DEAR CUSTOMER:
Thank you for buying this product !
Prior to first use, please read the manual carefully.
NOTE: 1. This unit is set on 2.1 mode upon startup, please press the 5.1/2.1
button for 5.1 surround sound.
2. To properly connect MP3,PC, you must use the enclosed 3.5 mm to RCA cable.
Front panel
1. -VOLUME+
2. /TUNING+
3. /TUNING-
4. ST-BY/
5. SOURCE
ST-BY/ Press to turn on speaker, long press into stand-by. PLAY/PAUSE
on the USB/SD/BL mode.
SOURCE Change the input mode.
-VOLUME+ Volume Up/Down
TUNING+/NEXT
Press once to increase the FM frequency 0.1M,long
press to the semi-automatic search for radio/Next track
in USB/SD/BL device
TUNING-/PREVIOUS
track in USB/SD/BL device
B52
(4)
ST- BY/ / TUNING +
(5)
SOURCE / TUNING -
Press once to reduce the FM frequency 0.1M,long
press to semi-automatic search for radio/Previous
NO.2
Operation explanation:
700 Watts Total Power
Drive Units: 3" x 5 full range magnetically shielded satellite
speakers + 5.25" powered subwoofer
~120V 60Hz
Features:
Ÿ
Quality 5.1 speaker system with built-in amplifier
Ÿ Full audio spectrum performances, ideal for your favourite entertainment
from Mp3, Mp4, CD/DVD movies and digital playbacks
Ÿ Specially designed woofer cabinet for bass and resolution
Ÿ Comes with remote control and RCA cables
Package contents:
subwoofer cabinet
satellite speakers
remote control
User manual
RCA CABLE
3.5 mm RCA CABLE
FM ANT
How to use the remote control
5. 1/2.1
(1)
(2)
(3)
1.Start the main unit by pressing ST-BY.
2.Choose DVD input mode by pressing DVD.
3.Choose AUX input mode by pressing AUX.
4.Choose FM input mode by pressing FM.
5.Choose USB/SD input mode by pressing USB/SD.
6.Adjust the master volume by pressing VOL+/- at the rage of 0-30dB.
7.FRONT: To select the Front Speakers.The output level can then be
adjusted using the volume (up/down) keys.
8.SUB: To select the sub Speakers.The output level can then be adjusted
using the volume (up/down) keys.
9.SURR: To select the rear speakers.The output level can then be adjusted
using the volume (up/down) keys.
10.CENTER: To select the center speaker.The output level can then be
adjusted using the volume (up/down) keys.
W170xH312xD336(mm)
W105xH172xD112(mm)
1 pc
5 pcs
1 pc
1 pc
1 pc
1 pc
1 pc
NO.1
5.1/2. 1
NO.3
