Foyum FY-DPBF Manual

2 - 3 cm

Auto-scan Type

Multi-frequency

Up to 4 different remotes in 1

PROGRAMMING:

-standard
1.Hold button 1 and press button 2 f our times ,then
release both buttons, the led of FY-DPBF emits a quick
f lash every 2 sec.
2.Place and press the original remote control in f ront of
the remote , at about 2-3 cm of distance,until the led of
FY-DPBF starts f lash quickly.
3.While the LED of FY-DPBF is f lashing, press the
button of the FY-DPBF where you want to store ,the
remote'code just copied, until the led will turn of f .
Note:
To duplicate a second button, repeat the operation f rom
the point 1.
Automatic matching code:
Hold on pressing press the button you want to match
code. until the receiver emitt the code ,the led of the
remote f lash quickly ,then release the button ,the
remote's code has matched successfully .

Emitting seed code:

Pressing the button 1 and button 2 at the same time
until LED f lashes quickly . Release two buttons .press
the button that you want to emit seed code , it has
emitted seed code successf ully .
AMC: Automatic matching code
FY-DPBF UNIVERSAL REMOTE
Best position for duplication
-BFT
1.Hold button 1 and press button 2 f our times ,then release both buttons,the
led of FY-DPBF emits a quick f lash every 2 sec.
2.Place the original remote control in f ront of the remote, at about 2-3 cm of
distance
3.Press and retain pressed the button of the original remote control that you
want to copy until the remote's led will turn on with a f ix light and then emits a
double f lash every 2 sec.
4.Transmit now the seed code of the original remote control (by pressing the
rear hide button or the buttons 1 and 2 simultaneously in the new models)
5. Now the LED will f lash quickly, press the button of the remote where you
want to store the code just copied, until the LED will turn of f .
AMC
6.Now activate the procedure to insert the new remote control on the
receiver.
-FAAC and GENIUS
ATTENTION, PLEASE: Verif y that the remote control to be copied is a
MASTER.
Pressing any button, the LED should issue a double f lash rather than switch
on immediately as a f ixed light.
1.Hold button 1 and press button 2 f our times
2.Place the original remote control in f ront of the remote, at about 2-3 cm of
distance
3.Press and retain pressed the original remote control button that you want to
copy until the LED FY-DPBF switches on a f ixed light and then It stars to emit
a double f lash every 2 seconds.
4.Predispose the FAAC/GENIUS remote control f or the emission of the seed
code (by pressing simultaneously the buttons 2 and 3)
5.While the FAAC/GENIUS LED is f lashing, place it in f ront of the FY-DPBF, at
about 2-3 cm of distance and press the button that you want to copy until the
remote's led will change frequency of flashing (faster than before), as
confirm of the correct copy of the code.
-V2
1.Hold button 1 and press button 2 f our times ,then
release both buttons,the led of FY-DPBF emits a quick
f lash every 2 sec.
2.Place the original remote control in f ront of the
remote, at about 2-3 cm of distance
3.Press and retain pressed the button of the original remote control that
you want to copy until the remote's led will turn on with a f ix light and
then emits a double f lash every 2 sec.
4.Press and retain pressed once again the same button of the original
remote control.
5.Now the LED will f lash quickly, press the button of the remote where
you want to store the code just copied, until the LED will turn of f .
6.Now activate the procedure to insert the new remote control
AMC
on the receiver.
COMPATIBILITES LIST
ACM TX2, TX2 COLOR, TX4
ADYX AMC TE4433H BLUE, 433-HG BRAVO
COMPACT, HY-DOM, MERCURI B, MERCURI C, SABUTON, MARS,
AERF
SATURN, ST3/N, TERRA, TMP-1, TMP-2, UNITECH
BROWN, BROWN RED, BRO.OVER, PASS, MINIPASS, TECH3
ALLMATIC AMC
APERIO GO, GO PRO, GO MINI
TX02-434-2,TX02-868-2 BLUE,4025 TX02-868-2,4022 TX02-434-2, 4020-
APERTO
TX03-434,TX-03-868-4,4013,TX03-434-4
(Sommer)
APRIMATI
TR2/TR4, TM4, TXM
AMC
C
PTX4 BLUE, PTX4 PINK
ATA
AVIDSEN 104251, 104250, 104250 OLD, 104250 RED, 104257, 104350, 654250
BALLAN
FM400, FM400E,FM404B,4013
BENINCA TO. GO. WV, TWV, ROLLKEY, APPLE, LOT WCV, CUPIDO, TO.GO. QV, IO,
LOT2WCV,LOT1W,LOT2W,LOT4W,LOT1WM,LOT2WM, T2W,T4W,APPLE
AMC
BESIDE BEZAP,HIT
MITTO, MITTO M ( MITTO2M/MITTO4M), MITTO RCB (MITTO
BFT RCB02/RCB04), MITTO A (MITTO 2A/MITTO 4A), MITTO B,
TRC(TRC2/TRC4), GHIBLI, MURALE, KLEIO,TE01,TE02,TE04,RB4
AMC
MURALE
CAME T431,T434,TOP432A,TOP434A,TOP432,TAM432SA,TOP432NA
TRQ S449 (TRQ449100/TRQ449200/TRQ449300/TRQ449400), TRQ S449
CARDIN GREEN (PRECODE), TXQ S449 (TXQ449200/TXQ449300/TXQ449400),
TXQ S449 GREEN, TRQ S486 (TRQ486200/TRQ486400), TXQ S486
AMC
(TXQ486200/TXQ486400), S437 TX, XRADO,S449,S476TX2,S476TX, S486
CASALI JA33 AMIGO, GENIUS/CASALI A252RC
