Summary of Contents for SyncusTech EMB-BYT1000
- Page 1 USER MANUAL SYNCUSTECH Synchronous with Customer EMB-BYT1000 Custom General Description Rev 0.2...
-
Page 2: Table Of Contents
SyncusTech USER MANUAL | EMB-BYT1000 Contents 1. TECHNICAL SPECIFICATIONS ················································· 4 2. JUMPERS & CONNECTORS ···················································· 5 2.1 Quick Listing of Jumpers ···································································· 6 2.2 Quick Listing of Connector ·································································· 6 3. INSTALLATION & DESCRIPTION ·············································· 7 3.1 JUMPER INSTALLATION ··································································· 7 3.1.1... - Page 3 SyncusTech USER MANUAL | EMB-BYT1000 4. I/O MAP ··············································································· 15 5. IRQ LIST·············································································· 16 6. MEMORY MAP ····································································· 16 7. BLOCK DIAGRAM ································································ 17 Page 3 www.syncus.co.kr / www.syncustech.com...
-
Page 4: Technical Specifications
SyncusTech USER MANUAL | EMB-BYT1000 1. TECHNICAL SPECIFICATIONS Module Function Description CPU (SOC) Intel® AtomTM E38XX Max. Speed 1.46 ~ 1.91GHz Processor System L2 Cache 512KB ~2MB Instruction set 64-bit BIOS UEFI Technology DDR3L Memory Max. Capacity Socket 1 x 204-pin DDR3 SODIMM Controller Intel®... -
Page 5: Jumpers & Connectors
SyncusTech USER MANUAL | EMB-BYT1000 2. JUMPERS & CONNECTORS The figures below show all the connectors and jumpers. Jumpers and Connectors Page 5 www.syncus.co.kr / www.syncustech.com... -
Page 6: Quick Listing Of Jumpers
SyncusTech USER MANUAL | EMB-BYT1000 2.1 Quick Listing of Jumpers RS422/485 CONTROL SELECT RS232/RS422,485 SELECT CMOS CLEAR FLAT PANEL (Backlight) POWER SELECT FLAT PANEL (Backlight control) POWER SELECT FLAT PANEL (VDD) POWER SELECT mSATA / mPCIe SELECT 2.2 Quick Listing of Connector... -
Page 7: Installation & Description
SyncusTech USER MANUAL | EMB-BYT1000 INSTALLATION & DESCRIPTION 3.1 JUMPER INSTALLATION 3.1.1 J1 & J2 : RS232/485 SELECT DESCRIPTION PIN No Select RS485 (1-2) Select RS422 (2-3) 3.1.2 J3 : CMOS CLEAR DESCRIPTION PIN No Normal operation (1-2) CMOS Clear (2-3) 3.1.3 J4 : FLAT PANEL BACKLIGHT SELECT... -
Page 8: Connector Description
SyncusTech USER MANUAL | EMB-BYT1000 3.2 CONNECTOR DESCRIPTION 3.2.1 CN1 : TEMP CONNECTOR SIGNAL SIGNAL PIN No 1.8V MISO MOSI 3.2.2 CN2 : POWER & RESET BUTTON SIGNAL SIGNAL PIN No +3.3V +3.3V +3.3V SATA_LED POWER SW RESET SW 3.2.3 CN3 : RS422/485 CONNECTOR... -
Page 9: Cn5 : Ps2 Keyboard, Mouse Header
SyncusTech USER MANUAL | EMB-BYT1000 3.2.5 CN5 : PS2 KEYBOARD, MOUSE HEADER SIGNAL PIN No MOUSE DATA MOUSE CLK K/B DATA K/B CLOCK 3.2.6 CN6 : TPM 1.2 INTERFACE HEADER SIGNAL SIGNAL PIN No L_CLKOUT1 L_FRAME_N RESET L_AD3 L_AD2 3.3V... -
Page 10: Cn8 : Dual Com3, Com4 Connector
SyncusTech USER MANUAL | EMB-BYT1000 3.2.8 CN8 : DUAL COM3, COM4 CONNECTOR SIGNAL SIGNAL PIN No DCD3 DCD4 RXD3 RXD4 TXD3 TXD4 DTR3 DTR4 DSR3 DSR4 RTS3 RTS4 CTS3 CTS4 3.2.9 CN9 : COM1, VGA CONNECTOR SIGNAL SIGNAL PIN No... -
Page 11: Cn10 & Cn11 : Rj45 + Dual Usb Connector
SyncusTech USER MANUAL | EMB-BYT1000 3.2.10 CN10 & CN11 : RJ45 + DUAL USB CONNECTOR SIGNAL SIGNAL PIN No DATAN TD0P DATAP TD0N TD1P TD1N DATAN TD2P DATAP TD2N TD3P TD3N 3.2.11 CN12 : USB 3.0 CONNECTOR SIGNAL SIGNAL PIN No... -
Page 12: Cn14 : Flat Panel (Backlight Control) Select
SyncusTech USER MANUAL | EMB-BYT1000 3.2.13 CN14 : FLAT PANEL (Backlight control) SELECT SIGNAL PIN No VCC_BLT VCC_BLT BLT_EN BLT_CTRL 3.2.14 CN15 : FLAT PANEL LVDD : "J6" Flat Panel LCD POWER Select BLT_VCC : " J4" Flat Panel BACKLIGHT Select... -
Page 13: Cn16 : Msata / Mpcie Connector
SyncusTech USER MANUAL | EMB-BYT1000 3.2.15 CN16 : mSATA / mPCIe CONNECTOR SIGNAL SIGNAL PIN No PCIE_WAKE_N 3.3V 1.5V PCIE_R_CLKRE PCIE_REFCLK2_ PCIE_REFCLK2_ W_DISABLE# PERST# RX0_DN 3.3V RX0_DP 1.5V SMB_PCIE_CLK TX0_DN SMB_PCIE_DAT TX0_DP USB2_DN USB2_DP 3.3V 3.3V 1.5V 3.3V 3.2.16 CN17 : SATA POWER CONNECTOR... -
Page 14: Cn18 & Cn19 : Sata Connector
SyncusTech USER MANUAL | EMB-BYT1000 3.2.17 CN18 & CN19 : SATA CONNECTOR SIGNAL SIGNAL PIN No 3.2.18 CN20 : USB4,5 EXTENSION HEADER SIGNAL SIGNAL PIN No USB2_P4_DN USB2_P5_DN USB2_P4_DP USB2_P5_DP 3.2.19 CN21 : AUDIO HEADER SIGNAL SIGNAL PIN No LINE_IN_L... -
Page 15: I/O Map
SyncusTech USER MANUAL | EMB-BYT1000 4. I/O MAP The Address Map of I/O Port in Main chipset 000H – 00FH 8237 DMA Controller 020H – 03FH 8259 Interrupt Controller 040H – 05FH 8254 Timer 060H – 06FH 8042 K/B Controller 070H –... -
Page 16: Irq List
SyncusTech USER MANUAL | EMB-BYT1000 5. IRQ LIST IRQ Number IRQ Object IRQ0 Timer IRQ1 PS/2 Keyboard IRQ2 Second 8259 IRQ3 COM 2 IRQ4 COM 1 IRQ5 Reserved IRQ6 IRQ7 IRQ8 Real time Clock IRQ9 Reserved IRQ10 Reserved IRQ11 Reserved IRQ12 Reserved &... -
Page 17: Block Diagram
SyncusTech USER MANUAL | EMB-BYT1000 7. BLOCK DIAGRAM Page 17 www.syncus.co.kr / www.syncustech.com...
