FREEDOM Modular Sport Rack Assembly Instructions
ICD Design, LLC is not responsible for any damage that may occur during installation.
This is a general assembly manual and may vary by the Gladiator's versions and options. Please consult our technical department for more information and
assistance.
PARTS:
✓ 2 Cross Bars
✓ 4 Base Legs
✓ Hardware:
2020 Jeep Gladiator JT
:
16 each. Carriage Bolt 3/8"-16 X 1.0" long, Zinc plated steel, grade 5
16 each. Lock nut, 3/8"-16, Zinc plated steel, grade 5
16 each. Flat Washer, 3/8"-16, Zinc plated steel, grade 5
Mounting to Truck Bed:
8 each. Hex Head Bolt 3/8"-16 X 1.0" long, Zinc plated steel, grade 5
8 each. Lock nut, 3/8"-16, Zinc plated steel, grade 5
8 each. Flat Washer, 3/8"-16, Zinc plated steel, grade
8 each. Rivet Nuts, 3/8"-16
Advertisement
Table of Contents
Summary of Contents for ICD HOBBS FREEDOM
- Page 1 2020 Jeep Gladiator JT ICD Design, LLC is not responsible for any damage that may occur during installation. This is a general assembly manual and may vary by the Gladiator’s versions and options. Please consult our technical department for more information and assistance.
- Page 2 On a regular basis and especially if you do a lot of off-roading, inspect and tighten any loose bolts. For Technical Support, please call (702) 560-2451 or email: info@icddsign.com HOBBS is a brand name of ICD DESIGN, LLC. 2620 Regatta Drive, Suite 102, Las Vegas, Nevada 89128, USA Tel: (702) 560-2451 Email: info@icddesign.com Website: www.icddesign.com...
