Summary of Contents for Airbus TW1m
- Page 1 TW1m Instruction Manual PS11730AENAD01 11/2018...
- Page 2 DECLARATION OF CONFORMITY We, Airbus Defence and Space Oy, Hiomotie 32, 00380 Helsinki, Finland, declare under our sole responsibility that the product TW1m is in conformity with the provisions of the following Council Directives: • 2011/65/EC (ROHS) • 2014/53/EU (Equipment Directive).
-
Page 3: Table Of Contents
10.GLOSSARY............... . 27 TW1m - Instruction Manual PS11730AENAD01 3/27 This document is the property of Airbus DS SLC and should not be copied or circulated without permission. -
Page 4: Introduction
The TW1m modem described in this manual is approved for use in the TETRA network. Contact your service provider for more information about networks. When using the features in the TW1m modem, obey all laws and respect the privacy and legitimate rights of others. Company policy Our policy is one of continuous development;... -
Page 5: Important Safety Information
TW1m - Instruction Manual PS11730AENAD01 5/27 This document is the property of Airbus DS SLC and should not be copied or circulated without permission. -
Page 6: Potentially Explosive Environments
• Do not store the TW1m modem in hot areas. High temperatures can shorten the life of electronic devices, damage batteries and warp or melt certain plastics. • Do not store the TW1m modem in cold areas. When it warms up (to its normal temperature), moisture can form inside, which may damage electronic circuit boards. -
Page 7: Device Overview
• Programming interface The TW1m modem is designed to be a TETRA modem solution that is compact in size yet provides a full TETRA feature set required by typical data and voice applications. It has been made integrator- and service friendly with commercial off-the-shelf connectors and a standard programming interface. - Page 8 MAB-1 must be integrated into an enclosure for environmental protection. Interfaces are provided as commercial connectors and external cabling must be customized by the user. PS11730AENAD01 TW1m - Instruction Manual 8/27 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.
-
Page 9: Technical Data
The integrating requires that the cables are tailored to the optimum length. Airbus does not provide the tailored cables. The RF antennas should be installed a minimum of 50cm from the TW1m boards to avoid TETRA interferences. Note: Simultaneous use of AT commands and IP data is not supported. -
Page 10: Device Layout
The TW1m modem features a GPS receiver for positioning applications. An external active GPS antenna is required for the receiver. Do not use a passive GPS antenna! The TW1m modem does not have an integrated TETRA antenna. Therefore, a connector for an external antenna is provided. A combined TETRA/GPS antenna can also be used. - Page 11 Data mode FBUS parametering MBUS prametering Table 3 Operation mode truth table (X = Any value) TW1m - Instruction Manual PS11730AENAD01 11/27 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.
-
Page 12: Operating Modes
FBUS and MBUS signals are disconnected from the UART transceivers and RS-232 or USB ports are not used during flashing. The TW1m modem’s flashing mode is toggled by pulling the PROG_EN signal (System Connector 2’s pin 5) low. The prommer mode is for Airbus R&D internal use only. -
Page 13: Interfaces
The connector type is JST B8B-PH-SM4-TB(LF)(SN) and the mating connector is JST PHR-8. Figure 7 Power connector TW1m - Instruction Manual PS11730AENAD01 13/27 This document is the property of Airbus DS SLC and should not be copied or circulated without permission. -
Page 14: System Connector 1
0 - 0.54V 1.26 - 1.8V 10mA (Internal pull-up) SGND 2.78V 40mA MIC- / Accessory supply PS11730AENAD01 TW1m - Instruction Manual 14/27 This document is the property of Airbus DS SLC and should not be copied or circulated without permission. -
Page 15: System Connector 2
1.95 - 3.0V 10mA 2.70V 10mA 10-bit ADC input *) not connected Table 6 System Connector 2’s pinout TW1m - Instruction Manual PS11730AENAD01 15/27 This document is the property of Airbus DS SLC and should not be copied or circulated without permission. -
Page 16: Rs-232 Connector
± 5.4V 10mA ± 25V 10mA ± 5.4V 10mA ± 5.4V 10mA Table 7 RS-232 Connector’s pinout PS11730AENAD01 TW1m - Instruction Manual 16/27 This document is the property of Airbus DS SLC and should not be copied or circulated without permission. -
Page 17: U.fl Connectors
The SIM card holder is a plastic guide to support the SIM card on the TH1n SIM connector. TW1m - Instruction Manual PS11730AENAD01 17/27 This document is the property of Airbus DS SLC and should not be copied or circulated without permission. -
Page 18: Tools And Accessories
The overall device cabling is typically specific made to fit for purpose by the integrator. PS11730AENAD01 TW1m - Instruction Manual 18/27 This document is the property of Airbus DS SLC and should not be copied or circulated without permission. -
Page 19: Installation
For more information and local requirements about ESD protection and ESD Protected Area, contact your local Airbus Defence and Space After Market Services representative. TW1m - Instruction Manual PS11730AENAD01 19/27 This document is the property of Airbus DS SLC and should not be copied or circulated without permission. -
Page 20: Environmental Conditions
SAR is not evaluated as the device is not a handheld device. Table 8 TW1m modem’s environmental conditions WARNING: Do not install the TW1m modem in a dusty environment. If the modem and the heat sink are dusty, they can overheat. Tools and installation materials ... -
Page 21: Powering Up Considerations
In certain conditions and usage forced air-cooling may be necessary. 2. Check that you have the tools and mounting screws that are suitable for the material the TW1m modem is to be installed on, and the accessories needed for the installation and operation of the TW1m modem. -
Page 22: Lightning Protection
Grounding The TW1m modem has been designed for negative ground systems. If you install the TW1m modem in a system with positive ground, take a special care to ensure that the grounding and supply voltages are correctly connected. All the input and output signal voltages in this document are always referred to the GND pins of the connector. -
Page 23: Programming
Figure 12. Figure 12 AB1 variant USB Parameterization cable connection System connector 2. Connection example for using standard USB cable to TW1m A2 and A4 parameterization is shown in Figure 13. Figure 13 A2 and A4 variant CA-119 Parameterization cable connection... -
Page 24: Configuring Tw1M
TW1m is configured (see Figure 15 for an example). Figure 14 Device configuration: Default values of the common settings PS11730AENAD01 TW1m - Instruction Manual 24/27 This document is the property of Airbus DS SLC and should not be copied or circulated without permission. - Page 25 P R O G R A M M I N G Figure 15 Device configuration: Example of adjusting the connection specific settings TW1m - Instruction Manual PS11730AENAD01 25/27 This document is the property of Airbus DS SLC and should not be copied or circulated without permission.
-
Page 26: Feature Guide
AT commands can be used to manage and control the functionality of the TW1m modem. For a complete list of the AT commands, refer to the latest version of the document AT Command set for Airbus DS TETRA products , which is available in Cinfodin. -
Page 27: Glossary
UART Universal asynchronous receiver-transmitter Universal serial bus USB_VBUS USB voltage line VBAT Voltage battery line Nbr_page TW1m - Instruction Manual PS11730AENAD01 27/27 This document is the property of Airbus DS SLC and should not be copied or circulated without permission. - Page 28 PS11730AENAD01...
