- Page 1 Instruction Manual RS232 Ethernet Converter for colorSENSOR LT-1-LC-20 OT-3-MA MICRO-EPSILON Eltrotec GmbH LT-3-HE OT-3-GL Manfred-Wörner-Straße 101 · 73037 Göppingen / Germany LT-3-LU OT-3-HR Tel. +49 (0) 7161 / 98872-300 · Fax +49 (0) 7161 / 98872-303 OT-3-LD eltrotec@micro-epsilon.de · www.micro-epsilon.com...
- Page 2 RS232 Ethernet Converter for colorSENSOR MICRO-EPSILON Eltrotec GmbH Manfred-Wörner-Straße 101 73037 Göppingen / Germany Tel. +49 (0) 7161 / 98872-300 Fax +49 (0) 7161 / 98872-303 e-mail eltrotec@micro-epsilon.de www.micro-epsilon.com Certified acc. to DIN EN ISO 9001: 2008...
-
Page 3: Table Of Contents
Contents Safety ............................5 Symbols Used ..............................5 Warnings ................................5 Notes on CE Identification ..........................6 Proper Use ............................... 6 Proper Environment ............................7 Functional Principle, Technical Data ..................7 Short Description ............................. 7 Structure of the System ........................... 8 Functions ................................. - Page 4 RS232 Ethernet Converter...
-
Page 5: Safety
Safety Safety The handling of the system assumes knowledge of the instruction manual. Symbols Used The following symbols are used in the instruction manual. Indicates a hazardous situation which, if not avoided, may result in death or serious CAUTION injuries. Indicates a hazardous situation which, if not avoided, may result in minor or moderate NOTICE injuries. -
Page 6: Notes On Ce Identification
Products which carry the CE mark satisfy the requirements of the EMC regulation 2004/108/EC ‘Electromag- netic Compatibility’ and the European standards (EN) listed therein. The EC declaration of conformity is kept available according to EC regulation, article 10 by the authorities responsible at MICRO-EPSILON Eltrotec GmbH Manfred-Wörner-Straße 101 73037 Göppingen / Germany... -
Page 7: Proper Environment
Functional Principle, Technical Data Proper Environment - Protection class: IP 50 - Operating temperature: -25 °C ... +65 °C (-13 ... +149 °F) - Storage temperature: -25 °C ... +65 °C (-13 ... +149 °F) - Humidity: 20 - 80 % relative humidity (non-condensing) - Ambient pressure: Atmospheric pressure - EMC: Acc. -
Page 8: Structure Of The System
Functional Principle, Technical Data Structure of the System Attachment options 4-pin. connectorRundstecker Binder series 707 PUR cable 2x duo LED green/orange: LED yellow: Ethernet activity and status LED Serial activity LED (RxD) LED yellow: Aluminum RJ45 Ethernet Serial activity LED (TxD) housing, interface- anodized in blue... -
Page 9: Technical Data
Functional Principle, Technical Data Technical Data RS232 Ethernet converter Model CAB-M5-4P-St-ge; 2m-PVC; RJ45-Bu-Eth Power supply +12 VDC ... +30 VDC Current consumption max. 200 mA Data rate 9600 Baud, 19200 Baud, 38400 Baud Operating temperature -25 °C ... +65 °C (-13 ... +149 °F) Storage temperature -25 °C ... -
Page 10: Delivery
Delivery Delivery Unpacking 1 RS232 Ethernet converter 1 Instruction manual 1 CD including “Deviceinstaller“ Check the delivery for completeness and shipping damage immediately after unpacking. In case of damage or missing parts, please contact the manufacturer or supplier. You will find optional accessories in appendix, see Chap. Storage Storage temperature: -25 - + 65 °C (-13 ... -
Page 11: Mounting
Mounting Mounting RS232 Ethernet Converter 0.5 x 45° (.02 all around circumferential) 70 (2.76) ø 4.5 (.18 dia. (4x)) (.12) Fig. 1 Dimensional drawing CAB-M5-4P-St-ge; 2m-PVC; RJ45-Bu-Eth Dimensions in mm, not to scale RS232 Ethernet Converter Page 11... -
Page 12: Mounting Steps
Mounting Mounting Steps Connect a sensor of the colorSENSOR OT series to the 4-pin connector Binder series 707 of RS232 Ethernet converter. Now connect a LAN cable with RJ45 connector to the Ethernet port on the PC. Now start the PC. PUR cable with 4-pin. -
Page 13: Pin Assignment
Mounting Pin Assignment Assignment +24 VDC (+Ub, OUT) GND (0 V) Fig. 3 Assignment 4-pin. connector Binder series 707 View on solder pin side male cable connector RS232 Ethernet Converter Page 13... -
Page 14: Leds On Converter
Mounting LEDs on Converter Fig. 4 Display elements on converter Fig. 5 View on Ethernet interface on converter Color Designation Meaning yellow Serial activity LED / receive data yellow Serial activity LED / send data 2x duo LED green/orange - Ethernet activity and status LED RS232 Ethernet Converter Page 14... -
Page 15: Warranty
The warranty period lasts 12 months following the day of shipment. Defective parts, except wear parts, will be repaired or replaced free of charge within this period if you return the device free of cost to MICRO-EPSILON Eltrotec. This warranty does not apply to damage resulting from abuse of the equipment and devices, from forceful handling or installation of the devices or from repair or modifications performed by third parties. -
Page 16: Appendix
Appendix | Optional Accessories Appendix Optional Accessories Designation Description Article number CAB-RJ45-Eth; 2m-PVC-Cat5e; RJ45-Eth Ethernet connection cable, 2 m long 11294232 CAB-RJ45-Eth; 5m-PVC-Cat5e; RJ45-Eth Ethernet connection cable, 5 m long 11293257 CAB-RJ45-Eth; 10m-PVC-Cat5e; RJ45-Eth Ethernet connection cable, 10 m long 11293702 CAB-RJ45-Eth;... - Page 17 Appendix | Software Fig. 6 Screen Download Deviceinstaller RS232 Ethernet Converter Page 17...
