IONIZING
AIR BLOWER
MODEL:QUICK442
INSTRUCTIONS
Operation/Maintenance BLOWER OVERHEAD Ionizing Air Blower
The Ionizing AIR BLOWER (OVERHEAD) is a member of the ionizing air blower
family. The BLOWER OVERHEAD is a two-Fan unit designed to provide targeted
coverage for electrostatic problems.
MATTERS FOR DAILY INSPECTION
*Clean high voltage needles
*Verify grounding connection
*Inspect equipment for damage
*Inspect for moisture or other contaminates
SECTION 1 Description
SECTION 2 Features
SECTION 3 Specifications
SECTION 4 Safety
SECTION 5 Installation
SECTION 6 Operation
SECTION 7 Maintenance
Advertisement
Table of Contents
Summary of Contents for Simco OVERHEAD Series
- Page 1 IONIZING AIR BLOWER MODEL:QUICK442 INSTRUCTIONS Operation/Maintenance BLOWER OVERHEAD Ionizing Air Blower The Ionizing AIR BLOWER (OVERHEAD) is a member of the ionizing air blower family. The BLOWER OVERHEAD is a two-Fan unit designed to provide targeted coverage for electrostatic problems. MATTERS FOR DAILY INSPECTION *Clean high voltage needles *Verify grounding connection...
-
Page 2: Section 1 Description
SECTION 1 Description The BLOWER OVERHEAD ionized air blower produces an air flow that is rich in positive and negative ions. Directing the air flow on an object that has a static electricity charge will neutralize the charge. If the object has a negative static charge, it will draw positive ions from the air flow. -
Page 3: Section 3 Specifications
* Covers an extended distance and large area coverage with ionized air. * Variable speed fan with wide range of air flow. * Integrated task lights (9 watt twin tube) * Inherently balanced ion output. * Expediently ion emitter cleaner. * Ionization indicator lamp. - Page 4 Finish: Acrylic Enamel Weight: 7.0 kg Size: 63 cm(L) x 9.0 cm(H)x17 cm(W) Bench Stand Feet: Nonconductive, Nonstaining Polymer Optional Air Filter: 30 PPI Open Cell Polyurethane Foam Ion Balance (offset voltage): OV ±15V Lamp: 9 watt twin tube Ion Output(discharge time: S) 300mm 300mm 300mm...
-
Page 5: Section 4 Safety
SECTION 4 Safety 1. Read instruction manual before installing or operating device. 2. This unit is equipped with a 3-prong grounding plug and must be plugged into a 3-terminal grounded receptacle. Do not defeat the grounding by modifying the plug or using an ungrounded 3-prong adapter, If an extension cord is necessary, use only a 3-wire extension cord that provides grounding. -
Page 6: Section 6 Operation
down the edge of fixture slightly, so that the fixture will be locked in. Note: Make figures of the fixture and the shield superposed. Keep the arrowhead adown. SECTION 6 Operation Put the plug of power into the socket and turn on the power switch, the air blower start working. - Page 7 Discharge times can be measured and checked against the Ion Output tables in Section3, Specifications. If a charged plate monitor is not available, but a static meter such as a SIMCO handheld electrostatic field meter SHISHIDO electrostatic Analyzer or warmbier charged plate monitor is available, ion output may be checked with the following procedure.
- Page 8 Ion Balance Check To test the unit for ion balance, the use of a charged plate monitor such as the SIMCO Electrostatic Analyzer H0601(SSD) or cpm374(Warmbier) is recommended. Offset voltage should be measured and checked against the Ion Balance in Section 3, Specifications.
-
Page 9: Section 8 How To Hang
SECTION 8 How to hang...
