Summary of Contents for AgriBus G+
- Page 1 AgriBus-G+ User's Guide ...
- Page 2 AgriBus-G+(ZyPlus) is a high-precision GNSS and workstation interface. Provides accurate GNSS guidance by connecting Bluetooth to smartphones and tablets that are equipped with your tractor and have AgriBus-NAVI installed on them. In addition, it has a vehicle speed pulse output function corresponding to each of the domestic and import tractors, and can be connected to a working machine having a vehicle speed link function to perform precise operations.
- Page 3 1.3. Names and Functions of the Components ① Mounting hole ② USB-A connectors ③ Main connector ④ GNSS-B ANTENNA CONNECTOR ⑤ GNSS-A ANTENNA CONNECTOR ⑥ LoWA ANTENNA CONNECTOR ⑦ Setting switch ⑧ LEDs (lamps) ⑨ 3G ANTENNA CONNECTOR...
- Page 4 1.4. Connector Description ① CAN1 connectors ② Power input Connect to the power connector on the agricultural machine. Apply power from DC12 to 24V. A higher voltage or reverse connection may damage the product. ③ Vehicle speed pulse output connector for foreign cars Cable color (white): Signal cable color (gray): GND ④...
-
Page 5: Basic Operations And Settings
2. Basic operations and settings 2.1. LEDs (lamps) LED1: Displays the status of the RTCM. For LoWA use Flashing Waiting for RTCM reception Lighting Receiving RTCM For 3G use Slow blink: Connecting to mobile phone network Fast blink: Connecting to the server Lighting Receiving RTCM LED2 (red): Not used... - Page 6 2.2. About AgriBus-NAVI (App) Settings ① Set Progress Smoothing Time to "0 ms"...
- Page 7 ② Setting how to acquire GNSS correction information Press "Set how to acquire GNSS correction data" on the setting window. Enter the host name, port number, mount point (path), user name, and password. Also, please contact the service provider for the above information.
- Page 8 Install the GNSS-A/B at a distance of 0.5 m or more, and install the two antennas horizontally as shown below. From the AgriBus-NAVI settings window, click GNSS Antenna Position and enter the GNSS-A antenna position. (e.g., X-1, Y 1.5, Z 2.2) ④...
- Page 9 This setting allows the AgriBus-G+'s attitude sensor to operate correctly. The settings vary depending on how the AgriBus-G+ is installed in the agricultural machinery. Set the following items. ・ Bottom Orientation of Equipment ・ Reference plane ・ Left/Right Skew ・ Forward/backward inclination ・...
- Page 10 Tapping a Bluetooth device that begins in the AGBGP-BT that appears on an available device Set "Acquire GNSS location" to "AgriBus-G+" on the AgriBus-NAVI settings window. Select the BluetoothID to connect to from "Connect BluetoothGNSS" on the AgriBus-NAVI settings window. 3. If you think it will fail, 3.1.
- Page 11 ・ Do you select "Connect Bluetooth GNSS" on the AgriBus-NAVI? 3.3. Bluetooth communication is unstable ・ Is 5 m or more away from AgriBus-G+? 3.4. GNSS is unstable ・ Is the GNSS Antenna correctly connected? ・ Is the GNSS antennae installed in a great location, such as the roof of agricultural equipment? 4.
