Summary of Contents for CDVI AIOM
- Page 1 ENGLISH AIOM 10-Input/10-Output Module The installer’s choice cdvigroup.com...
-
Page 2: Table Of Contents
6] WARRANTY - TERMS & CONDITIONS ..........19 Copyright (C) 2012 CDVI. All rights reserved. ATRIUM Access Control is protected by copyright law and international treaties. -
Page 3: Product Presentation
10-Input/10-Output Module 1] PRODUCT PRESENTATION The AIOM 10-Input/10-Output Module module supports 10 zone inputs and 10 outputs. It can be connected to the ATRIUM 2-Door Controller’s, AC22, anywhere on the 1220m (4000ft) 4 conductor RS485 communication bus. Effortless auto-detect technology identifies the AIOM on the communication bus. -
Page 4: Notes And Recommendations
To comply with UL listings, the following requirements must be met: • Use of UL listed readers (Wiegand: 26-bit, 30-bit and 40-bit; mag stripe: up to 32 digits) • Use of a UL recognized tamper switch on every housing cabinet for the AIOM • Use only UL listed cables •... -
Page 5: Recommended Wiring
INSTALLATION MANUAL AIOM 10-Input/10-Output Module Recommended Wiring Maximum Equipment Wire Type Size Length Zone input and output 2 conductors, copper 22AWG (0.64mm) 22AWG (0.64mm) 600m (2000ft .) CAT 5/5e or 4 pairs 24AWG (0.51mm) RS485 bus, Star or Daisy Chain (no BIAS/ 1220m (4000ft .) -
Page 6: Package Contents
INSTALLATION MANUAL AIOM 10-Input/10-Output Module 3] PACKAGE CONTENTS This chapter details how to install and setup the ATRIUM 10-Input/10-Output Module. Content of the 10-Input/10-Output Module The 10-Input/10-Output Module contains: • One 10-Input/10-Output Module module in its cabinet with connection diagram label •... -
Page 7: Location And Mounting
INSTALLATION MANUAL AIOM 10-Input/10-Output Module Location and Mounting The cabinet is designed to be installed indoors, in a safe and secure location. Suggested locations include electrical rooms, communication equipment rooms, closets or in the ceiling. To save time, wiring and facilitate testing, install the cabinets at an equal distance between its controlled doors. -
Page 8: Mounting Instructions
INSTALLATION MANUAL AIOM 10-Input/10-Output Module 4] MOUNTING INSTRUCTIONS Install the wall tamper switch using the supplied bolts and nuts as shown in the following picture. Install the tamper switch plastic spacer on the back at bottom left side of Cabinet Side View the box as show in the following picture. - Page 9 INSTALLATION MANUAL AIOM 10-Input/10-Output Module Install the door tamper switch by aligning the switch holes to the pre-installed plastic bracket pins. Press firmly to secure the tamper switch in position, then fix the bracket to is mounting flange. Refer to page <?> for wiring diagram.
-
Page 10: Installing The Box Lock
INSTALLATION MANUAL AIOM 10-Input/10-Output Module Installing the box lock Installing the box lock allows to secure the box from non authorized access. If needed install the box lock as shown in the following picture. 1. Remove the box door knock-out. -
Page 11: Fixing The Box To Its Location
INSTALLATION MANUAL AIOM 10-Input/10-Output Module Fixing the Box to its Location Install the box to its location using 4 screws (not supplied) as shown in the following picture. If the wall tamper switch is used, make sure that the tamper switch arm moves freely and is completely pushed in when the enclosure is installed on the wall. -
Page 12: Installing The 10-Input/10-Output Module Pc Board
INSTALLATION MANUAL AIOM 10-Input/10-Output Module Installing the 10-Input/10-Output Module PC board Install the 5 fasteners (PCB holder) supplied respectively to the box holes identified in red in the following picture . AIOM Input / Output Module INPUTS INPUTS OUTPUTS OUTPUTS... -
Page 13: Wiring Diagram
Connecting the Box Tamper Switches Connecting the tamper switches allows the AIOM Module to detect when the cabinet door is opened and/or when the cabinet is removed from the wall. To install the tamper switches, see “Installing the Tamper Switches”. -
Page 14: Connecting Inputs
INSTALLATION MANUAL AIOM 10-Input/10-Output Module Connecting Inputs The 10-Input/10-Output Module can monitor the state of up to 20 devices (using zone doubling) such as magnetic contacts, motion detectors, temperature sensors, or other devices. The following are examples of the type of inputs that can be monitored: Magnetic Door Contact: Permits supervision of door “status”... -
Page 15: Examples Of Input Connection Methods
INSTALLATION MANUAL AIOM 10-Input/10-Output Module Examples of Input Connection Methods Single without EOL and without TAMPER Supervision (Limit of 1 Detection Device on the Input) INPUTS When using this method, only one device can be connected to the 12V Z1 GND Z2 Z3 GND Z4 Z5 input. - Page 16 INSTALLATION MANUAL AIOM 10-Input/10-Output Module Single with WIRE SHORT and WIRE CUT Supervision INPUTS (Limit of 1 Detection Device on the Input) 12V Z1 GND Z2 Z3 GND Z4 Z5 When using this method, only one device can be connected to the input.
-
Page 17: Connecting Outputs
INSTALLATION MANUAL AIOM 10-Input/10-Output Module Connecting Outputs The ATRIUM 10-Input/10-Output Module can control up to 10 devices such as garage doors, lights, air conditioning, heating systems, blinds, pumps, locks, etc. Devices requiring/using 100mA or less @ 12Vdc may be directly connected to the outputs. Outputs can be configured as normally open (deactivated) or normally closed (activated);... -
Page 18: Led Indicators
INSTALLATION MANUAL AIOM 10-Input/10-Output Module LED Indicators The ATRIUM 10-Input/10-Output Module has several status LEDs that are very useful to diagnose problems when using or installing the ATRIUM system. Refer to the following picture for the emplacement of those LEDs on the ATRIUM 10-Input/10-Output Module. -
Page 19: Connecting The 10-Input/10-Output Module To The Atrium 2-Door Controller
INSTALLATION MANUAL AIOM 10-Input/10-Output Module Connecting the 10-Input/10-Output Module to the ATRIUM 2-Door Controller The 10-Input/10-Output Module has a RS485 LOCAL BUS terminal allowing the connection with the ATRIUM 2-Door Controller, up to 1220m (4000ft). Connect the module’s to the ATRIUM 2-Door Controller’s LOCAL BUS using Bus, star and/or daisy chain topologies. -
Page 20: Warranty - Terms & Conditions
CDVI or a local CDVI subsidiary. The “5 Year Warranty” is only applicable to hidden defects detected during the lifetime of the product, as defined by the CDVI Group (5 years or 200 000 operations - whichever of the two expires first). - Page 21 INSTALLATION MANUAL AIOM 10-Input/10-Output Module NOTES: cdvigroup.com...
- Page 22 INSTALLATION MANUAL AIOM 10-Input/10-Output Module NOTES: cdvigroup.com...
- Page 23 INSTALLATION MANUAL AIOM 10-Input/10-Output Module NOTES: cdvigroup.com...
- Page 24 Reference : G0301FR0429V01 Extranet : EXE-CDVI_IM AIOM CMYK A4 EN 01 *G0301FR0429V01* CDVI Group FRANCE (Headquarter/Siège social) Phone: +33 (0)1 48 91 01 02 Fax: +33 (0)1 48 91 21 21 CDVI CDVI FRANCE + EXPORT IBÉRICA Phone: +33 (0)1 48 91 01 02...
