Summary of Contents for Hanwha Wisenet SPI-50
- Page 1 IR illuminator Quick Guide SPI-50...
- Page 2 Caution CAUTION RISK OF ELECTRIC SHOCK.DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSISTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.
- Page 3 11. Unplug this apparatus when a card is used. Use caution when moving the cart/ apparatus combination to avoid injury from tip-over. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as powersupply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
- Page 4 Contents ovErvIEw Product Features What’s included InStallatIon Mounting on the positioning system How to set IR illuminator channel SpECIfICatIon Specification Product Overview 4_ Contents...
- Page 5 overview product features 1. It enables you to identify objects even at night with no lighting. 2. You can switch between Day/Night camera modes with the built-in sensor. 3. You can use a single or dedicated bracket to attach the product to the positioning system. 4.
- Page 6 Installation Mounting on the positioning system 1. Secure the bracket to the camera with the 3 supplied bolts. 2. Connect the IR illuminator to the fixed bracket, using 3 bolts as shown. 6_ Installation...
- Page 7 wiring hole 3. Insert the IR illuminator cable into the housing through the wiring hole in the bracket and the hole in the back of the housing. wiring hole 4. Connect the power cable and RS-485 cable of the IR illuminator to the board in the housing. English_7...
- Page 8 Installation How to set Ir illuminator channel 1. Open the round cover on the back of the IR illuminator. 2. You can set the illuminator channel using the DIP switch in the DIP switch cover. Use only the 2nd DIP switch to set the illuminator channel.
- Page 9 Specification Specification Description Items SPI-50 LED Type IR LED Distance Performance 200m Number of LED 9(EA) Contiunously variable Operational Fixed 25° angle Wavelength 850nm Automatic IR On/Off control related to Camera Day&Night, Automatic Control Brightness can be controlled during zoom operation Between Camera &...
- Page 10 Specification product overview Unit : mm 10_ Specification...
- Page 11 Hanwha Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products. The Eco mark represents Hanwha Techwin’s devotion to creating environmentally friendly products, and indicates that the product satisfies the EU RoHS Directive.
- Page 12 Hanwha Techwin(Tianjin) Co.Ltd No.11, Weiliu Rd., Micro-Electronic Industrial Park, Jingang Road Tianjin 300385, China Tel : +86.22.2388.7788 www.hanwha-security.cn Hanwha Techwin Middle East FZE JAFZA View 18, 20th floor, office 2001, 2002, 2003, Downtown Jebel Ali, Dubai, United Arab Emirates http://hanwha-security.com...
