- Page 1 USER'S MANUAL LAARMANN LM2000 Edition Month Year January 2019...
-
Page 2: Table Of Contents
6.2 Starting the milling process ......................15 6.3 Stopping the milling process ....................... 15 7. TROUBLESHOOTING .......................... 16 8. MAINTENANCE ..........................16 8.1. WEAR ............................16 8.2. CLEANING ........................... 16 9. PARTS LIST LAARMANN LM2000 ....................... 17 10. CE CERTIFICATE ..........................21... -
Page 3: Safety Information
Transport Do not knock, shake or throw the LM2000 during transport. Otherwise the electronic and mechanical components may be damaged. Packing material Please keep the packing material for the duration of the guarantee period. - Page 4 Milling of materials, which give a risk of fire or explosion, is prohibited. Cleaning Do not clean the LM2000 under running water. Danger to life through electric shock. Use only a soft cloth moistened with water. Cleaning agents and solvents should not be used, not for cleaning the milling tools either.
-
Page 5: General Description
The closed milling pulverizing system guarantees complete recovery of the samples. Final finenesses of down to 20-40 μm can be achieved, depending on the milling time and the specific properties of the sample material. The optimum filling of a LM2000 is around 1-1.3 Liters of sample material. -
Page 6: Technical Features
MANUAL LM2000 3. TECHNICAL FEATURES 3.1. CONSTRUCTION The housing of LM2000 is made of steel plate with powder coated RAL5005 paint. Protective equipment The milling chamber of the LM2000 is safely closed by an electrical safety switch. Starting of the machine is possible only when: power is connected;... -
Page 7: Installation
4.3. CONNECTING THE POWER CORD The correct voltage and frequency for the LM2000 are given on the name plate. Ensure that these values correspond to the available power supply system. To avoid interference from noise, surges and spikes, a dedicated line is preferred. If no such line is available, avoid lines to which powerful electric motors, refrigerators and similar devices are connected. -
Page 8: Environment Conditions
MANUAL LM2000 4.4. ENVIRONMENT CONDITIONS The machine has been built for operating in laboratory environment. Therefore the environmental conditions should be the following: - Temperature from +5C to +40C - Humidity up to 85% RH, non-condensing... -
Page 9: Instructions For Use
MANUAL LM2000 5. INSTRUCTIONS FOR USE 5.1. OVERALL VIEW The LM200 has a couple new features: • An improved air bellow system o The old machine released the bellow into rest position, in some cases this meant that the bowl can’t be easily removed as the air bag was in the way. -
Page 10: Instructions For Use
If you experience errors please proceed to step 6. You can also have the controls in your own language, please contact LAARMANN for the options. Once bought your nations flag will appear next to the British flag and you can press it to switch languages. - Page 11 MANUAL LM2000 to remove the Bowl from the machine. H/M/S count the passed time, these number can’t be adjusted If you press exit, you will go back to the start screen. The hand control is mostly used for system checks and short milling.
- Page 12 MANUAL LM2000 Here you see the overview of the automatic system starting screen. Here you will see the selected parameters and are able to start the machine for use. The machine will automatically pressurize the bowl and start the program.
- Page 13 MANUAL LM2000 Here you see the number pad. In case of this message, please close the hood an press “lock the Lid”. If this message comes up when the lid is closed and you have pressed “lock the Lid” carefully check if you can open the hood or not.
- Page 14 MANUAL LM2000 In case of this message, please check the pressure coming from the supply. The pressure should be around 7-8 to ensure smooth operation. Also check if there is no air escaping within the system. Open the side panel with the...
-
Page 15: Working Instructions
MANUAL LM2000 6. WORKING INSTRUCTIONS 6.1. GENERAL The LM2000 is a high performance product. It is used mainly in the processing minerals. 6.2 Starting the milling process • Set the parameters as described before • Open the lid of the machine and put in the sample on top of the puck in the bowl •... -
Page 16: Troubleshooting
Before cleaning the machine, unplug the mains cord from wall socket. Use only a soft cloth moistened with water. Cleaning agents and solvents should not be used, not for cleaning the milling tools either. Do not clean the LM2000 under running water. Danger to life through electric shock. -
Page 17: Parts List Laarmann Lm2000
MANUAL LM2000 9. PARTS LIST LAARMANN LM2000 D E TA IL B Fig.1: LM2000 internal parts... - Page 18 MANUAL LM2000 ITEM Description Specification Subassembly frame 20120025-31-00 Subassembly bearing plate 20120025-32-00 Subassembly motor plate 20120025-33-00 Subassembly cover 20120025-34-00 Weld assembly clamping table 20120029-01-00 Cover shaft 20120025-35-01 Weight 20120025-36-01 Bearing shaft 20120025-37-01 Bushing 20120025-38-01 Mounting plate 20120029-02-01 Dowel 20120029-03-01 Electric motor...
- Page 19 MANUAL LM2000...
- Page 20 MANUAL LM2000 Fig.3: LM2000 Toolboy ITEM Description Specification Support M0006-20-00 Turntable M0006-03-00 Pivot M0006-04-01 Lifting arm M0006-15-00 Shaft M0006-06-01 Cradle assembly M0006-07-00 Airbagclamp Chain Mounting bracket filter reg. (not in picture) M0006-08-01 G1\4" 5mic. 0-12bar type: Filter regulator (not in picture)
-
Page 21: Ce Certificate
All supply voltages and frequencies as stated on the rating plate must be used. External power cables and connectors must be supplied by LAARMANN. Any additional equipment used must be of a type approved by LAARMANN. This conformity certificate will lose its validity in case of: •...
