 50 segments. The defined segments can then be assigned to as many as 50 distinct alarm zones. Use the UCM software to organize the luminaires into segments, according to the site’s requirements for alarm detection and response.

  • Page 60: Defining The Segments And Alarm Zones

    1 to 7, then the second segment will start with luminaire 8.) Next, assign the defined segment a zone number for alarm reporting and lighting control. Each Senstar LM100 can include up to 50 segments and up to 50 distinct alarm zones. Note The listed properties apply to the selected segment (Zone, Relay, Head, Threshold, Profile).

  • Page 61: Verifying The Luminaire Segment Boundaries

    1. Establish a UCM connection to the LM100 gateway and select the Config tab. 2. Select File > Response Plot and set the Senstar LM100 response plot so the Display Format is Magnitude vs Location, the Heads: All radio button is selected, and the Peak Capture checkbox is selected.

  • Page 62: Segment Threshold Setting Procedure

    Figure 57: Setting the segment Thresholds Figure 57: illustrates a Segment setting window for a Senstar LM100 system, which has been split into 6 segments and 5 zones. Segments 1, 2 and 5 (Zones 1, 2 and 4) use the overall Threshold setting.

  • Page 63: Intrusion Simulations

    Senstar LM100 calibration Intrusion simulations Conduct simulations for both cut and climb intrusions to test the Senstar LM100 system. The easiest method for simulating a cut intrusion is to firmly tap the fence with the blade of a medium sized screwdriver. Hold the screwdriver by the handle, and flip your wrist to bring the blade into contact with the fence.

  • Page 64: Scheduling Routine Light Activation

    Once the segment and zone assignments are made, a schedule can be setup for routine light control. The Senstar LM100 enables up to eight lighting schedules for the defined luminaire zones. Specify the time at which the schedule begins (On) the time at which the schedule ends (Off) the days of the week on which the schedule is active, the Zone to which the schedule applies, and set the brightness (Level) on the Schedule tab.

  • Page 65: Input/Output Configuration

    Note See document # 00DA1003-002 for details on using the UltraLink modular I/O system to report Senstar LM100 alarm conditions. select the Aux Cfig tab to setup the gateway’s inputs and outputs select the control mode for the gateway’s I/O specify the type of I/O option card, if applicable use the radio buttons to specify each port’s function...

  • Page 66: Auxiliary (Aux) Inputs

    Manager. Remote light activation In both local control mode and remote control mode, the Senstar LM100 can be configured to have specific luminaires activated from remote locations. In local control mode, a simple on/off switch in a central control room can be connected to an Aux input on the gateway. When the switch is turned on the aux input goes high and the luminaire zone that is specified to activate in response turns on (Zone Light Activate on the Aux Config tab).

  • Page 67: Input Configuration Procedure

    9. For Local Control mode, specify the luminaire zone to activate when the input is activated. 10. Select the Light Level (brightness) for the activated zone. 11. Repeat this procedure for each designated input. 12. Save the UCM configuration file and download the configuration changes to the gateway. Senstar LM100 Product Guide Page 67...

  • Page 68: Output Relays

    4. Select the Hold/Active Time parameter, if applicable. 5. Select the Inactive Time parameter, if applicable. 6. Repeat this procedure for each designated output. 7. Save the UCM configuration file and download the configuration changes to the gateway. Page 68 Senstar LM100 Product Guide...

  • Page 69: Linking Relays To Zones (Local Control Mode)

    At each location, tap the fence fabric, or cut the scrap wire, the number of times specified by the Event Count parameter + 1. Wait at least 2 seconds between taps. PASS ____ FAIL____ Senstar LM100 Product Guide Page 69...
  • Page 70 FAIL____ • Alarm Light Control - For luminaire zones that are setup to activate in response to alarm conditions, simulate an alarm and verify that the luminaire zone activates as specified. PASS ____ FAIL____ Page 70 Senstar LM100 Product Guide...

  • Page 71: Maintenance

    Note Luminaires are service-free and include no user-serviceable components. The Senstar LM100 system requires minimal maintenance to ensure proper operation. However, setting up and following a maintenance schedule based on your site-specific requirements can ensure proper detection performance, prevent nuisance alarms and extend the operational lifetime of the system.

  • Page 72: Preventing Weather Related Nuisance Alarms

    Preventing weather related nuisance alarms If your Senstar LM100 system is having a problem with nuisance alarms during inclement weather, connect the UCM to the gateway and review the alarm history to try to determine the source of the nuisance alarms.

  • Page 73: Replacing The Gateway

    7. Retest the protected fence and recalibrate, if required. Updating the Senstar LM100 Firmware To update the Senstar LM100 device firmware (gateway, luminaire, wireless gate sensor) select the Application button in the Program field at the top of the UCM screen. The following example will illustrate updating the luminaire firmware, which can take up to 30 minutes to complete due to the distributed locations of the luminaires, and the low power RF transmissions.
  • Page 74 Updating the Senstar LM100 Firmware the firmware upgrade from Senstar Technical Services. Save the firmware file to a known location (e.g., a folder on your desktop). Save a UCM file with your current settings as a safety backup before proceeding with the update.

  • Page 75: Parts List

    Senstar LM100 luminaires Senstar LM100 luminaire AP E8FG0111 luminaire AP with 3 m (10 ft.) RS-485 comm/power cable for hard- wired connection to gateway (1 required per Senstar LM100 system) Senstar LM100 luminaire E8FG0211 1 luminaire with post clamps, power cable crimps and grommet...
  • Page 76 AC/DC power supply 185 W GP0160-185 48 VDC 185 W power supply IP65 (universal AC input voltage) AC/DC power supply 480 W GP0160-480 48 VDC 480 W power supply IP65 (universal AC input voltage) Page 76 Senstar LM100 Product Guide...

  • Page 77: Specifications

    PCB dimensions (L x W) • 13.2 x 14.5 cm (5.2 x 5.7 in.) Quantity • one gateway per Senstar LM100 system • IP66/NEMA 4 painted aluminum, outdoor rated Enclosure • L x W x D 26 cm (+2.5 for cable glands) x 16 cm x 9 cm...
  • Page 78 12 - 48 VDC power consumption • 2.5 W nominal Supervision • installed orientation and communication of each luminaire Temperature • -40º to +70ºC (-40º to +158º F) Relative humidity • 0 to 100% Page 78 Senstar LM100 Product Guide...
