Pickup Installation - Tune-o-matic Bridge
1. Check and make a note of the height of your outside strings using an
accurate 6 inch scale (ruler). You will want to know this later in step 6.
2. Remove the strings and bridge, being careful not to allow the bridge
to fall off and damage your guitar.
3. Slip the metal bracket over the bared posts, with the "bump" oriented
towards the low E string side of the guitar.
4. Place the bridge assembly over the bracket and posts (Fig 7).
5. Restring your guitar.
6. Adjust the bridge's height until the action matches your measured
height from step 1.
7. Attach the slimmest of the plastic pickup mounting pads to the pickup,
but don't remove the pad's adhesive backing yet. Slide the pickup and
mounting pad between the bracket and the strings. The strings should
almost, but not quite, touch the top of the pickup. If there's too much
space, try one of the thicker brackets.
8. Remove the adhesive backing from the mounting pad that fits best.
Slide the mounting pad beneath the strings, care- fully positioning it
flush against the surface of the metal bracket. Press firmly to secure it
well.
9. Slide the pickup into place.
10. Proceed to the Fine adjustments section.
