Summary of Contents for Datum Trak-Slider
- Page 1 Trak-Slider Instructions American Filing Solutions P.O. Box 891719, Temecula, CA 92589 Toll Free: (888) 891-1970 x 8958 Fax: (888) 891-9970 Email: sales@FilingToday.com www.FilingToday.com...
- Page 2 1/4-20 Flanged 1/4-20 x 3/4" Hex Nut Hex Head Bolt Gusset 1/4-20 x 1/2" 1/4-20 Nylock Nut Allen Cap Screw Rivet 1/4-20 x 3/8" Pan Head Phillips 1/4 USS Flat Washer Machine Screw #8 x 3/8" Tek Screw Phillips 1/4-20 "J" Type Tinnerman Nut Wheel End Stop 3/4"SQ x 1/2"...
- Page 3 American Filing Solutions P.O. Box 891719, Temecula, CA 92589 Toll Free: (888) 891-1970 x 8958 Fax: (888) 891-9970 Email: sales@FilingToday.com www.FilingToday.com...
- Page 4 NOTE: All shelving used on a Datum Bi/Tri Slider system must have the same overall height. The shelving must also have a minimum of 1-1/2" of clearance from the floor to the filing surface of the bottom shelf. TOOLS REQUIRED: 7/16" wrench & socket set 7/32"...
- Page 5 American Filing Solutions P.O. Box 891719, Temecula, CA 92589 Toll Free: (888) 891-1970 x 8958 Fax: (888) 891-9970 Email: sales@FilingToday.com www.FilingToday.com...
- Page 6 NOTE: All systems will consist of one starter rail assembly and the required amount of add-on rail assemblies. Example: A B632LT consists of (1) #36LTBSST; starter and (2) 36LTBSAO; add-on (Part numbers are found on each box.) The starter rail assembly contains one section of rail and hardware.
- Page 7 American Filing Solutions P.O. Box 891719, Temecula, CA 92589 Toll Free: (888) 891-1970 x 8958 Fax: (888) 891-9970 Email: sales@FilingToday.com www.FilingToday.com...
- Page 8 Wheel End Stop STEP 11: Attach 2" bases to mobile carriage using (4) 1/4-20 x 3/4" hex bolt and 1/4-20 nylock nut (See figure 4). NOTE: When using Datum 2" bases, the carriages and bases will have pre-punched holes for attachment.
- Page 9 Important: Step 12a-12b for Datum Thinkstak Shelving STEP 12A: Each movable shelf section will require 6 rivets per shelf opening. Please refer to the diagram below for proper rivet placement. Additional rivets are included in each hardware kit. Install Additional Rivets Here When...
- Page 10 STEP 14: Mount a top stabilizer bracket assembly to the top of each Bi-Slider rolling section using (3) 1/4-20 x 3/4" hex bolts, (3) flat washers and (3) 1/4-20 nylock nuts (holes are prepunched when using 1" tops). See figure 5. STEP 14A: Tri/Quad Slider system only.
-
Page 11: Safety Precautions
While this problem is more annoying than hazardous, it may be corrected by re-leveling the rail assembly. The Datum Bi/Tri Slider system has been designed so that the deck plates can be easily removed for access to the leveling glides.
