ITEM # 343-8180
If you are missing parts or have any questions about this product, contact our customer service representative first!
You can also order parts by writing to the address listed below. Please include the product model number, color and a
detailed description of the part.
*
Failure to follow these warnings and assembly instructions could result in serious injury or death.
*
Read all instructions before assembling crib. KEEP INSTRUCTIONS FOR FUTURE USE.
*
Before each usage or assembly, inspect crib for damaged hardware, loose joints, missing parts or sharp edges,
DO NOT use crib if any parts are missing or broken. Ask your dealer or write to our customer service
representative (address & phone number shown above) for replacement parts and instructional literature if
needed. DO NOT substitute parts.
*
Infants can suffocate on soft bedding. Never add a pillow or comforter. Never place additional padding under
an infant.
*
When child is able to climb out or reaches the height of 35 inches (90 cm), the crib shall no longer be used.
*
To reduce the risk of SIDS, pediatricians recommend healthy infants be placed on their backs to sleep, unless
otherwise advised by your physician.
DO NOT place crib near window where cords from blinds or drapes may strangle a child.
*
*
Strings can cause strangulation! DO NOT place crib with a string around a child's neck, such as hood strings
or pacifier cords. DO NOT suspend strings over a crib or attach strings to toys.
*
To help prevent strangulation tighten all fasteners. A child can trap parts of the body or clothing on loose
fasteners.
If refinishing, use a non-toxic finish specified for children's products.
*
*
When child is able to pull to standing position, set mattress to lowest position and remove bumper pads, large
toys and other objects that could serve as steps for climbing out.
*
Never use plastic shipping bags or other plastic film as mattress covers because they can cause suffocation.
DO NOT use a water mattress with this crib.
*
Replace teething rail if damaged or loose (if teething rail is provided for this model).
*
*
CAUTION: ANY MATTRESS USED IN THIS CRIB MUST BE AT LEAST 27-1/4 INCHES BY 51-5/8 INCHES
(69CM BY 131CM) WITH A MINIMUM THICKNESS OF 4 INCHES (10CM) BUT NOT EXCEEDING 6 INCHES
(15CM).
Infants can suffocate in gaps between crib sides and a mattress that is too small.
*
*
Follow warnings on all products in a crib.
WARNING ENTRAPMENT / STRANGULATION HAZARD:
* Infants have died in toddler beds from entrapment and strangulation.
* NEVER use bed with children under 15 months.
* NEVER place bed near windows where cords from blinds or drapes may strangle a child.
*
The TODDLER BED or DAY BED is not intended for children under 15 months of age or over 50 pounds
*
If guardrails are used as the mattress containment means, guardrail(s) provided must be used to avoid the
formation of a gap between the mattress and the bed that could cause an entrapment (when product is used as
a TODDLER BED or DAY BED).
*
DO NOT place DAY BED or TODDLER BED near windows where cords from blinds or drapes may strangle a
child.
*
DO NOT place items with a string, cord, or ribbon around a child's neck, such as hood strings or pacifier cords.
*
DO NOT suspend strings over a TODDLER BED or DAY BED for any reason.
CUSTOMER SERVICE
CALL 1-800-295-1980
Customer Service Department No. 413
12345 Albert-Hudon Boulevard, Suite 100
Montreal, Quebec
Canada H1G 3L1
E-MAIL: csr@jardcoent.com
WARNING
MODEL#: DA707BC-C/NC
DA707BC-H (Honey Pine),
DA707BC-W/NW
(Cherry),
(White)

Advertisement

loading

Summary of Contents for Jardine DA707BC-C

  • Page 1 MODEL#: DA707BC-C/NC (Cherry), ITEM # 343-8180 DA707BC-H (Honey Pine), DA707BC-W/NW (White) CUSTOMER SERVICE If you are missing parts or have any questions about this product, contact our customer service representative first! CALL 1-800-295-1980 You can also order parts by writing to the address listed below. Please include the product model number, color and a detailed description of the part.
  • Page 2: Care And Cleaning

    Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Jardine Enterprise warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. This warranty is valid only upon presentation of proof of purchase.
  • Page 3: Hardware And Part List

    ASSEMBLY INSTRUCTION FOR "343-8180"CRIB DA707BC-C/NC (Cherry),DA707BC-H (Honey Pine), DA707BC-W/NW(White) HARDWARE AND PART LIST BOLT 3-1/4"×1/4"DIA 12PCS BOLT 2"×1/4"DIA 4PCS 1/2"×1/4"DIA BOLT 2"×1/4"DIA 2PCS MATTRESS SUPPORT BOLT 16PCS 0.3805"×0.1785"DIA RUBBER BUMPER 2PCS MACHINE SCREWS 2PCS RIGHT(H2) 1PC LEFT(H1) 1PC SMALL ALLEN WRENCH 4MM 1PC...
  • Page 4 ASSEMBLY INSTRUCTION FOR "343-8180"CRIB DA707BC-C/NC (Cherry),DA707BC-H (Honey Pine), DA707BC-W/NW(White) Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts, which may have come loose inside the carton during shipment. Identify and count all parts and compare with the parts list below.
  • Page 5 ASSEMBLY INSTRUCTION FOR "343-8180"CRIB DA707BC-C/NC (Cherry),DA707BC-H (Honey Pine), DA707BC-W/NW(White) STEP. 3 ATTACH THE TOP RIGHT PANEL (PART H2) TO THE RIGHT SIDE FRAME USING BOLTS (PART B) AND WRENCH (PART G) PROVIDED. REPEAT THIS STEP FOR THE TOP LEFT PANEL (PART H1) AND THE LEFT SIDE FRAME (PART I1).
  • Page 6 ASSEMBLY INSTRUCTION FOR "343-8180"CRIB DA707BC-C/NC (Cherry),DA707BC-H (Honey Pine), DA707BC-W/NW(White) STEP 4: Attach the mattress support to the 4 corner posts with the mattress support bolts (D). Use Allen Key to tighten bolts. Refer to details 1 and 2 for direction on how to properly attach the mattress support.
  • Page 7 ASSEMBLY INSTRUCTION FOR "343-8180"CRIB DA707BC-C/NC (Cherry),DA707BC-H (Honey Pine), DA707BC-W/NW(White) STEP 5 ALIGN AND SLIDE DROP SIDE FROM THE BOTTOM ONTO THE DROP SIDE UPPER AND LOWER TRACKS ON THE LEFT AND RIGHT FRONT POSTS. MAKE SURE THE RELEASE LATCH ON THE LOWER GUIDES IS TO THE OUTSIDE OF THE LOWER DROP SIDE TRACKS (PULL TOWARDS YOU).
  • Page 8: Starting From Scratch

    DAY BED WARNINGS: 1. ANY MATTRESS USED IN THIS DAY BED MUST BE AT LEAST 27-1/4" × 51-5/8" (69CM × 131CM) WITH A MINIMUM THICKNESS OF 4" AND NOT EXCEEDING 6" (15CM). 2. THE DAY BED IS INTENDED FOR USE BY A CHILD NOT LESS THAN 15 MONTHS OF AGE AND WHO WEIGHS NO MORE THAN 50LBS (27.7KG) NOTE: WHEN INSERTING SCREWS, TURN CLOCKWISE UNTIL TIGHT, THEN LOOSEN 1/2-3/4 OF A TURN, AFTER CRIB IS COMPLETELY ASSEMBLED, RETURN TO EACH...
  • Page 9 BED "FULL SIZE" THIS CRIB CAN BE CHANGED TO A FULL SIZE BED. USING HEADBOARD (L) TO ATTACH PURCHASED FULL SIZE BED FRAME (NOT PROVIDED) AT THE LOCATION SHOWN IN DIAGRAM A1. DIAGRAMA1 IMPORTANT: STORE AWAY ALL EXTRA PARTS TO THIS "CRIB", "DAY BED", OR "FULL SIZE HEADBOARD "...
