Summary of Contents for Deister electronic Logident UDL 250
- Page 1 UDL 250 Long Distance Reader Wiring and Installation Instructions V14/05/09 #896108...
- Page 2 GmbH. deister electronic GmbH reserves the right to make changes to any and all parts of this documentation without obligation to notify any person or entity of such changes.
-
Page 3: Table Of Contents
Wiring and Installation UDL 250 Contents 1. General Information...........4 2. Technical Data............5 3. Mechanical Dimensions..........6 3.1 UDL 250 Housing − Side View................6 3.2 UDL 250 Housing − Front View................6 3.3 UDL 250 Housing − Rear View................7 4. Wiring Diagram............8 4.1 Pin Assignment....................8 5. -
Page 4: General Information
Wiring and Installation UDL 250 1. General Information The UDL 250 is a compact long distance reader of the UHF type with an integrated antenna. The frequency range is factory-set and depends on allowed regulations for the particular region (see also “Transmission Frequency” in chapter 1. “Technical Data”). The UDL 250 has been specially developed for contactless identification of objects within a reading range up to 4 m. -
Page 5: Technical Data
Wiring and Installation UDL 250 2. Technical Data Dimensions: mm (inch) W x H x D 278 x 238 x 86 (10.9 x 9.4 x 3.4) Weight: kg (lbs) 2.5 (5.5) Housing Material: ALUMINIUM, VA, ABS/PMMA Protection Class: IP 65 Operating Temperature: °C (°F) -20 ... -
Page 6: Mechanical Dimensions
Wiring and Installation UDL 250 3. Mechanical Dimensions All dimensions in mm. UDL 250 Housing − Side View Figure 3.1.1: UDL 250 Side View UDL 250 Housing − Front View Figure 3.2.1: UDL 250 Front View 896108_wi_en_li_udl-250_pro_v130214_io_sk_fh_bf.odt V14/05/09... -
Page 7: Udl 250 Housing − Rear View
Wiring and Installation UDL 250 UDL 250 Housing − Rear View Figure 3.3.1: UDL 250 Rear View V14/05/09 896108_wi_en_li_udl-250_pro_v130214_io_sk_fh_bf.odt... -
Page 8: Wiring Diagram
Wiring and Installation UDL 250 4. Wiring Diagram Pin Assignment Figure 4.1.1: Wiring Diagram male connector The pin assignment of the male connector is as follows: Description +Vcc RS485–A RS485–B Table 4.1.1: Pin Assignment male connector 896108_wi_en_li_udl-250_pro_v130214_io_sk_fh_bf.odt V14/05/09... -
Page 9: Interfaces
Wiring and Installation UDL 250 5. Interfaces RS485 Most RS485 buses require termination resistors across the conductor pair. The need for termination has to be checked for each installation. Especially for high data rates, steep edges or long cables termination resistors are absolutely mandatory. Only both ends of the main cable, i.e. -
Page 10: Figure 5.1.1: Diagram With Switchable Termination Resistor On Rs485 Bus
Wiring and Installation UDL 250 Figure 5.1.1: Diagram with switchable termination resistor on RS485 bus Technical Data (for baud rates up to 115.2 kBps): Max. bus length: 1200 m Max. stub length: because of reflections stubs should be kept as short as possible;... -
Page 11: Leds And Beeper
Wiring and Installation UDL 250 LEDs and Beeper The standard settings for the LEDs and the beeper are as follows: LED/Beeper Action Status UDL 250 Yellow LED blinking field is switched off constantly on field is switched on Green LED blinking successful reading/writing of a transponder... -
Page 12: Mounting
Wiring and Installation UDL 250 6. Mounting For mounting on walls or ceilings deister electronic provides the ball joint bracket LRM1 (accessory) or the base plate for mast mounting LRM3 (accessory) as an ideal supplement. For further details concerning accessories refer to chapter 10. “Accessories”. -
Page 13: Mast/Tube Mounting With Base Plate Lrm3
Wiring and Installation UDL 250 Mast/Tube Mounting with base plate LRM3 Mount the base plate LRM3 directly onto the back side of the UDL 250 using the two supplied M6 screws with washers. Then mount the mast in the desired direction onto the LRM3 with a hose clamp. -
Page 14: Radiation Patterns Of The Transmitting Antenna
Wiring and Installation UDL 250 Radiation Patterns of the Transmitting Antenna 6.4.1 Cutting Plane Diagram The following diagram shows a perspective view of the UDL 250 in order to help assigning the following cutting planes to the orientation of the reader within space. Figure 6.4.1.1: Orientation of cutting planes of UDL 250 896108_wi_en_li_udl-250_pro_v130214_io_sk_fh_bf.odt V14/05/09... -
Page 15: Figure 6.4.1.2: Radiation Pattern 1
Wiring and Installation UDL 250 Figure 6.4.1.2: Radiation pattern 1 cutting plane: polarization: vertical pictured frequency: 867 MHz V14/05/09 896108_wi_en_li_udl-250_pro_v130214_io_sk_fh_bf.odt... -
Page 16: Figure 6.4.1.3: Radiation Pattern 2
Wiring and Installation UDL 250 Figure 6.4.1.3: Radiation pattern 2 cutting plane: polarization: vertical pictured frequency: 867 MHz 896108_wi_en_li_udl-250_pro_v130214_io_sk_fh_bf.odt V14/05/09... -
Page 17: Figure 6.4.1.4: Radiation Pattern 3
Wiring and Installation UDL 250 Figure 6.4.1.4: Radiation pattern 3 cutting plane: polarization: horizontal pictured frequency: 867 MHz V14/05/09 896108_wi_en_li_udl-250_pro_v130214_io_sk_fh_bf.odt... -
Page 18: Figure 6.4.1.5: Radiation Pattern 4
Wiring and Installation UDL 250 Figure 6.4.1.5: Radiation pattern 4 cutting plane: polarization: horizontal pictured frequency: 867 MHz 896108_wi_en_li_udl-250_pro_v130214_io_sk_fh_bf.odt V14/05/09... -
Page 19: Get Connection - Preparations
Wiring and Installation UDL 250 7. Get Connection – Preparations Connection via USB will create a virtual serial COM Port and will therefore consequently ask for installation of the appropriate drivers. This driver installation is described in the according instruction manual of the SNG3. SNG3 Interface Converter Figure 7.1.1: Picture of SNG3 The interface converter SNG3 (optional, see chapter 10. -
Page 20: Commissioning And Test Software Rdemo
Wiring and Installation UDL 250 8. Commissioning and Test Software RDemo The software program “RDemo” is specially designed for testing purposes. It is a helpful tool for reading out data from and writing data into the memory of a transponder. The current RDemo version can be found at: www.deister.com –... -
Page 21: Figure 8.2.2: Rdemo - Debus Button
Wiring and Installation UDL 250 Click on button “deBus” in order to open the window “RDemo : deBus”: Figure 8.2.2: RDemo – deBus button Figure 8.2.3: RDemo – deBus configuration In order to have the reader detected please proceed as follows: 1) Set “baud rate”... - Page 22 Wiring and Installation UDL 250 In order to check the communication between UDL 250 and Host/PC click on the “Version” button (see red circle below). Then a “version information received”-message will be shown in a yellow pop-up bubble in the lower part of the window: The data exchange concerning the communication between RDemo and the UDL 250 can be viewed within the window “Monitor”.
-
Page 23: Configuration Software Webconfig
Wiring and Installation UDL 250 9. Configuration Software WebConfig WebConfig is a program which allows configuration of the UDL 250 to some extent. It can easily be reached from RDemo using the according button beneath the main menu bar (see red circle below): Figure 9.1: RDemo –... -
Page 24: Table 9.1: Configuration Steps For Udl 250
Wiring and Installation UDL 250 Alternatively, WebConfig can be started without using RDemo. To do so copy the file “WebConfig.exe” from the supplied CD into a suitable directory on your local drive and then open with double click. Configuring the UDL 250 has to be carried out as follows: Step Configuration Software “WebConfig”... -
Page 25: Webconfig
For a detailed description of the configuration parameters please refer to the document “UDK2/UDK20/UDK800 – deBus Protocol” (which can be obtained on request from your local sales and service partner or at deister electronic) and the application notes which can be found at the “deister RFID Portal” (www.deister.com – deister RFID Portal). -
Page 26: Basic Setup
Wiring and Installation UDL 250 9.1.2 Basic Setup Figure 9.1.2.1: WebConfig – Basic Setup enable RS485 termination If this check box is activated, the internal RS485 termination of the device is on. read mode This parameter defines, if the reader expects only one tag in the antenna field or if there may be more tags within the antenna field. -
Page 27: Antenna Power Table
Wiring and Installation UDL 250 9.1.3 Antenna Power Table WebConfig Radiated Output Power Power Value of Antenna 0 dBm 1 mW 1 dBm 1.3 mW 2 dBm 1.6 mW 3 dBm 2 mW 4 dBm 2.5 mW 5 dBm 3.1 mW 6 dBm 4 mW 7 dBm... -
Page 28: Frequency Setup
Wiring and Installation UDL 250 9.1.4 Frequency Setup Figure 9.1.4.1: WebConfig – Frequency Setup preferred channel This value defines the channel number that the reader will preferably use prior to other channels. channel mask This mask defines the channels which may be used by the reader. Each activated check box enables the use of the corresponding channel (for more details see also chapter 9.1.5 “Table of Frequencies“). -
Page 29: Table Of Frequencies
Wiring and Installation UDL 250 9.1.5 Table of Frequencies ETSI 302 208 v1.2 (EU) DRM Ch. No. Frequency E.R.P. 865.1 MHz 865.3 MHz 865.5 MHz 865.7 MHz ≤ 2.00 W 865.9 MHz 866.1 MHz 866.3 MHz ≤ 2.00 W 866.5 MHz 866.7 MHz 866.9 MHz ≤... -
Page 30: Accessories
Wiring and Installation UDL 250 10. Accessories Article Description Article No. Connection cable, grey, 3 m, M12 connector 4-pole 9287.301 to 4-pole Phoenix connector LRM1 Ball joint bracket 6103.000 LRM3 Base Plate for mast mounting 6106.000 AC/DC Adapter Wall power supply, input voltage 230 V/AC, output 8812.000 Euro voltage 12 V/DC (1 A), Friwo®... -
Page 31: Regulatory Notices
Wiring and Installation UDL 250 11. Regulatory Notices Hereby, deister electronic GmbH declares that this equipment - if used according to the instructions - is in compliance with the essential requirements and other relevant provisions of the RTTE Directive 1999/5/EC. - Page 32 Wiring and Installation UDL 250 Index of Figures Figure 3.1.1: UDL 250 Side View................6 Figure 3.2.1: UDL 250 Front View................6 Figure 3.3.1: UDL 250 Rear View................7 Figure 4.1.1: Wiring Diagram male connector.............8 Figure 5.1.1: Diagram with switchable termination resistor on RS485 bus.....10 Figure 6.1.1: Mounting with flexible pivot LRM1............12 Figure 6.1.2: Mounting with base plate LRM3............12 Figure 6.4.1.1: Orientation of cutting planes of UDL 250...........14...
- Page 33 Wiring and Installation UDL 250 Notes: V14/05/09 896108_wi_en_li_udl-250_pro_v130214_io_sk_fh_bf.odt...
- Page 34 Wiring and Installation UDL 250 Notes: 896108_wi_en_li_udl-250_pro_v130214_io_sk_fh_bf.odt V14/05/09...
- Page 35 Wiring and Installation UDL 250 Notes: V14/05/09 896108_wi_en_li_udl-250_pro_v130214_io_sk_fh_bf.odt...
- Page 36 Fax: +49 (0) 51 05 - 51 62 17 info.de@deister.com www.deister.com Japan: France: deister electronic france deister electronic Japan, LTD. Toshiba Hoshikawa Bldg. 4F 101 rue Pierre Semard 92320 Chatillon 2-4 Kawabe-chô Tel.: +33 (0) 1 47 - 35 78 78...
