Rightline Gear 110M10 Quick Start Manual

Truck Bed Air Mattress
QR
Set Up
www.rightlinegear.com/setup.html
CODE
Video:
NOTE: IT IS RECOMMENDED TO KEEP THE MATTRESS
INFLATED FOR SEVERAL HOURS BEFORE INITIAL
USE. THE MATTRESS'S MATERIAL WILL STRETCH DUR-
ING THIS TIME AND ADDITIONAL AIR WILL BE RE-
QUIRED TO RETURN THE MATTRESS TO ITS DESIRED
FIRMNESS. THE LOSS OF AIR BEFORE INITIAL USE IS
NORMAL AND DOES NOT MEAN THE MATTRESS IS
LEAKING.

Inflate The Air Mattress

1-
Lay the air mattress over a flat area, free from rocks
and sticks (Fig 1). Make sure the mattress is completely
unfolded and its flocked side is facing up (Fig 2).
Fig 1
WARNING: THE AIR PUMP'S POWER SUPPLY MUST
BE A VEHICLE'S 12 VOLT DC OUTLET.
2-Attach the large adaptor to the inflation port on the side
of the air pump (Fig 3).
3-Insert the air pump's charge plug into the vehicle's 12
volt DC outlet (Fig 4).
Fig 3
WARNING: DO NOT LEAVE THE PUMP UNATTENDED
WHILE OPERATING. DO NOT ALLOW THE PUMP TO
GET WET OR KEEP IT RUNNING FOR OVER 15 MIN-
UTES. DO NOT OBSTRUCT THE INFLATION AND DE-
FLATION PORTS. DO NOT ALLOW SMALL DEBRIS TO
BE SUCKED INTO THE INFLATION OR DEFLATION
PORTS.
110M10, 110M60
Flocked
Side
Fig 2
Fig 4
4-Place the adaptor into the mattress's easy inflate valve's
opening (Fig 5). The adaptor will push the valve open.
Power the air pump on (Fig 6).
Fig 5
5-Inflate the mattress to the desired firmness, turn the air
pump off, and remove the adaptor from the opening. The
air pressure inside the mattress will push the valve closed.
Screw the cap over the easy inflate valve's opening (Fig
7).
6-Use the mouth valve to inflate the mattress if the air
pump is unavailable (Fig 8).
Fig 7
7-Place the mattress between the wheel wells of the truck
bed (Fig 9) with its flocked side facing up and its valve
side facing the rear of the truck.
Fig 9
8-Store your gear between the mattress and the bed walls
(Fig 10).
Fig 10
Fig 6
Fig 8
