05.0410 Mounting
Bail
90.4524 Washer
(2)
90.4424 Bolt (2)
90.4972 Cover (1)
90.4072 Machine
Screw (4)
05.0502 SPDT
Switch (2)
02.6021 Circuit
Board Assembly
81.0198 #6 Blue
Spade Connector (2)
41.0141.010Red (4')
41.0141.010Blk (4')
SHO-ME
MODEL NO. 02.6100
Sealed Beam
Installation and Maintenance
Instructions
90.3057 Sealed
Beam Bulb (10)
90.6756 Rubber
Gasket (10)
90.4225 1/4-20 x
3 1/2" Slotted
Round Bolt (2)
90.3939 Red Pilot
Lamp (3)
90.3804 15 AMP
Fuse
81.0198 #6 Blue
Spade Connnector (4)
PRODUCTS COMPANY
U.S. and Canada Toll Free Numbers Phone: 800-641-4098 FAX: 800-526-1240
E-mail: sales@able2products.com WEB: www.able2products.com
®
90.3758 Lamp
Connector (10)
90.6602 DUST COVER
34" Short Cable
90.3704 4-Way
Connector
02.6020 Cable
Harness with
Connector (20')
804 East Hwy 248
Cassville, MO 65625
90.4901 alum frame
90.4928 Split
Washer (2)
90.4150 1 /4-20
nylon insert ss (2)
90.4523 Stainless
Steel Washer (2)
90.4150 Stainless
Steel Nylon Insert
Nut (2)
1-09-08
Advertisement
Summary of Contents for Able 2 SHO-ME 02.6100A
- Page 1 SHO-ME ® MODEL NO. 02.6100 Sealed Beam Installation and Maintenance Instructions 90.3758 Lamp 90.3057 Sealed Connector (10) Beam Bulb (10) 90.4901 alum frame 90.6756 Rubber 90.4928 Split Gasket (10) Washer (2) 90.4150 1 /4-20 nylon insert ss (2) 90.4225 1/4-20 x 3 1/2"...
-
Page 2: Trouble Shooting
Installation Instructions All connections are external. There is no need to open the control box during the installation process. Remove dust cover by removing the two lock nuts and washers located on the back of the arrow board. Mount the SHO-ME Directional Arrow Board on the vehicle as desired. Replace dust cover. - Page 3 Wiring for 02.6100 Arrow Board Black to all Red to Red White/Gnd Green to Red White to Red Black Ground Green +12V Left +12V Center White +12V Right Black Ground +12V SHO-ME ® Made In U.S.A. - 3 -...
