Navair F-14B Emergency Procedure Tabs

Natops pocket checklist
Hide thumbs
Table of Contents

Advertisement

Quick Links

CIRCUIT BREAKERS
EMERGENCY PROCEDURE TABS
NAVAIR 01-F14AAP-1B
POCKET CHECKLIST
AIRCRAFT
DISTRIBUTION STATEMENT C — DISTRIBUTION
AUTHORIZED TO U.S. GOVERNMENT AGENCIES
AND THEIR CONTRACTORS (1 JUNE 1992).
DESTRUCTION NOTICE — FOR UNCLASSIFIED,
LIMITED DOCUMENTS, DESTROY BY ANY
METHOD THAT WILL PREVENT DISCLOSURE OF
CONTENTS OR RECONSTRUCTION OF THE
DOCUMENT.
ISSUED BY AUTHORITY OF THE CHIEF OF
NAVAL OPERATIONS AND UNDER THE
DIRECTION OF THE COMMANDER,
NAVAL AIR SYSTEMS COMMAND.
REFERENCE DATA
NATOPS
F-14B
01 AUGUST 2001
BINGO
ECS LEAKS
COCKPIT/OXYGEN
COOLANT/CANOPY
CONTROLLED
MANUAL
GROUND EGRESS
GENERATOR
ELECTRICAL
TRANS/RECT
WOW
AICS/AIRSTART
NOZZLE/START VALVE
OIL/THROTTLE
INFLIGHT
ON DECK
ELECTRICAL
FLAPS
FLAPS
FLIGHT
SPOILERS
SPOILERS
CONTROL
WINGSWEEP
WINGSWEEP
SAS
SAS
DUMP
LEAK
PRESSURE
TRANSFER
COMBINED
FLIGHT
HYDRAULICS
BRAKES
ARRESTMENT
LANDING GEAR/
BRAKES
BLOWN TIRE
LAUNCH BAR
TAKEOFF
SINGLE ENGINE
LANDING
CRUISE/FUEL
MIGRATION
ABORT
BLOWN TIRE
ECS
EJECT/
EGRESS
ENGINE
FIRE
FLIGHT
CONTROL
FUEL
LANDING
OPS
TAKEOFF
