TOOLS REQUIRED:
•
Tape Measure
•
Phillips Head Screwdriver
•
Drill Motor & 3/32" Drill Bit
•
Pencil or Scriber
•
File
•
Scissors
•
Utility Knife
•
Level
Assembled Unit
Step 1
Verify Part Lengths Required
R2040 guides should measure the opening height minus 1 15/16".
The completed canopy assembly should measure the opening width minus 1/16".
Note: The Mesh Lock
end cap guide runners. A 1" wide, 8" long piece of thin cardboard
folded in the middle can be inserted into the guide channel to make
the bottom of the channel visible.
Date: 05/01/2019
ROLL AWAY
Installation Instructions
REVIEW ALL INSTRUCTIONS
BEFORE STARTING STEP 1
Partially
Flat Head Screw
#6 x 3/4"
can obscure the guide locks and canopy
TM
Tel: 800-677-5264 | Fax: 888-526-4329
R. Lang Company
Series 4000
®
(Window Screen)
IMPORTANT:
THOROUGHLY
PARTS INCLUDED:
R4060 & R4070 left and right
Guide Locks
With R4280 magnets installed
R2040 with
TM
Meshlock
Installed
Installation
Page 1 of 5
