Vello LAE-CR-CEF User Manual

Auto lens adapter, canon ef/ef-s lens to canon rf mount
Hide thumbs

Advertisement

Quick Links

Download this manual
AUTO
LENS ADAPTER
User Manual
LAE-CR-CEF
Canon EF/EF-S Lens to
Canon RF Mount

Advertisement

loading
Need help?

Need help?

Do you have a question about the LAE-CR-CEF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vello LAE-CR-CEF

Summary of Contents for Vello LAE-CR-CEF

  • Page 1 AUTO LENS ADAPTER User Manual LAE-CR-CEF Canon EF/EF-S Lens to Canon RF Mount...
  • Page 2 THANK YOU FOR CHOOSING VELLO This Vello Auto Lens The inside of the adapter is Adapter is for attaching coated to reduce any stray Canon EF and EF-S lenses reflections and maximize to a Canon RF mount. It picture quality. The tripod...
  • Page 3 Vello will not responsible • Do not use solvents such • Handle the unit with for any damage. as benzene, alcohol, or care.
  • Page 4 OVERVIEW Front Back EF-S Lens Alignment Dot Camera Mount (White) Lens Release Alignment Dot EF Lens Alignment Dot (Red) EF/EF-S Lens Mount Canon RF Mount Tripod Foot Tripod Foot Mounting Wheel 1/4-20 Tripod Socket...
  • Page 5 CONTENTS • Vello LAE-CR-CEF Lens Adapter for Canon EF/EF-S lens to Canon RF mount • Front and Rear Caps • Removable Tripod Foot • User Manual...
  • Page 6 MOUNTING THE LENS ADAPTER Note: Place the lens and 3. Line up the alignment camera on a stable, flat dots on the lens adapter surface when mounting or and the camera. removing the lens adapter. 4. Carefully insert the lens 1.
  • Page 7 5. Line up the alignment dot on the lens with the alignment dot on the lens adapter. 6. Carefully insert the lens into the lens adapter, and rotate the lens clockwise until it locks into place.
  • Page 8 REMOVING THE LENS ADAPTER 1. Turn the camera’s 3. Rotate the lens power off. counterclockwise to release, and carefully 2. Press and hold the detach the lens from the release pin on the lens lens adapter. adapter. 4. Reattach the front lens cap to the lens adapter.
  • Page 9 5. Press and hold the lens 7. Reattach the back lens release button on the cap to the lens adapter. camera. 6. Rotate the lens adapter counterclockwise to release, and carefully detach the lens adapter from the camera.
  • Page 10 REMOVING THE TRIPOD FOOT To remove the tripod Note: If your lens has a built-in foot, rotate the mounting tripod collar, use the collar on wheel counterclockwise the lens to mount the assembly until the foot is loose to the tripod. enough to remove from the lens adapter.

  • Page 11: Specifications

    SPECIFICATIONS Compatible Lenses Canon EF and EF-S Compatible Cameras Canon EOS R Front Mount Canon EF/EF-S Rear Mount Canon RF Tripod Mount 1/4-20 Dimensions (H × W × D) 3.5 × 2.8 × 1.6 in. (8.8 × 7.1 × 4 cm) without protective caps Weight 5.7 oz.

  • Page 12: One-Year Limited Warranty

    One-Year Limited Warranty This VELLO product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
