- Page 1 Model No. JA2000J Installation, Operation and Parts Manual Jack Manual or Pneumatic Release Lifting Capacity 2000KG ORIGINAL Distributed by Please read this entire manual carefully and completely before installation or operation of the jack.
- Page 2 Installation, operation and parts manual JA2000J INDEX 1. Important safety instructions………………………….…………………….…3~4 1.1 Important notices 1.2 Qualified personnel 1.3 Danger notices 1.4 Warnings 2. Overview of the lift………………………………………………………….……..5~6 2.1 General descriptions 2.2 Safety construction 2.3 Construction of the jack 2.4 CE and name plate 2.5 Optional parts...
-
Page 3: Important Safety Instructions
Users must always bear in mind that this jack is specially designed for lifting cars or other vehicles, so never use it for any other purposes. Otherwise, Jema Autolifte and as well as our distributors, will not bear any responsibility for accidents or damages of the product. - Page 4 Installation, operation and parts manual JA2000J 1.4 Warnings 1.4.1 Always keep a close eye on how that can be possible to turn heads when you're under the vehicle to prevent injury. 1.4.2 It is forbidden to stand on the jack or use it for anything other than the designated purpose.
- Page 5 To meet user needs, Jema Autolifte developed 3 different jack models in our Basic line series. Model 1: Hydraulic pneumatic pump...
- Page 6 Installation, operation and parts manual JA2000J 2.3 Construction of the lift 1. Beam 2.Base 3.Moving bracket 4.Supporting frame 5.Pneumatic pump 6.Oil cylinder 2.4 CE and name plate Check the maximum Capacity and air pressure on the rating plate on the jack. Do NOT lift beyond max lift capacity under no circumstances when use of the jack.
-
Page 7: Installation Instructions
Installation, operation and parts manual JA2000J INSTALLATION INSTRUCTIONS 3.1 Preparations before installation Appropriate lifting equipment 14# open spanner 3.2 Precautions for installation 3.3 Installation instructions Step1: Take the jack out of the transport box Step2: Use proper lifting tools to have the jack placed onto the lift. - Page 8 Installation, operation and parts manual JA2000J (Hydraulic pneumatic) JA2000J-AIR: Connect the air hose (It is only necessary to jack with pneumatic hydraulic pump) air-in connector pneumatic pump bleed valve The end user need to prepare ￠8mm air hose. Length of the hose is decided by practical use.
- Page 9 3. JA2000J-AIR: Press the lever on air hydraulic pump to lift the jack. 4. JA2000J-AIR: When the jack has reached the desired height press return valve on the air hydraulic pump to make sure the jack goes into the safety lock before the user begins his work on the vehicle.
- Page 10 Installation, operation and parts manual JA2000J Lower the jack 1. JA2000J-AIR: Press the lever on air hydraulic pump to lift jack off the safety lock. 2. Pull the unlocking handle. 3. JA2000J-AIR: Press on return valve on the pump and the jack is lowering.
-
Page 11: Troubleshooting
Installation, operation and parts manual JA2000J TROUBLE SHOOTING ATTENTION: If the trouble could not be fixed by the user, please do not hesitate to contact the distributor for help .We will offer our service at the earliest time we can. Troubles will be judged and solved much faster if more details or pictures can be provided. -
Page 12: Maintenance
MAINTENANCE By complying with the statutory servicing can be sure your Jema Autolifte jack will operate safely and with minimal maintenance. Jema Autolifte jack should be made mandatory servicing 1 annually - You can contact your Jema Autolifte distributor service department. - Page 13 Installation, operation and parts manual JA2000J ANNEX Annex1, Overall dimension 1. JA2000J-AIR...
- Page 14 Installation, operation and parts manual JA2000J Annex2, Hydraulic system...
- Page 15 Installation, operation and parts manual JA2000J Annex3, Separated drawings...
- Page 16 Installation, operation and parts manual JA2000J Material # Name Specification (drawing#) Note 204101005 Flat washer 615028017 Protection cloth 60*65 410280291 Shaft of oil cylinder CJ-A12-B5-C2 203103006 Non-metallic lock nut 612028003 Safety rack assembly CJ-A12-B5-C4 208101003 Brake cable Rubber L1=940，steel cable L2=1080...
- Page 17 Installation, operation and parts manual JA2000J Material # Name Specification (drawing#) Note 615028002 Pneumatic pump JA2000J-AIR 615028001 CJ-A12-B9 614028020 Supporting frame A CJ-A12-B6-C1 420280010 Sheath CJ-A12-B6-C4 202111004 Inside hex sunken head screw M8*12 614028015 Welded square tube A CJ-A12-B1-C2 614028014...
- Page 18 Installation, operation and parts manual JA2000J 207104004 U-shape ring KD50*40*10 207105012 Anti-dust ring DHS30(30*38*516.5) 207101023 O-shape ring 40*5.3 207101024 O-shape ring 23.6*3.55 207101025 O-shape ring 48.7*3.55 207106009 Anti-abrasion ring BS50703-0500A-47 207106010 Anti-abrasion ring BS50703-0300C-47 208101003 Blake cable Rubber L1=940，steel cable L2=1080...
- Page 19 Installation, operation and parts manual JA2000J Declaration of Conformity (Manufacturer’s Declaration) We: Jema Autolifte CO., LTD - Lixianzhuang Industrial Zone, Shangma, Chengyang, Qingdao, Shandong, 266000, P.R.China declare in sole responsibility that the equipment Vehicle Lift JA2000J. to which this declaration applies, complies with these normative...
