OUTDOOR HOUSING
PIH - 510 H/L/G & 510 H/L/G IP
INSTALLION / OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PIH-510 H and is the answer not in the manual?

Questions and answers

Summary of Contents for Otima PIH-510 H

  • Page 1 OUTDOOR HOUSING PIH - 510 H/L/G & 510 H/L/G IP INSTALLION / OPERATION MANUAL...
  • Page 2: Important Safeguards

    IMPORTANT SAFEGUARDS 1. Read Instructions All the safety and operating instructions should be read before the unit is operated. 2. Retain Instructions The safety and operating instructions should be retained for future reference. 3. Head Warnings All warnings on the unit and in the operating instructions should be adhered to. 4.
  • Page 3: Installation

    INSTALLATION Step 1 Separate The Housing and PSU Box Untighten the screws Untighten and pull out Separate the housing Untighten the screws from PSU box and the bolt from the hinge and PSU box from PSU box open it. (Goose Neck) Step 2 Install Power Supply Unit When use 24Vac power source:...
  • Page 4 Step 3 Install the Power Box Drill 4 holes on desired Tighten 4 screws to fix the power box Drill holes on the locations (These four screws are not supplied. intended positions of User must prepare their own screws.) of the wall. (Goose Neck) Step 4 Connection...
  • Page 5 2. Connect Alarm, telemetry control (RS-485) and Video cables: Untighten the right Connect the Connect the video Connect the Alarm knob, put the Alarm, telemetry control cable to output jack input cable to Alarm RS-485 and video (RS-485) to RS-485 Input cables through the Input...
  • Page 6 2. Connect Alarm, RS-485, RJ-45 and Video cables: TXDI TXDI ALARM 1 Untighten the right knob, put Connect the telemetry Connect the Alarm input the Alarm, RS-485, RJ-45 control (RS-485) to RS-485 cable to Alarm Input and video cables through the Input (TXDI+,TXDI-) (Alarm 1 &...
  • Page 7: Camera Setting

    Attach the base to Connect the housing Tighten 3 screws to housing cable fix base Step 6 Camera Setting Setting Fast Dome ID Setting Alarm Mode Setting Camera Function Setting Fan Power Refer to FastDome operation manual for camera setting Step 7 Attach Camera Body and Base Reconnect the...
  • Page 8 Step 9 Attach PSU and Bracket Attach the housing Insert the bolt into back to PSU box the hinge and tighten Step 10 Connection Between Housing and FastDome Connect the fan & Connect the Fast heater cable to pin Dome cable to jack connection jack Step 11...
  • Page 9: Wall Mounting

    Wall Mounting Attach the bracket Tighten the 4 screws and housing to the box to fix the bracket Swan Neck Tighten the screws of PSU box to fix the cover.
  • Page 10: Structural Drawing

    STRUCTURAL DRAWING Pendant 274.0mm 70.0mm 477.5mm 270.0mm Wall Mounting 70.0mm 204.0mm 367.15mm 312.5mm 270.0mm 405.0mm...
  • Page 11 Swan Neck 500.0mm 225.0mm 320.0mm 650.0mm 270.0mm 200.0mm 685.0mm...
  • Page 12: Wiring Diagram

    WIRING DIAGRAM Outdoor Housing Connect to Heater and Fan DC12V DC12V Connect to TXDI+ TXDI- SWITCH POWER SWITCH POWER FastDome TXDO+ TXDO- LINE AC90~260V AC24V ALARM NEUTRAL AC-OUT ALARM NEUTRAL LINE NEXT AC-IN AC-IN VIDEO FastDome Keyboard AC24V 24Vac Outdoor Housing for IP Series Connect to Heater and Fan DC12V...
  • Page 13: Specification

    SPECIFICATION Outdoor Housing Model No. PIH-510 H PIH-510 L PIH-510 G Type Pendant Wall Mounting Swan Neck Brocket Aluminum Flame Resistant ABS Construction Steel Internal Fixing Polycarbonate Housing DC12V Input Voltage 700mA (Fan + Heater) Connection Current Consumption RS-485 In (2 inputs) RS-485 Out (2 outputs)
